Honeywell MC-PHAO01 / MC-PLAM02 / MC-PSIM11 Low Level Analog Mux | Replacement, Equivalent & Selection Guide
The Honeywell MC-PHAO01, MC-PLAM02, and MC-PSIM11 are low-level analog multiplexer (mux) I/O modules designed for Honeywell’s Experion PKS and TDC 3000 distributed control systems (DCS). These modules handle low-level analog signal conditioning and multiplexing for process measurement inputs such as thermocouples and RTDs. Konmask.com supplies genuine and compatible replacement units with full traceability.
Technical Specifications
- Part Numbers: MC-PHAO01 / MC-PLAM02 / MC-PSIM11
- Manufacturer: Honeywell Process Solutions
- Series: Experion PKS / TDC 3000 / PlantScape
- Module Type: Low Level Analog Multiplexer (Mux) I/O Module
- Signal Type: Low-level analog inputs (thermocouple, RTD, mV)
- Form Factor: DIN-rail / card cage mount (system-dependent)
- Communication: Proprietary Honeywell DCS backplane bus
- Operating Temperature: 0°C to 60°C
- Power Supply: Supplied via DCS backplane
- Weight: Approx. 1,400 g (packaged)
- Compliance: CE, UL (system-level certification)
Compatible Replacement & Equivalent Models
The following models are functionally equivalent or direct replacements for the MC-PHAO01 / MC-PLAM02 / MC-PSIM11 in Honeywell DCS environments:
- MC-PHAO01 — Primary analog output / mux card (direct replacement)
- MC-PLAM02 — Low-level analog mux module, compatible slot replacement
- MC-PSIM11 — Signal interface module, compatible in same card cage
- MC-PHAO02 — Upgraded variant; verify firmware compatibility before substitution
- MC-TAIH02 — High-level analog input alternative for non-mV applications
Always verify hardware revision and firmware version with your DCS system engineer before substituting modules.
Why Choose the Original Model
- Factory-calibrated for Honeywell DCS backplane signal integrity
- Guaranteed compatibility with Experion PKS R400–R520 and TDC 3000 LCN/UCN
- Supports Honeywell’s FDM (Field Device Manager) diagnostics
- Minimizes re-engineering risk in brownfield plant upgrades
- Backed by Honeywell’s global spare parts and lifecycle support program
Typical Applications
- Thermocouple and RTD temperature measurement in refinery and petrochemical plants
- Low-level mV signal acquisition in power generation control systems
- Analog I/O expansion in existing Experion PKS or TDC 3000 cabinets
- Replacement of failed or end-of-life mux cards during planned shutdowns
- Spare parts inventory for critical process control infrastructure
System Compatibility
- Honeywell Experion PKS — R400, R410, R430, R500, R510, R520
- Honeywell TDC 3000 — LCN, UCN, HPM, APM subsystems
- Honeywell PlantScape — Legacy installations
- Not compatible with Honeywell Safety Manager or ControlEdge series without engineering review
Selection Guide
Use the table below to select the correct module for your application:
- Need analog output (mA)? → MC-PHAO01
- Need low-level mux input (TC/RTD/mV)? → MC-PLAM02
- Need signal interface / termination? → MC-PSIM11
- Upgrading from TDC 3000 to Experion PKS? → Consult Konmask for migration kit options
- Need hot-swap capability? → Confirm chassis revision supports online replacement
Quality Assurance & Sourcing
- All modules are sourced from authorized distributors or verified surplus with full documentation
- Each unit undergoes visual inspection, functional bench test, and ESD-safe packaging
- Certificate of conformance (CoC) and test reports available on request
- Traceability records maintained for 5 years per ISO 9001 practices
- Konmask.com does not supply counterfeit or uncertified components
How to Order
- Confirm your exact part number (MC-PHAO01, MC-PLAM02, or MC-PSIM11) from your system BOM or cabinet label
- Note your DCS system version (Experion PKS release or TDC 3000 generation)
- Contact Konmask.com via email or phone with quantity and required delivery timeline
- Receive quotation with lead time, CoC availability, and shipping options
- Place order — standard lead time 3–10 business days; expedited available
Replacement & Compatibility FAQ
Q: Can MC-PLAM02 replace MC-PHAO01 directly?
A: They serve different functions (mux input vs. analog output). Confirm your application requirement before substituting.
Q: Is MC-PSIM11 compatible with Experion PKS R520?
A: Generally yes for legacy I/O cabinets. Verify with Honeywell’s compatibility matrix or contact Konmask for engineering support.
Q: Do you supply refurbished units?
A: Yes. All refurbished units are tested and include a 12-month warranty. New surplus and factory-new options also available.
Q: What is the lead time for urgent orders?
A: Expedited shipping available for in-stock units. Contact us for same-day quotation.
Q: Can I return a module if it doesn’t fit my system?
A: Yes, within 30 days with original packaging and documentation. See our returns policy for details.
