Process Control Chassis Solution – Honeywell TC-FXX132 | TotalPlant Solution (TPS)
Where This Product Is Used
The Honeywell TC-FXX132 13-Slot Chassis is a core structural and backplane component of the Honeywell TotalPlant Solution (TPS) Distributed Control System (DCS). It is deployed across the most demanding continuous-process industries where system uptime, signal integrity, and modular expandability are non-negotiable.
- Oil & Gas Refining – Crude distillation unit (CDU) control, compressor surge control, and flare management systems
- Petrochemical & Chemical Plants – Reactor temperature/pressure loop control, batch sequencing, and safety interlock integration
- Power Generation – Boiler management systems (BMS), turbine control, and load-dispatch automation
- Pulp & Paper – Digester control, recovery boiler management, and stock preparation automation
- Pharmaceutical Manufacturing – cGMP-compliant process control for fermentation, purification, and filling lines
- Water & Wastewater Treatment – SCADA-integrated pump station control and chemical dosing systems
- LNG & Offshore Platforms – Hazardous-area rated control cabinets requiring compact, high-density I/O chassis
Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | TC-FXX132 |
| Manufacturer | Honeywell Process Solutions |
| Series / Platform | TotalPlant Solution (TPS) / HPM |
| Chassis Slots | 13 slots (I/O module positions) |
| Backplane Bus | High-speed TPS proprietary backplane |
| Compatible Modules | TC-series I/O, power, and controller modules |
| Mounting | 19-inch rack panel mount |
| Weight | 1,680 g (approx.) |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Humidity | 5% to 95% RH, non-condensing |
| Power Input | Via dedicated TPS power supply module |
| Certifications | CE, UL listed (platform-level) |
Why Engineers Specify This Model
- High-Density I/O Integration – 13 slots allow consolidation of analog, digital, and specialty I/O modules in a single chassis, reducing cabinet footprint and wiring complexity.
- Proven TPS Backplane Architecture – The proprietary backplane ensures deterministic, low-latency communication between modules — critical for tight PID loop performance in refinery and power applications.
- Hot-Swap Module Support – Compatible TPS modules support online insertion and removal (OIR), enabling maintenance without process shutdown.
- Long-Term Platform Availability – TPS remains operational at thousands of sites globally; TC-FXX132 chassis are actively sourced for brownfield expansions and lifecycle replacements.
- Standardized Rack Form Factor – 19-inch rack compatibility simplifies integration into existing control room enclosures and DIN-rail cabinets.
- Redundancy-Ready – Supports redundant power supply configurations when paired with appropriate TPS power modules.
Complete System Bill of Materials
The TC-FXX132 chassis is typically deployed as part of a complete HPM (High-Performance Manager) node. Common companion components include:
- TC-PRS021 – TPS Power Supply Module (primary)
- TC-PRS022 – TPS Power Supply Module (redundant)
- TC-CCR013 – High-Performance Manager (HPM) Controller Card
- TC-IAH061 – Analog Input Module (16-channel, 4–20 mA)
- TC-OAH062 – Analog Output Module (8-channel)
- TC-IDJ161 – Digital Input Module (32-channel, 24 VDC)
- TC-ODJ161 – Digital Output Module (32-channel)
- TC-FBM207 – FOUNDATION Fieldbus H1 Interface Module
- TC-FPCXX2 – Chassis Filler Panel (for unused slots)
Contact Konmask.com for complete BOM sourcing — we supply full HPM node kits from verified stock.
Compliance & Industry Standards
- IEC 61511 – Functional Safety for Process Industry Sectors (platform-level SIL compliance when integrated with Honeywell Safety Manager)
- IEC 61131-2 – Programmable Controllers: Equipment Requirements and Tests
- NAMUR NE 21 – Electromagnetic Compatibility of Industrial Process and Laboratory Control Equipment
- CE Marking – Conformity with EU EMC and Low Voltage Directives
- UL 508 – Industrial Control Equipment (platform-level listing)
- RoHS Compliant – Restriction of Hazardous Substances (where applicable to production date)
Quality Assurance & Sourcing
Konmask.com specializes in the procurement of genuine, tested industrial automation components for brownfield DCS maintenance, lifecycle replacement, and system expansion projects.
- ✅ Authenticity Verified – All Honeywell TPS components are inspected against OEM part markings, date codes, and firmware labels before dispatch.
- ✅ Functional Test Available – Power-on and backplane continuity testing available on request for critical spares orders.
- ✅ Traceability Documentation – Certificate of conformance (CoC) and inspection report provided upon request.
- ✅ Secure Packaging – ESD-safe anti-static bags, foam-lined cartons, and moisture barrier packaging for international shipment.
- ✅ Global Logistics – DDP/DAP shipping to major industrial hubs: Middle East, Southeast Asia, Europe, and Americas.
How to Source This Part
Procurement teams and maintenance engineers can source the TC-FXX132 through the following channels:
- Online Order – Add to cart and complete checkout at Konmask.com. Secure payment via T/T bank transfer, PayPal, or credit card.
- RFQ / Bulk Inquiry – Email support@konmask.com with your required quantity, delivery timeline, and destination port for a formal quotation.
- Urgent Spares – Call or WhatsApp +0086 19859288691 for same-day quotation on emergency maintenance requirements.
- BOM Sourcing – Submit your full HPM node BOM and we will provide a consolidated quote covering all line items.
Lead Time: Ex-stock items ship within 3–5 business days. Non-stock items: 2–4 weeks subject to availability.
Application-Specific FAQ
Q: Is the TC-FXX132 compatible with Honeywell Experion PKS?
A: The TC-FXX132 is a TPS/HPM platform chassis. While Experion PKS can interface with legacy TPS nodes via the Universal Control Network (UCN), the chassis itself is not a native Experion component. Consult your Honeywell system integrator for migration path options.
Q: Can I mix different I/O module types in the same chassis?
A: Yes. The 13-slot backplane supports mixed I/O configurations — analog, digital, and specialty modules can coexist in the same chassis, subject to power budget constraints of the installed power supply module.
Q: What is the maximum number of I/O points per chassis?
A: With 13 slots (minus 1 for the controller card and 1–2 for power modules), up to 10 I/O modules can be installed. Point count depends on module type — e.g., 10 × 32-channel digital modules = 320 I/O points per chassis.
Q: Do you supply the chassis with modules pre-installed?
A: We can supply the chassis standalone or as a configured kit with specified modules. Contact us with your BOM for a kit quotation.
Q: Is this a new or refurbished unit?
A: We supply both new-surplus (unused, original packaging) and professionally refurbished units. Condition is clearly stated on each order confirmation. All units pass functional inspection prior to shipment.
Q: What warranty is provided?
A: Konmask.com provides a 90-day warranty against defects in materials and workmanship on all shipped units. Extended warranty options are available for volume orders.
