Industrial Fan Construction Solution – KARL 52004-1.030 | Klein Fan Series
Where This Product Is Used
The KARL 52004-1.030 DNG 3-6/TS Klein Fan Construction module is deployed in demanding industrial environments where reliable forced-air cooling and ventilation control are critical to system uptime. Typical application sites include:
- Control cabinet thermal management – maintaining safe operating temperatures inside PLC and DCS enclosures
- Power electronics cooling – protecting drives, rectifiers, and inverter stacks in continuous-duty cycles
- Automated production lines – integrated fan assemblies in conveyor, press, and robotic cell control panels
- Process industry panels – oil & gas, chemical, and water-treatment SCADA enclosures requiring IEC-rated ventilation
- Machine tool control units – CNC and servo-drive cabinets with high heat-dissipation requirements
Technical Specifications
| Part Number | 52004-1.030 |
| Series | DNG 3-6/TS Klein Fan Construction |
| Compatible Assembly Refs | 0130-76142 · DIP180 · 0100-76142 · 0020-78718 · 0100-77040 |
| Manufacturer | KARL |
| Product Type | Fan Construction Module / Ventilation Assembly |
| Weight | 2,600 g (2.6 kg) |
| Mounting | Panel / DIN-rail compatible enclosure integration |
| Application | Industrial control cabinet forced-air cooling |
Why Engineers Specify This Model
- Exact OEM fit – drop-in replacement for KARL DNG 3-6/TS fan assemblies; no field modification required
- Multi-reference compatibility – single unit covers cross-references 0130-76142, DIP180, 0100-76142, 0020-78718, and 0100-77040, simplifying BOM consolidation
- Robust construction – engineered for continuous-duty industrial cycles with vibration-resistant housing
- Thermal reliability – consistent airflow performance prevents thermal shutdown events in critical control systems
- Reduced downtime – stocked as a ready-to-ship spare, minimising mean time to repair (MTTR) for production facilities
Complete System Bill of Materials
This fan construction module is commonly ordered alongside the following components to complete a full thermal management assembly:
- KARL 0130-76142 – Fan housing / filter frame
- KARL DIP180 / 0100-76142 – Fan motor insert
- KARL 0020-78718 – Mounting bracket / adapter plate
- KARL 0100-77040 – Wiring harness / connector set
Contact our team to source the complete assembly kit in a single order.
Compliance & Industry Standards
- Designed for integration in IEC 60529-rated enclosures
- Suitable for use in CE-marked control panel assemblies
- Compatible with UL 508A industrial control panel requirements (verify with your panel builder)
- RoHS-compliant materials (confirm with current KARL datasheet for your region)
Quality Assurance & Sourcing
Every KARL 52004-1.030 unit shipped from Konmask.com undergoes the following quality checks:
- Visual and dimensional inspection against OEM specifications
- Verified part number and label authenticity check
- Secure anti-static packaging for safe international transit
- Full traceability documentation available on request
We source directly from authorised distributors and verified industrial surplus channels to ensure genuine KARL components.
How to Source This Part
- Add the KARL 52004-1.030 to your cart and proceed to checkout
- For bulk orders (>5 units) or project BOM quotes, email support@konmask.com
- Lead time: typically 3–7 business days for in-stock units; contact us for expedited shipping options
- Export documentation (commercial invoice, packing list, COO) provided for international shipments
Application-Specific FAQ
Q: Is the KARL 52004-1.030 a direct replacement for part number 0100-76142?
A: Yes. The 52004-1.030 is the primary assembly that incorporates or supersedes the 0100-76142 fan motor insert. Verify with your KARL documentation for your specific cabinet revision.
Q: What enclosure sizes is the DNG 3-6/TS fan construction compatible with?
A: The DNG 3-6/TS series is designed for standard industrial control enclosures in the 3–6 unit (TS) form factor. Consult the KARL dimensional drawing for exact cutout dimensions.
Q: Can this fan module be used in hazardous area (ATEX/IECEx) installations?
A: The standard 52004-1.030 is not ATEX-rated. For hazardous area applications, contact us to discuss suitable alternatives.
Q: Do you offer warranty on this part?
A: Yes. Konmask.com provides a 90-day warranty against manufacturing defects on all KARL components. See our returns policy for details.
