Semiconductor & Precision Motion Solution — KOLLMORGEN 00-S0613-038 | ServoDisc Series
Where This Product Is Used
The KOLLMORGEN 00-S0613-038 ServoDisc motor is a direct-drive, ironless-rotor servo motor engineered for applications demanding zero cogging, ultra-low inertia, and exceptional torque linearity. It is widely deployed in:
- Semiconductor lithography equipment — ASML/SVG wafer-stage and reticle-stage positioning (cross-reference: SVG 859-0399-002)
- Wafer handling & inspection systems — precise θ-axis rotation in robotic end-effectors
- Laser beam steering & galvanometer assemblies — high-bandwidth mirror positioning
- Medical imaging & surgical robotics — smooth, backlash-free joint actuation
- PCB drilling & pick-and-place machines — high-cycle, low-vibration spindle drives
- Optical fiber alignment platforms — sub-micron positioning stages
Technical Specifications
| Manufacturer Part Number | 00-S0613-038 |
| Cross-Reference / OEM P/N | ASML / SVG 859-0399-002 |
| Series | ServoDisc (Pancake / Printed-Winding) |
| Motor Type | Ironless-rotor, direct-drive DC servo |
| Rotor Construction | Disc-wound printed armature — zero cogging |
| Weight | 1,090 g (2.40 lb) |
| Mounting | Flange-mount (confirm shaft/bolt pattern with datasheet) |
| Condition | Genuine OEM / Refurbished — tested before shipment |
Why Engineers Specify This Model
- Zero cogging torque — the ironless disc armature eliminates magnetic detent, enabling nanometer-level positioning repeatability
- Ultra-low rotor inertia — enables extremely high servo bandwidth, critical for fast-settling wafer stages
- Linear torque-current relationship — simplifies servo tuning and reduces thermal runaway risk
- Dual OEM qualification — validated by both KOLLMORGEN and ASML/SVG supply chains (P/N 859-0399-002)
- Compact pancake form factor — integrates into space-constrained tool architectures without gearboxes
- Long service life — brushed disc-winding design with replaceable brush sets reduces downtime vs. conventional wound motors
Complete System Bill of Materials
Engineers integrating this motor into a servo axis typically source the following complementary components — all available at Konmask.com:
- Servo amplifier / drive compatible with DC brush servo (e.g., Copley, AMC, or OEM drive)
- Encoder or resolver feedback module (check OEM stage assembly for existing feedback device)
- Motor cable assembly & connector kit (match to OEM harness P/N)
- Brush replacement kit for ServoDisc series
- Mounting hardware & shaft coupling
Compliance & Industry Standards
- Designed and manufactured to KOLLMORGEN internal quality standards
- Compatible with SEMI S2 / S8 equipment safety requirements when integrated per OEM guidelines
- RoHS compliance status: confirm with Konmask sales for specific lot
- Export classification: consult Konmask for EAR/ECCN determination prior to international shipment
Quality Assurance & Sourcing
Konmask sources KOLLMORGEN ServoDisc motors through authorized distribution channels and qualified secondary-market suppliers. Every unit undergoes:
- Visual inspection for mechanical damage, brush wear, and commutator condition
- Winding resistance and insulation resistance (IR) test
- No-load spin test to verify smooth rotation and absence of bearing noise
- Serialization and traceability documentation provided on request
How to Source This Part
- Add to cart and complete checkout — we ship globally from our warehouse
- Request a quote for volume orders (>3 units) or expedited delivery via support@konmask.com
- Lead time: in-stock units ship within 1–3 business days; sourced units 7–21 days
- Payment: T/T wire transfer, PayPal, credit card accepted
- Export documentation: commercial invoice, packing list, and COO certificate available
Application-Specific FAQ
Q: Is the 00-S0613-038 a direct drop-in replacement for SVG 859-0399-002?
A: Yes — the ASML/SVG P/N 859-0399-002 is the OEM procurement cross-reference for the KOLLMORGEN 00-S0613-038. Verify mounting and connector pinout against your specific tool revision before installation.
Q: What servo drive is compatible with this motor?
A: The ServoDisc is a DC brush servo motor. It is compatible with any brush-type servo amplifier sized to its voltage and current ratings. Contact Konmask for drive pairing recommendations.
Q: Can I get a test report or inspection certificate?
A: Yes. Konmask provides a pre-shipment inspection report upon request. Lot traceability documentation is available for qualified buyers.
Q: Do you offer a warranty?
A: All units carry a 90-day functional warranty against defects in materials and workmanship under normal operating conditions.
Q: What is the lead time for multiple units?
A: Contact us at support@konmask.com or call +0086 19859288691 for real-time stock and lead-time confirmation.
