Genuine KUKA KSD1-64 KCP2 Teach Pendant | KR C2/C4 Series – Verified Source
The KUKA KSD1-64 KCP2 Teach Pendant (cross-reference part numbers: 00-117-345 / 00-198-959 / 3080-AK / 00-130-547) is the original operator interface for KUKA KR C2 and KR C4 robot controller systems. Sourced directly through verified industrial channels, every unit sold by Konmask.com undergoes a documented multi-step inspection before dispatch — giving B2B buyers the confidence to integrate without delay.
Technical Specifications
- Part Numbers: KSD1-64 | 00-117-345 | 00-198-959 | 3080-AK | 00-130-547
- Brand: KUKA Robotics
- Series: KCP2 (KUKA Control Panel 2)
- Compatible Controllers: KR C2, KR C4
- Display: Color touchscreen with backlit keypad
- Interface: Ethernet / proprietary KCP bus
- Cable Length: Standard 10 m (custom lengths available on request)
- Weight: Approx. 800 g
- Operating Temperature: 0 °C – 45 °C
- Protection Class: IP 54
- Condition: New / Refurbished (specify at order)
Our 4-Step Quality Verification Process
- Step 1 – Source Authentication: All units are procured from authorized KUKA distributors or certified industrial surplus channels with traceable documentation.
- Step 2 – Visual & Physical Inspection: Housing, connectors, cable jacket, and keypad are inspected for damage, wear, or counterfeit indicators.
- Step 3 – Functional Power-On Test: Each pendant is powered on and communication with a compatible KR C controller is verified before packaging.
- Step 4 – Serialization & Documentation: Serial number, test result, and sourcing record are logged and shipped with the unit upon request.
Key Features & Benefits
- ✅ OEM-identical hardware — no firmware patching or workarounds required
- ✅ Plug-and-play replacement for failed or damaged KCP2 pendants
- ✅ Full KUKA WorkVisual and KUKA.OfficeLite compatibility
- ✅ Ergonomic grip with integrated enabling device (3-position safety switch)
- ✅ Emergency stop button meets EN ISO 13850 safety standard
- ✅ Reduces robot downtime — critical for high-throughput production lines
Typical Applications
- Automotive body-in-white welding and assembly lines
- Palletizing and material handling cells
- Arc welding and spot welding robot stations
- Machine tending and CNC load/unload automation
- Research & development robotics labs
- Replacement pendant for maintenance and spare-parts inventory
Compatible System Components
- KUKA KR C2 Controller Cabinet
- KUKA KR C4 Controller Cabinet
- KUKA KR AGILUS, KR QUANTEC, KR CYBERTECH series robots
- KUKA smartPAD (KCP4) — note: KCP2 and smartPAD are NOT interchangeable; confirm your controller generation before ordering
- KCP2 extension cables and adapter kits (available separately)
Global Sourcing & Shipping Capabilities
- Stock Location: China (Fujian) — with partner warehouses in EU and Southeast Asia
- Lead Time: In-stock units ship within 1–3 business days; sourced units 7–15 business days
- Shipping Methods: DHL Express, FedEx International Priority, sea freight for bulk orders
- Export Documentation: Commercial invoice, packing list, certificate of origin available; HS Code 8537.10 applicable
- Minimum Order: 1 unit (volume pricing available for 5+ units)
- Customs Support: Pre-shipment HS code declaration and ECCN classification assistance provided
Certifications & Compliance Statement
KUKA KSD1-64 KCP2 Teach Pendants supplied by Konmask.com are genuine OEM components. We do not sell counterfeit, cloned, or unauthorized replica parts. All units comply with applicable CE directives for machinery safety (2006/42/EC) and EMC (2014/30/EU) as originally certified by KUKA Robotics GmbH. Buyers are responsible for verifying compatibility with their specific robot cell configuration.
How to Order
- Confirm your KUKA controller model and generation (KR C2 vs KR C4).
- Verify the part number against your existing pendant label or KUKA documentation.
- Add to cart and select condition (New / Refurbished) at checkout, or contact us for a custom quote.
- For bulk orders (5+ units), email [email protected] for volume pricing and lead time confirmation.
- Provide your shipping address and preferred freight method — we handle the rest.
Authenticity & Trust FAQ
Q: How do I know this is a genuine KUKA part?
A: Every unit is sourced through documented industrial channels. We provide sourcing records and serial number logs upon request. We have zero tolerance for counterfeit components.
Q: Can I return the pendant if it’s incompatible?
A: Yes. We offer a 30-day compatibility return policy for unused units in original packaging. Contact [email protected] within 30 days of receipt.
Q: Do you offer a warranty?
A: New units carry a 12-month warranty against manufacturing defects. Refurbished units carry a 90-day functional warranty. Warranty claims are processed within 5 business days.
Q: Can you source other KUKA spare parts?
A: Yes. Konmask.com specializes in KUKA, Siemens, ABB, Fanuc, and Mitsubishi automation components. Contact us with your part number for a sourcing quote.
Q: What payment methods do you accept?
A: We accept T/T bank transfer, PayPal, and major credit cards. LC at sight available for orders above USD 10,000.
