Industrial Robot Motion Control Solution — KUKA KSP 600-3X20 | C4 XRC Series
Where This Product Is Used
The KUKA KSP 600-3X20 (Part No. UL00-198-266 / KSP600-340 / 00-198-268) is a servo power module designed for KUKA’s C4 XRC robot controller cabinet. It is deployed across demanding industrial environments where precise multi-axis motion control is critical:
- Automotive Body-in-White (BIW) Welding Lines — Powers 6-axis articulated robots in resistance and arc welding cells, maintaining sub-millimeter repeatability at high duty cycles.
- Robotic Assembly & Press-Fit Stations — Drives servo axes for force-controlled insertion tasks in engine, transmission, and electronics assembly.
- Material Handling & Palletizing — Supports high-payload KUKA KR series robots in logistics, warehousing, and end-of-line palletizing cells.
- Machine Tending & CNC Integration — Interfaces with CNC machining centers for automated part loading/unloading, reducing cycle time and operator exposure.
- Painting & Sealing Robots — Used in controlled-environment booths where consistent axis torque and speed regulation are mandatory.
- Collaborative & Hybrid Automation Cells — Integrated into mixed human-robot workspaces requiring safe, responsive servo response.
Technical Specifications
| Attribute | Detail |
|---|---|
| Manufacturer | KUKA Roboter GmbH |
| Part Number (Primary) | UL00-198-266 |
| Cross-Reference PN | KSP600-340 / 00-198-268 |
| Model Series | KSP 600-3X20 |
| Compatible Controller | KUKA C4 XRC Cabinet |
| Module Type | Servo Power Module (3-Axis, 20A per axis) |
| Rated Current | 3 × 20 A |
| Supply Voltage | DC Bus (from KPP power supply unit) |
| Axes Supported | 3 servo axes (expandable via additional KSP modules) |
| Communication Interface | KUKA proprietary backplane bus (C4 XRC) |
| Mounting | DIN rail / cabinet rack mount |
| Weight | 800 g (approx.) |
| Condition Available | New / Refurbished / Exchange |
Why Engineers Specify This Model
- 3-Axis Integrated Design — A single KSP 600-3X20 module drives three robot axes simultaneously, reducing cabinet footprint and wiring complexity versus discrete single-axis drives.
- 20 A Per-Axis Rating — Sufficient for mid-to-high payload KUKA KR robots (KR 60, KR 120, KR 150 series) operating at full rated torque.
- Plug-and-Play C4 XRC Compatibility — Designed exclusively for the KUKA C4 XRC architecture; firmware and parameterization are managed by the KRC4 controller automatically upon installation.
- Proven Field Reliability — Widely deployed in Tier-1 automotive plants globally; extensive installed base ensures availability of replacement units and engineering expertise.
- Multiple Part Number Cross-Reference — UL00-198-266, KSP600-340, and 00-198-268 all refer to the same module, simplifying procurement across different KUKA documentation revisions.
Complete System Bill of Materials
The KSP 600-3X20 operates within the KUKA C4 XRC controller ecosystem. A complete drive system typically includes:
- KPP 600-20 — KUKA Power Pack (DC bus power supply unit)
- KSP 600-3X20 (this module) — Servo power module, axes 1–3
- KSP 600-3X20 (second unit) — Servo power module, axes 4–6
- KRC4 Controller — Main robot controller with KUKA.WorkVisual software
- KUKA smartPAD — Teach pendant for programming and diagnostics
- Motor Power Cables — KUKA-rated shielded servo cables (robot-specific lengths)
- Resolver/Encoder Cables — Feedback cables for each axis motor
Contact us to source any of the above components as a complete kit.
Compliance & Industry Standards
- Designed and manufactured to ISO 9283 (Manipulating Industrial Robots — Performance Criteria)
- CE Marked — Compliant with EU Machinery Directive 2006/42/EC and Low Voltage Directive 2014/35/EU
- RoHS Compliant — Restriction of Hazardous Substances (EU Directive 2011/65/EU)
- Compatible with ISO 10218-1 safety requirements for industrial robots
- Suitable for use in environments meeting IEC 60204-1 (Safety of Machinery — Electrical Equipment)
Quality Assurance & Sourcing
At Konmask.com, every KUKA servo module undergoes a structured verification process before dispatch:
- ✅ Part Number Verification — Physical label cross-checked against UL00-198-266 / KSP600-340 / 00-198-268 documentation
- ✅ Visual & Mechanical Inspection — Connector pins, PCB, and housing inspected for damage or counterfeit indicators
- ✅ Functional Test (where applicable) — Refurbished units bench-tested on compatible C4 XRC test rigs
- ✅ Traceability Documentation — Serial number and batch records retained for warranty and audit purposes
- ✅ Secure Anti-Static Packaging — ESD-safe bags and foam-lined cartons for international freight
How to Source This Part
- Add to Cart — Select quantity and proceed to checkout for immediate stock items.
- Request a Quote — For bulk orders (>3 units), OEM pricing, or exchange programs, email [email protected].
- Urgent Requirement? — Call or WhatsApp +0086 19859288691 for same-day quotation and expedited shipping options.
- Exchange / Core Return Program — Send your faulty KSP 600-3X20 for credit toward a tested replacement unit.
Application-Specific FAQ
Q: Is UL00-198-266 the same as KSP600-340 and 00-198-268?
A: Yes. All three part numbers refer to the identical KUKA KSP 600-3X20 servo module. KUKA uses different PN formats across documentation generations; all are interchangeable for ordering purposes.
Q: Which KUKA robots is this module compatible with?
A: The KSP 600-3X20 is compatible with all KUKA robots using the C4 XRC controller cabinet, including KR 30, KR 60, KR 120, KR 150, KR 210, and KR 240 series (subject to axis current requirements).
Q: Can this module be used in a KRC2 or KRC3 controller?
A: No. The KSP 600-3X20 is designed exclusively for the C4 XRC (KRC4) architecture. It is not backward-compatible with KRC2 or KRC3 cabinets.
Q: What is the lead time for new units?
A: In-stock units ship within 1–3 business days. For out-of-stock or special configurations, typical lead time is 7–15 business days. Contact us for real-time availability.
Q: Do you offer a warranty?
A: Yes. New units carry a 12-month warranty. Refurbished/exchange units carry a 6-month warranty. All warranties cover manufacturing defects under normal operating conditions.
Q: Can you supply the full C4 XRC drive stack (KPP + dual KSP)?
A: Yes. We can source and supply complete drive sets. Contact us with your robot model and serial number for a matched kit quotation.
