Process Control & Industrial Automation Solution – Mitsubishi A616AD | MELSEC-A Series
Where This Product Is Used
The Mitsubishi A616AD is a 6-channel analog-to-digital (A/D) converter module designed for the MELSEC-A Series programmable logic controller platform. It is widely deployed across demanding industrial environments where precise analog signal acquisition is critical:
- Chemical & Petrochemical Plants — monitoring temperature, pressure, and flow sensors in continuous process loops
- Automotive Manufacturing — real-time feedback from torque sensors, load cells, and position transducers on assembly lines
- Power Generation & Utilities — acquiring 4–20 mA current loop signals from field instruments in SCADA-integrated substations
- Food & Beverage Processing — temperature and level monitoring in CIP (Clean-In-Place) and pasteurization systems
- Steel & Metal Processing — tension control and furnace temperature regulation in rolling mill automation
- Water Treatment Facilities — pH, turbidity, and dissolved oxygen sensor integration into PLC control loops
- Semiconductor Fabrication — precision analog data acquisition in cleanroom process equipment
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | A616AD |
| Series | MELSEC-A (AnS Series Compatible) |
| Manufacturer | Mitsubishi Electric |
| Module Type | Analog Input (A/D Converter) |
| Number of Channels | 6 Channels |
| Input Signal Range | Voltage: 0–5V, 1–5V, 0–10V, -10–+10V / Current: 4–20 mA |
| Resolution | 12-bit (0–4095) |
| Conversion Speed | Approx. 2.5 ms per channel (all 6 channels: ~15 ms) |
| Isolation | Photocoupler isolation between channels and CPU bus |
| Power Consumption | 5 VDC internal bus |
| Weight | 1,680 g |
| Compatible Base Units | A-Series main base / extension base units |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -20°C to 75°C |
| Humidity | 10–90% RH (non-condensing) |
Why Engineers Specify This Model
- 6-Channel Density — acquire six independent analog signals in a single module slot, reducing rack space and wiring complexity
- Flexible Input Modes — supports both voltage and current inputs per channel, eliminating the need for external signal converters
- 12-Bit Resolution — delivers 0.024% full-scale accuracy, sufficient for most industrial process control applications
- Photocoupler Isolation — protects the CPU backplane from ground loops and electrical noise common in industrial field wiring
- Proven MELSEC-A Ecosystem — direct plug-in compatibility with existing A-Series racks; no additional interface hardware required
- Long Service Life — Mitsubishi Electric’s industrial-grade components ensure reliable operation in 24/7 continuous production environments
- GX Developer / GX Works2 Support — fully configurable via standard Mitsubishi programming software with buffer memory mapping
Complete System Bill of Materials
For a complete MELSEC-A analog acquisition system, the following components are typically specified alongside the A616AD:
- CPU Module: A2USHCPU, A3UCPU, A2UCPU, A1SCPU
- Main Base Unit: A38B, A35B, A32B, A1S38B
- Power Supply Module: A61P, A62P, A63P, A1S61P
- Analog Output Module: A616DAI, A616DAV (for closed-loop control)
- Digital I/O Modules: AX40, AY40, AX80, AY80
- Programming Cable: SC-09, USB-SC09-FX
- Terminal Block: A6TBY36-E (for field wiring termination)
Contact support@konmask.com for complete system quotations.
Compliance & Industry Standards
- Manufactured under ISO 9001 certified quality management systems
- Compliant with IEC 61131-2 (Programmable Controllers — Equipment Requirements and Tests)
- CE Marked for European market conformity (EMC Directive & Low Voltage Directive)
- UL Listed for North American industrial control equipment applications
- Meets RoHS environmental compliance requirements
- Designed for use in Pollution Degree 2 industrial environments per IEC 60664-1
Quality Assurance & Sourcing
At Konmask.com, every A616AD module undergoes a rigorous 4-step verification process before shipment:
- Source Authentication — modules are procured exclusively from authorized Mitsubishi Electric distributors and verified OEM channels
- Physical Inspection — label verification, housing integrity check, and connector pin inspection against factory specifications
- Functional Power-On Test — each unit is powered and channel communication is verified prior to packaging
- Documentation Package — original datasheet, test report, and certificate of conformity included with every shipment
How to Source This Part
- Add to Cart — click the purchase button above to proceed directly to checkout
- Request a Quote — for bulk orders (5+ units) or system-level BOM quotations, email support@konmask.com
- Confirm Lead Time — in-stock units ship within 1–3 business days; ex-stock orders confirmed within 24 hours
- Global Shipping — DHL Express, FedEx International, and UPS Worldwide available to 150+ countries
- Export Documentation — commercial invoice, packing list, and certificate of origin provided for customs clearance
Application-Specific FAQ
Q: Can the A616AD be used with AnS-Series (compact) base units?
A: Yes. The A616AD is compatible with both standard A-Series and AnS-Series base units, making it suitable for both large and compact MELSEC-A system configurations.
Q: Can I mix voltage and current inputs on the same module?
A: Yes. Each of the 6 channels can be independently configured for either voltage or current input via the module’s parameter settings in GX Developer or GX Works2.
Q: What is the maximum cable length for analog field wiring?
A: Mitsubishi recommends shielded twisted-pair cable up to 200 m for current input (4–20 mA) and up to 30 m for voltage input to maintain signal integrity.
Q: Is the A616AD still in production?
A: The MELSEC-A Series has reached end-of-production. However, Konmask.com maintains stock of genuine A616AD modules to support legacy system maintenance and plant life extension projects.
Q: Do you provide a warranty?
A: Yes. All modules sold by Konmask.com carry a 12-month warranty against manufacturing defects. Replacement or full refund is provided for verified defective units.
Q: Can you supply the full MELSEC-A system?
A: Yes. Konmask.com stocks a broad range of MELSEC-A Series CPUs, base units, power supplies, I/O modules, and special function modules. Contact us for complete system sourcing.
