Mitsubishi MR-JE-70C AC Servo Amplifier 750W | Replacement, Equivalent & Selection Guide
The Mitsubishi Electric MR-JE-70C is a 750W single-axis AC servo amplifier from the MELSERVO-JE series, designed for general-purpose motion control applications. It accepts a 3-phase or single-phase 200–240 V AC input and communicates via SSCNET III/H (CC-Link IE Field Network compatible) for high-speed, noise-immune fiber-optic network control. This page provides full technical specifications, compatible replacement models, application guidance, and a structured selection guide to help engineers and procurement teams make the right choice.
Technical Specifications
- Model: MR-JE-70C
- Series: MELSERVO-JE (MR-JE Series)
- Rated Output: 750 W (0.75 kW)
- Power Supply: 3-phase / Single-phase 200–240 V AC, 50/60 Hz
- Rated Current: 5.0 A
- Control Mode: Position / Speed / Torque (switchable)
- Communication Interface: SSCNET III/H (fiber optic)
- Encoder Compatibility: 17-bit absolute encoder (131,072 pulses/rev)
- Regenerative Brake: Built-in (external resistor optional)
- Protection Degree: IP20
- Ambient Temperature: 0–55 °C (operating), -20–65 °C (storage)
- Weight: Approx. 1.38 kg
- Dimensions (W×H×D): 55 × 170 × 170 mm
- Compliance: CE, UL, RoHS
Compatible Replacement & Equivalent Models
The table below lists direct and functional equivalents for the MR-JE-70C. Always verify wiring, encoder type, and network protocol before substituting.
| Model | Brand | Power | Interface | Compatibility Note |
|---|---|---|---|---|
| MR-JE-70A | Mitsubishi | 750 W | Pulse train | Same power class; pulse interface only — no SSCNET |
| MR-J4-70B | Mitsubishi | 750 W | SSCNET III/H | Higher-spec upgrade; fully network compatible |
| MR-J5-70G | Mitsubishi | 750 W | CC-Link IE TSN | Next-gen replacement; requires iQ-R/iQ-F controller |
| SD700 / 0.75 kW | Schneider Electric | 750 W | EtherCAT / CANopen | Cross-brand alternative; different wiring & software |
| SGDV-7R6A01A | Yaskawa (Sigma-5) | 750 W | MECHATROLINK-III | Cross-brand; requires Yaskawa controller |
Contact [email protected] for cross-reference verification before ordering a replacement.
Why Choose the Original MR-JE-70C
- Proven reliability — field-tested in thousands of OEM and retrofit installations worldwide.
- Seamless Mitsubishi ecosystem integration — plug-and-play with iQ-F / iQ-R PLCs and GOT HMIs via SSCNET III/H.
- Advanced auto-tuning — one-touch tuning reduces commissioning time significantly.
- Compact footprint — 55 mm width saves panel space versus comparable drives.
- Genuine factory warranty — sourced through authorized channels at Konmask.com.
Typical Applications
- CNC machine tools (milling, turning, grinding)
- Packaging and labeling machinery
- Semiconductor and electronics assembly equipment
- Conveyor and material handling systems
- Printing and textile machinery
- Robotic arm joint control (auxiliary axes)
System Compatibility
- Compatible PLCs: Mitsubishi iQ-F (FX5U/FX5UC), iQ-R series via Motion CPU (e.g., R16MTCPU)
- Compatible HMIs: Mitsubishi GOT2000 series
- Compatible Servo Motors: HG-KN73J, HG-SN72J, HG-KN73BJ (750 W, 17-bit encoder)
- Programming Software: MR Configurator2 (SW1DNC-MRC2)
- Network: SSCNET III/H fiber optic — up to 16 axes per network
Selection Guide
Use the following criteria to confirm the MR-JE-70C is the right drive for your application:
- Step 1 — Power match: Confirm motor rated output is 750 W (0.75 kW). For 400 W → MR-JE-40C; for 1 kW → MR-JE-100C.
- Step 2 — Interface: Requires SSCNET III/H network controller. If using pulse-train input, select MR-JE-70A instead.
- Step 3 — Voltage: Confirm 200–240 V AC supply. For 400 V systems, the MR-JE series is not applicable — consider MR-J4 or MR-J5.
- Step 4 — Encoder: Verify motor uses 17-bit absolute encoder (HG-KN/SN series). Incompatible with older TS/HC motor encoders.
- Step 5 — Environment: IP20 rating — suitable for enclosed control panels. Not for open or wet environments.
Quality Assurance & Sourcing
All MR-JE-70C units sold through Konmask.com are:
- Sourced from authorized Mitsubishi Electric distributors or verified surplus channels
- Inspected for physical integrity, label authenticity, and firmware version prior to dispatch
- Shipped with original packaging where available
- Backed by our 30-day return policy and post-sale technical support
How to Order
- Click Add to Cart or Buy Now on this page.
- For bulk orders (5+ units) or urgent requirements, email [email protected] for a dedicated quote.
- Lead time: In-stock units ship within 1–3 business days. ETA provided for pre-order items.
- Export documentation (CO, packing list, commercial invoice) available on request.
Replacement & Compatibility FAQ
Q: Can I replace an MR-JE-70A with an MR-JE-70C?
A: Only if your controller supports SSCNET III/H. The MR-JE-70C does not accept pulse-train input.
Q: Is the MR-JE-70C compatible with older MR-J2S motors?
A: No. MR-JE series requires HG-KN/SN motors with 17-bit encoders. MR-J2S motors use incompatible encoder protocols.
Q: Can I use the MR-JE-70C as a standalone drive without a Mitsubishi PLC?
A: Limited functionality only. Speed/torque analog mode is available, but full positioning requires SSCNET III/H network control.
Q: What is the difference between MR-JE-70C and MR-J4-70B?
A: Both use SSCNET III/H, but the MR-J4-70B supports advanced vibration suppression, higher encoder resolution (22-bit), and more control modes. The MR-JE-70C is the cost-optimized entry-level option.
Q: Do you provide a warranty?
A: Yes — 30-day return guarantee. Extended warranty options available; contact us for details.
