MKS 627D01TDC1B Capacitance Manometer Pressure Transducer – Baratron 627D Series
When a critical vacuum process loses pressure measurement accuracy, the consequences cascade instantly — deposition rates drift, etch uniformity collapses, and entire wafer batches are scrapped. In semiconductor fabs, chemical vapor deposition (CVD) chambers, and high-purity gas delivery systems, the pressure transducer is not a peripheral sensor; it is the heartbeat of process control. Without a reliable, thermally stable, and contamination-resistant measurement device, operators are flying blind in environments where a 1 mTorr deviation can mean the difference between a functional chip and a costly reject.
The MKS 627D01TDC1B is a precision capacitance manometer from MKS Instruments’ industry-defining Baratron® 627D Series — a product line that has set the global benchmark for vacuum pressure measurement for decades. This specific model is engineered for full-scale ranges and temperature-controlled operation, delivering the absolute accuracy and long-term stability demanded by the world’s most advanced semiconductor OEMs, research institutions, and industrial vacuum system integrators. As a gas-type independent sensor, it measures true pressure regardless of the process gas composition, making it indispensable in multi-gas process environments.
Technical Specifications
- Model / SKU: 627D01TDC1B
- Manufacturer: MKS Instruments (Baratron®)
- Series: Baratron 627D
- Sensor Type: Capacitance Manometer (Gas-Type Independent)
- Measurement Principle: Capacitive diaphragm deflection
- Output Signal: Analog (0–10 VDC)
- Temperature Control: Heated sensor head (45°C or 100°C depending on configuration)
- Wetted Materials: Inconel® diaphragm, 316L stainless steel body
- Process Connection: VCR® / ConFlat® compatible (per configuration)
- Operating Temperature: 0°C to 50°C (ambient)
- Weight: Approx. 1,880 g
- Condition: New / Refurbished / Tested — available upon inquiry
Note: Full datasheet specifications are available upon request. Do not rely solely on listed parameters for critical process design — always verify with the official MKS datasheet for your specific configuration suffix.
Key Features & Benefits
- Gas-Type Independent Measurement: Capacitance manometer technology measures absolute pressure regardless of gas species — no correction factors needed for N₂, Ar, O₂, HF, or exotic process gases.
- Thermally Stabilized Sensor Head: The 627D’s heated sensor design eliminates condensation and thermal drift, ensuring measurement integrity in reactive and corrosive gas environments.
- High Accuracy & Repeatability: Delivers ±0.5% of reading accuracy (full scale), meeting the stringent requirements of semiconductor process control and R&D applications.
- Inconel® Diaphragm: Superior corrosion resistance against aggressive process chemistries including halogen-based etch gases and acid vapors.
- Wide Dynamic Range: Capable of measuring from atmosphere down to high-vacuum ranges, adaptable across multiple process steps.
- Direct OEM Replacement: Drop-in compatible with existing MKS Baratron 627D installations — minimizes downtime during maintenance or upgrade cycles.
- Long Service Life: Robust construction and MKS’s proven diaphragm technology ensure extended MTBF in continuous 24/7 production environments.
Industry & Equipment Applications
- Semiconductor Manufacturing: CVD, PVD, ALD, dry etch, and ion implant chambers requiring precise vacuum pressure control.
- Flat Panel Display (FPD) Production: Large-area deposition systems where uniform pressure is critical to panel quality.
- Solar Cell Fabrication: PECVD and sputtering systems for thin-film photovoltaic production.
- Pharmaceutical & Biotech: Freeze-drying (lyophilization) and sterile vacuum processing requiring traceable pressure measurement.
- Research & Development: University labs, national laboratories, and industrial R&D centers using high-vacuum experimental setups.
- Industrial Vacuum Systems: Heat treatment furnaces, vacuum coating, and leak detection systems.
System Integration & Compatible Parts
The MKS 627D01TDC1B is designed for seamless integration within MKS Instruments’ broader process control ecosystem. Compatible and commonly paired components include:
- MKS PDR900 / PR4000B: Power supply and readout units for Baratron transducers.
- MKS 248A / 248B: Control valves for pressure-controlled process loops.
- MKS 600 Series: Mass flow controllers for upstream gas delivery integration.
- MKS 670 Signal Conditioner: For multi-channel pressure monitoring configurations.
- VCR® Fittings & ConFlat® Flanges: Standard ultra-high vacuum (UHV) compatible connections.
Contact our technical team at support@konmask.com for system integration consultation and compatible spare parts sourcing.
