Gas Process Flow Control Solution — PORTER LB-366 NVL-003F | Thermal Mass Flow Controller Series
Where This Product Is Used
The PORTER LB-366 NVL-003F thermal mass flow controller (MFC) is engineered for precision gas flow regulation in demanding industrial and high-tech environments. Typical deployment scenarios include:
- Semiconductor Fabrication: CVD, PVD, and etch process chambers requiring stable, repeatable gas delivery (SiH₄, N₂, Ar, O₂, HCl, and specialty gases).
- Chemical Vapor Deposition (CVD): Precise precursor gas metering for thin-film deposition uniformity and yield control.
- Analytical Instrumentation: Carrier and calibration gas control in GC, mass spectrometry, and emissions analyzers.
- Industrial Gas Blending: Multi-component gas mixing skids for specialty gas production and quality assurance.
- R&D Laboratories: Bench-scale reaction studies, catalyst testing, and combustion research requiring traceable flow accuracy.
- Fuel Cell & Hydrogen Systems: Hydrogen and reformate gas metering in fuel cell test stands and electrolyzer rigs.
Technical Specifications
| Manufacturer | PORTER Instrument (Parker Hannifin) |
| Model / SKU | LB-366 NVL-003F |
| Series | LB-366 Thermal Mass Flow Controller |
| Operating Principle | Thermal (capillary bypass) mass flow sensing |
| Control Valve Type | Normally Closed (NVL = normally closed valve) |
| Full Scale Range | Refer to calibration certificate / order documentation |
| Accuracy | ±1% F.S. (typical) |
| Repeatability | ±0.2% F.S. |
| Signal Interface | Analog 0–5 VDC / 4–20 mA (model dependent) |
| Wetted Materials | 316L SS body, Viton / EPDM seals (confirm for corrosive gas service) |
| Operating Pressure | Up to 100 psig inlet (typical) |
| Operating Temperature | 0–50 °C ambient |
| Power Supply | ±15 VDC or 24 VDC (model dependent) |
| Weight | 1,360 g (as listed) |
| Country of Origin | USA |
Note: Always verify full specifications against the original PORTER datasheet and calibration certificate supplied with the unit.
Why Engineers Specify This Model
- Proven Thermal Sensing Architecture: PORTER’s capillary-bypass thermal sensing delivers stable, drift-resistant measurement across a wide range of process gases.
- Normally Closed Fail-Safe Valve (NVL): The NVL suffix confirms a normally closed valve — critical for safety-critical gas systems where loss of power must default to flow shutoff.
- Drop-In Compatibility: LB-366 series units conform to industry-standard footprint and connector pinouts, simplifying replacement in existing tool sets without re-engineering gas panels.
- Long Service Life: Robust stainless steel construction and PORTER’s quality manufacturing heritage support multi-year service intervals in continuous-process environments.
- Broad Gas Compatibility: Suitable for inert, reactive, and mildly corrosive gases when appropriate wetted materials are selected.
Complete System Bill of Materials
For a fully functional gas delivery sub-system using the LB-366 NVL-003F, engineers typically specify:
- PORTER LB-366 NVL-003F Mass Flow Controller (this unit)
- MFC mounting bracket / gas stick manifold block
- Upstream pressure regulator (line pressure ≤ rated inlet)
- Upstream particulate filter / purifier (0.003 µm recommended for semiconductor service)
- D-sub or equivalent signal cable harness (0–5 V or 4–20 mA)
- ±15 VDC or 24 VDC regulated power supply
- Downstream isolation valve (manual or pneumatic)
- MFC readout / controller (PLC analog I/O card or dedicated MFC controller)
Contact support@konmask.com for BOM assistance and compatible accessory sourcing.
Compliance & Industry Standards
- Designed and manufactured in accordance with SEMI F-series guidelines for semiconductor gas delivery components.
- Calibrated against NIST-traceable flow standards.
- Wetted materials and valve design compatible with SEMI S2 environmental, health, and safety requirements (verify per gas service).
- CE marking applicability — confirm with PORTER documentation for your specific configuration.
Quality Assurance & Sourcing
Konmask.com sources industrial automation components through verified supply channels. Each unit offered is:
- Inspected for physical integrity and completeness prior to listing.
- Stored in ESD-safe, climate-controlled conditions.
- Shipped with original manufacturer documentation where available.
- Traceable to original manufacturer lot/serial records upon request.
We do not sell counterfeit, refurbished-as-new, or unverified grey-market parts. All listings reflect actual available stock or confirmed lead-time sourcing.
How to Source This Part
- Add to Cart directly on this page for immediate purchase.
- Request a Quote (RFQ): Email support@konmask.com with your required quantity, delivery timeline, and any calibration gas/range requirements.
- Bulk / OEM Orders: Contact us for volume pricing on 5+ units or standing blanket orders.
- Expedite Requests: Call or WhatsApp +0086 19859288691 for urgent same-day quotation.
Application-Specific FAQ
Q: What does “NVL” mean in the PORTER part number?
A: NVL designates a Normally Closed Valve. When de-energized (power off), the control valve closes, stopping gas flow. This is the preferred fail-safe configuration for most semiconductor and hazardous gas applications.
Q: Can this MFC control corrosive gases such as HCl or Cl₂?
A: The standard LB-366 uses 316L SS wetted surfaces with Viton seals. For aggressive corrosive gases, confirm wetted material compatibility and consider PORTER’s corrosive-service variants. Contact us for application review.
Q: Is recalibration required after long storage?
A: PORTER recommends recalibration after extended storage (>12 months) or if the unit has been exposed to contamination. Konmask can advise on local calibration service providers.
Q: What signal interface does the LB-366 NVL-003F use?
A: The standard interface is 0–5 VDC analog (setpoint and readback). Some configurations support 4–20 mA or RS-232/RS-485 digital. Confirm your specific unit’s interface from the label or calibration certificate.
Q: Can I replace an existing PORTER MFC with this unit without modifying my gas panel?
A: Yes — the LB-366 series uses a standard industry footprint. Verify port size, flow range, and connector pinout match your existing installation before swapping.
