Genuine Prosoft MVI56-MCMR Enhanced Modbus Master/Slave | ControlLogix Series – Verified Source
The Prosoft MVI56-MCMR is a high-performance Modbus Master/Slave communication module designed for the Allen-Bradley ControlLogix backplane. Sourced directly through verified industrial distribution channels, every unit sold by Konmask.com undergoes our rigorous 4-step quality verification process before shipment. Whether you are replacing a failed module or expanding your control network, you can order with confidence.
Technical Specifications
- Part Number: MVI56-MCMR
- Manufacturer: Prosoft Technology
- Platform: Allen-Bradley ControlLogix (1756 backplane)
- Protocol: Modbus RTU / ASCII – Master & Slave (simultaneous)
- Serial Ports: 2 × RS-232 / RS-422 / RS-485 configurable
- Baud Rate: 110 bps – 115.2 kbps
- Data Table Size: Up to 5,000 registers (read/write)
- Backplane Current Draw: 800 mA @ 5 VDC
- Operating Temperature: 0 °C to 60 °C (32 °F to 140 °F)
- Storage Temperature: -40 °C to 85 °C
- Humidity: 5 % to 95 % non-condensing
- Dimensions (H × W × D): 94 mm × 45 mm × 94 mm (standard 1756 module)
- Weight: Approx. 400 g
- Agency Approvals: UL, CE, cUL
- Firmware: Field-upgradeable via ProSoft Configuration Builder (PCB)
Our 4-Step Quality Verification Process
Every MVI56-MCMR unit shipped from Konmask.com passes the following checks before it leaves our facility:
- Step 1 – Source Authentication: We verify the supply chain documentation, including manufacturer certificates of conformance and distributor invoices, to confirm genuine Prosoft origin.
- Step 2 – Physical Inspection: Trained technicians inspect label integrity, PCB markings, connector condition, and housing for any signs of refurbishment, counterfeiting, or damage.
- Step 3 – Functional Bench Test: Each module is powered up and tested for backplane communication, serial port continuity, and firmware version confirmation using ProSoft Configuration Builder.
- Step 4 – Packaging & Documentation Audit: Units are repackaged with anti-static protection, and all accompanying documentation (datasheet, quick-start guide, test report) is included before dispatch.
Key Features & Benefits
- Simultaneous Modbus Master and Slave operation on two independent serial ports — eliminates the need for separate gateway hardware
- Supports up to 250 Modbus slave devices per port for large-scale SCADA and DCS integration
- Seamless ControlLogix backplane integration — data mapped directly to controller tags via standard ladder logic Add-On Instructions (AOI)
- Configurable via free ProSoft Configuration Builder software — no proprietary hardware programmer required
- Diagnostic LEDs and built-in event log for rapid fault isolation and reduced downtime
- Field-upgradeable firmware ensures long-term compatibility with evolving network standards
- Compact 1-slot ControlLogix form factor — maximises chassis space in dense control panels
Typical Applications
- Oil & gas wellhead and pipeline SCADA systems
- Water and wastewater treatment plant automation
- Power generation and substation control
- Building management systems (BMS) integrating legacy Modbus field devices
- Manufacturing lines requiring Modbus RTU/ASCII communication with drives, meters, and sensors
- Mining and minerals processing control networks
Compatible System Components
- Chassis: Allen-Bradley 1756-A4, 1756-A7, 1756-A10, 1756-A13, 1756-A17
- Power Supplies: 1756-PA72, 1756-PB72, 1756-PA75, 1756-PB75
- Controllers: 1756-L61, 1756-L62, 1756-L63, 1756-L64, 1756-L65, 1756-L71, 1756-L72, 1756-L73, 1756-L74, 1756-L75 (and later ControlLogix 5580 series)
- Configuration Software: ProSoft Configuration Builder (PCB) v4.x or later — free download from Prosoft Technology
- Programming Software: Rockwell Automation Studio 5000 Logix Designer v21 or later
Global Sourcing & Shipping Capabilities
Konmask.com maintains established procurement relationships with authorised Prosoft distributors across Asia-Pacific, Europe, and North America. We ship worldwide via DHL Express, FedEx International Priority, and UPS Worldwide Expedited.
- Lead Time: In-stock units typically ship within 1–2 business days of payment confirmation
- Export Compliance: All shipments are screened against applicable export control regulations (EAR/ECCN); end-user declarations provided upon request
- Customs Documentation: Commercial invoice, packing list, and certificate of origin provided as standard
- Packaging: Anti-static bag, foam-lined carton, and moisture-barrier outer packaging for safe international transit
- Insurance: Full declared-value cargo insurance available on request
Certifications & Compliance Statement
The Prosoft MVI56-MCMR carries the following agency approvals as issued by the original manufacturer:
- UL Listed (Underwriters Laboratories)
- CE Marked (European Conformity — EMC Directive 2014/30/EU, Low Voltage Directive 2014/35/EU)
- cUL Listed (Canadian Standards)
- RoHS Compliant
Konmask.com does not modify, repair, or alter any hardware or firmware. All units are sold in their original manufacturer configuration. Copies of manufacturer certificates of conformance are available upon written request.
How to Order
- Step 1: Confirm your ControlLogix chassis slot availability and firmware revision requirements with your controls engineer.
- Step 2: Add the MVI56-MCMR to your cart and proceed to checkout, or contact us directly for volume pricing and lead-time confirmation.
- Step 3: Submit your purchase order (PO) or pay via our secure online checkout. We accept T/T bank transfer, credit card, and PayPal for international orders.
- Step 4: Receive your tracking number within 1 business day of shipment. Our team is available to assist with customs clearance documentation.
For urgent requirements or quantity orders (>5 units), please contact us directly at support@konmask.com or call +0086 19859288691 for a dedicated quote within 4 business hours.
Authenticity & Trust FAQ
Q: How do I know the module is genuine Prosoft and not a counterfeit?
A: Every unit passes our 4-step verification process (see above). We provide source documentation and a test report with each shipment. If you have any doubt after receipt, we offer a full return within 30 days.
Q: Is this a new, used, or refurbished unit?
A: Unless explicitly stated otherwise in the product listing, all units are new-in-box (NIB) sourced from authorised distribution. Surplus or tested-used units are clearly labelled as such.
Q: Do you offer a warranty?
A: Yes. We provide a 12-month warranty against manufacturing defects. Warranty claims are handled directly by Konmask.com — you do not need to contact Prosoft Technology separately.
Q: Can you provide an official Prosoft datasheet or manual?
A: Yes. The official MVI56-MCMR User Manual and datasheet are available for download from the Prosoft Technology website. We can also email copies upon request.
Q: What if the module does not work in my system?
A: Contact our technical support team at support@konmask.com. We will assist with configuration troubleshooting before initiating any return process.
