PROSOFT PLX82-EIP-PNC EtherNet/IP to PROFINET Controller Gateway | Replacement, Equivalent & Selection Guide
The ProSoft Technology PLX82-EIP-PNC is an industrial protocol gateway that bridges EtherNet/IP (Allen-Bradley / Rockwell Automation) networks with PROFINET (Siemens / IEC 61158) networks. Acting as an EtherNet/IP adapter and PROFINET controller simultaneously, it enables seamless data exchange between PLCs and devices from different automation ecosystems — without custom programming or middleware.
Technical Specifications
| Part Number | PLX82-EIP-PNC |
| Manufacturer | ProSoft Technology |
| Series | PLX82 Protocol Gateway Series |
| Function | EtherNet/IP Adapter ↔ PROFINET Controller |
| EtherNet/IP Port | 1 × RJ45, 10/100 Mbps |
| PROFINET Port | 2 × RJ45 (integrated switch), 10/100 Mbps |
| Max EIP Connections | Up to 100 Class 1 I/O connections |
| Max PROFINET Devices | Up to 64 PROFINET IO devices |
| Data Exchange | Up to 500 bytes input / 500 bytes output per connection |
| Power Supply | 24 VDC (±10%), 200 mA typical |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Mounting | DIN rail |
| Dimensions (W×H×D) | Approx. 45 × 100 × 120 mm |
| Weight | 630 g |
| Certifications | CE, UL, cUL, RoHS |
| Configuration Tool | ProSoft Configuration Builder (PCB), free download |
| Firmware Update | Via Ethernet (TFTP) |
Compatible Replacement & Equivalent Models
If the PLX82-EIP-PNC is unavailable or you are evaluating alternatives, the following models offer similar EtherNet/IP ↔ PROFINET bridging functionality:
| Model | Manufacturer | Key Difference |
|---|---|---|
| PLX82-EIP-PNC (this unit) | ProSoft Technology | Reference model — PROFINET Controller role |
| PLX82-EIP-PND | ProSoft Technology | PROFINET Device role (not controller) |
| PLX31-EIP-PNC | ProSoft Technology | Rack-mount version for ControlLogix/CompactLogix |
| HMS Anybus X-gateway AB7651 | HMS Networks | EtherNet/IP Scanner ↔ PROFINET IO Device |
| HMS Anybus X-gateway AB7652 | HMS Networks | EtherNet/IP Adapter ↔ PROFINET IO Controller |
| Moxa MGate 5105-MB-EIP | Moxa | Modbus/EIP to PROFINET (different protocol scope) |
| Hilscher netTAP NT 100-RE-EN | Hilscher | Multi-protocol gateway, configurable roles |
| Turck TBEN-S2-2EIP-2PN | Turck | IP67 field-mount, EtherNet/IP ↔ PROFINET |
Note: Always verify firmware version, I/O data size, and role (controller vs. device) before substituting. Contact [email protected] for compatibility confirmation.
Why Choose the Original PLX82-EIP-PNC
- Proven interoperability — certified for Rockwell Automation EtherNet/IP and Siemens PROFINET ecosystems
- PROFINET Controller role — actively manages PROFINET IO devices, unlike passive device-role gateways
- No PLC programming required — data mapping configured entirely in ProSoft Configuration Builder
- High I/O capacity — up to 64 PROFINET devices and 100 EtherNet/IP connections simultaneously
- Compact DIN-rail form factor — fits standard control cabinets without rack modification
- Free configuration software — PCB tool with built-in diagnostics and live data monitoring
- Global certifications — CE, UL, cUL, RoHS compliant for international deployments
Typical Applications
- Connecting Allen-Bradley ControlLogix / CompactLogix PLCs to Siemens PROFINET field devices (drives, I/O, sensors)
- Integrating legacy Siemens PROFINET infrastructure into new Rockwell EtherNet/IP architectures
- Automotive assembly line cross-vendor automation
- Food & beverage processing with mixed PLC environments
- Oil & gas and water treatment facilities requiring multi-vendor protocol bridging
- Machine builder OEM panels shipped to customers with different PLC standards
System Compatibility
| Side | Compatible Systems |
|---|---|
| EtherNet/IP (Adapter) | Rockwell ControlLogix, CompactLogix, MicroLogix 1100/1400, Studio 5000, RSLogix 5000 |
| PROFINET (Controller) | Siemens S7-300/400/1200/1500, TIA Portal, Step 7; any PROFINET IO Device (drives, remote I/O, sensors) |
| Configuration PC | Windows 7/10/11 with ProSoft Configuration Builder (PCB) v4.x+ |
Selection Guide
Use this guide to confirm the PLX82-EIP-PNC is the right model for your application:
| Requirement | PLX82-EIP-PNC | PLX82-EIP-PND | PLX31-EIP-PNC |
|---|---|---|---|
| Standalone DIN-rail mount | ✅ | ✅ | ❌ (rack-mount) |
| PROFINET Controller role | ✅ | ❌ | ✅ |
| PROFINET Device role | ❌ | ✅ | ❌ |
| EtherNet/IP Adapter role | ✅ | ✅ | ✅ |
| No ControlLogix rack needed | ✅ | ✅ | ❌ |
| Up to 64 PROFINET IO devices | ✅ | N/A | ✅ |
Key decision point: Choose PLX82-EIP-PNC when your gateway must control PROFINET IO devices. Choose PLX82-EIP-PND when the gateway acts as a PROFINET slave/device.
Quality Assurance & Sourcing
- Genuine parts — all units sourced from authorized distributors or factory-direct channels
- Pre-shipment inspection — each unit tested for power-on, port link, and firmware integrity
- Warranty — 12-month warranty against manufacturing defects
- Traceability — serial number and batch records maintained for every shipment
- Export compliance — ECCN classification and customs documentation available on request
How to Order
- Confirm part number: PLX82-EIP-PNC
- Specify quantity and required delivery timeline
- Contact us via email or phone for a formal quotation
- Provide shipping address and preferred freight method (DHL / FedEx / sea freight)
- Payment: T/T bank transfer or as agreed
📧 [email protected] | 📞 +0086 19859288691
Replacement & Compatibility FAQ
Q: Can the PLX82-EIP-PNC replace a PLX31-EIP-PNC?
A: Functionally yes — both bridge EtherNet/IP to PROFINET as a controller. The PLX82 is standalone DIN-rail; the PLX31 requires a ControlLogix/CompactLogix rack slot. Confirm your installation space before substituting.
Q: Is the PLX82-EIP-PNC compatible with Siemens S7-1500?
A: Yes. It supports standard PROFINET IO protocol compatible with S7-1200 and S7-1500 via TIA Portal GSDML import.
Q: Can it replace an HMS Anybus AB7652?
A: Both perform EtherNet/IP Adapter ↔ PROFINET Controller bridging. Configuration tools and GSDML files differ. Verify I/O data size limits and connection counts for your specific application.
Q: What firmware version is current?
A: Please contact us or visit ProSoft Technology’s official site for the latest firmware. We ship units with the most current stable firmware available at time of order.
Q: Do you provide the GSDML file?
A: Yes. The GSDML file for TIA Portal / Step 7 integration is included with the unit and available for download upon request.
