Rexroth CLM01.4-N-E-2-B-FW FWA-CLM1.4-LA1-01V06-MS Axis Positioning Control Module | Replacement, Equivalent & Selection Guide
The Bosch Rexroth CLM01.4-N-E-2-B-FW paired with firmware FWA-CLM1.4-LA1-01V06-MS is a high-performance single-axis positioning control module from the Rexroth CLM (Compact Logic Module) series. Designed for precise motion control in industrial automation systems, it integrates seamlessly with Rexroth SERCOS and analog drive platforms. Konmask.com supplies this module new, tested, and ready for deployment.
Technical Specifications
- Part Number: CLM01.4-N-E-2-B-FW
- Firmware: FWA-CLM1.4-LA1-01V06-MS
- Series: CLM (Compact Logic Module) — Generation 1.4
- Manufacturer: Bosch Rexroth AG
- Function: Single-axis positioning and motion control
- Interface: SERCOS II / Analog encoder interface
- Communication: PROFIBUS-DP, RS-232/RS-485 optional
- Power Supply: 24 VDC
- Firmware Version: LA1-01V06 (MS = MultiSingle axis)
- Mounting: DIN rail / panel mount
- Operating Temperature: 0 °C to +55 °C
- Weight: Approx. 300 g
- Compliance: CE, UL
Compatible Replacement & Equivalent Models
If the CLM01.4-N-E-2-B-FW is unavailable or discontinued, the following models offer functional equivalence or direct replacement capability:
- CLM01.3-N-E-2-B-FW — Previous generation CLM, same axis count, firmware-compatible with adaptation
- CLM01.4-N-E-1-B-FW — Single-axis variant with reduced I/O; suitable for simpler positioning tasks
- CLM01.4-N-E-4-B-FW — Expanded 4-axis version for multi-axis upgrade paths
- Rexroth CSH01.1C / CDB01.1C — Drive-integrated positioning for compact machine designs
- Siemens SIMOTION D410 — Cross-brand alternative for PROFIBUS-based motion systems
- Mitsubishi MR-J4 + QD75MH — Alternative for servo + positioning controller architectures
Contact Konmask.com for cross-reference verification before substitution.
Why Choose the Original Model
- ✅ Proven field reliability in Rexroth SERCOS-based machine tools and transfer lines
- ✅ Firmware FWA-CLM1.4-LA1-01V06-MS pre-loaded — no additional programming hardware required
- ✅ Drop-in replacement for existing CLM1.4 installations without re-engineering
- ✅ Full Rexroth ecosystem compatibility — works with HCS, HMD, and MDD drive families
- ✅ Stable long-term supply via Konmask.com authorized sourcing channels
Typical Applications
- CNC machine tool axis positioning (milling, turning, grinding)
- Automated assembly line servo coordination
- Packaging machinery with multi-step positioning sequences
- Printing and converting machine web tension control
- Injection molding machine clamp and ejector axis control
- Robotics and gantry systems requiring deterministic motion
System Compatibility
- Drive Systems: Rexroth HCS01, HCS02, HMD01, DKC series
- Motors: Rexroth MDD, MKD, MSK servo motor families
- PLC/Controller: Rexroth IndraControl L/V, Siemens S7-300/400 via PROFIBUS
- Engineering Software: Rexroth IndraWorks, WinStudio, DriveTop
- Firmware Compatibility: FWA-CLM1.4-LA1-01V06-MS (included); upgradeable via Rexroth service tool
Selection Guide
| Requirement | Recommended Model |
|---|---|
| Single-axis, SERCOS II, standard I/O | CLM01.4-N-E-2-B-FW ✅ (this model) |
| Single-axis, analog only, cost-sensitive | CLM01.4-N-E-1-B-FW |
| Multi-axis (up to 4), same platform | CLM01.4-N-E-4-B-FW |
| Drive-integrated positioning, compact | Rexroth CSH01.1C |
| Cross-brand PROFIBUS motion control | Siemens SIMOTION D410 |
Key selection parameters: number of controlled axes, fieldbus protocol (SERCOS vs. PROFIBUS vs. EtherCAT), encoder type (incremental/absolute), and firmware version compatibility with existing machine software.
Quality Assurance & Sourcing
- 🔍 Source: New original or factory-refurbished with full traceability
- 🔍 Testing: Function-tested prior to shipment; firmware version verified
- 🔍 Packaging: Anti-static ESD packaging with moisture barrier
- 🔍 Warranty: 12-month warranty against manufacturing defects
- 🔍 Certification: CE marked; RoHS compliant
- 🔍 Lead Time: In-stock items ship within 1–3 business days; contact us for bulk orders
How to Order
- Confirm your part number: CLM01.4-N-E-2-B-FW + firmware FWA-CLM1.4-LA1-01V06-MS
- Verify quantity and delivery timeline with our team
- Add to cart or contact [email protected] for a formal quotation
- Provide your shipping address and preferred freight method (DHL / FedEx / sea freight)
- Payment via T/T bank transfer, PayPal, or credit card
Replacement & Compatibility FAQ
Q: Can CLM01.3 firmware run on CLM01.4 hardware?
A: No. Hardware generation 1.3 and 1.4 use different firmware branches. Always match firmware to hardware revision.
Q: Is FWA-CLM1.4-LA1-01V06-MS the latest firmware version?
A: V06 is a stable production release. Newer versions may exist — contact Rexroth service or Konmask.com for the latest available firmware for your application.
Q: Can this module replace a CLM01.4-N-E-2-B-FW without firmware?
A: The firmware (FWA-CLM1.4-LA1-01V06-MS) is a separate orderable item. This listing includes both hardware and firmware as a bundle. Confirm with us if you need hardware only.
Q: What is the difference between -FW and non-FW suffix?
A: The -FW suffix indicates the module is supplied with firmware pre-installed. Non-FW variants require separate firmware ordering and loading.
Q: Do you ship internationally?
A: Yes. Konmask.com ships worldwide via DHL, FedEx, and sea freight. Export documentation and customs support available.
