Bosch Rexroth HCS02.1E-W0028-A-03-NNNN – HCS Compact Drive Controller | IndraDrive Platform
Engineering Background
The HCS02.1E-W0028-A-03-NNNN is a high-performance compact converter and drive controller from Bosch Rexroth’s IndraDrive HCS series. Engineered for precision motion control in demanding industrial environments, this unit delivers 28 A continuous output current within a single-axis compact architecture. It integrates seamlessly into Rexroth IndraDrive system topologies, supporting both standalone and multi-axis configurations via SERCOS III or PROFIBUS DP communication backbones.
Product Positioning
Targeting procurement engineers and system integrators in machine tool, packaging, printing, and semiconductor manufacturing sectors, the HCS02.1E-W0028-A-03-NNNN represents Rexroth’s commitment to compact form factor without compromising drive performance. Its modular design reduces panel space requirements while maintaining full IndraDrive firmware and parameter compatibility across the HCS product family.
Complete Technical Specifications
| Parameter | Value |
|---|---|
| Part Number / SKU | HCS02.1E-W0028-A-03-NNNN |
| Manufacturer | Bosch Rexroth AG |
| Series | IndraDrive HCS02 |
| Device Type | HCS Compact Converter / Drive Controller |
| Continuous Output Current | 28 A |
| Supply Voltage | 3 × AC 200–480 V, ±10% |
| Supply Frequency | 50 / 60 Hz |
| DC Bus Voltage | 750 V DC (nominal) |
| Control Voltage | 24 V DC (external) |
| Cooling Method | Forced air (integrated fan) |
| Protection Class | IP20 |
| Ambient Temperature (Operating) | 0 °C to +40 °C |
| Storage Temperature | -25 °C to +70 °C |
| Relative Humidity | 5–95%, non-condensing |
| Communication Interface | SERCOS III / PROFIBUS DP (firmware dependent) |
| Encoder Interface | IndraDrive compatible (MSK/MSM motor series) |
| Country of Origin | Germany |
| Weight (approx.) | 300 g |
| Compliance | CE, UL, RoHS |
Proven Application Environments
- Machine Tool & CNC: High-dynamic axis control for milling, turning, and grinding centers requiring sub-millisecond torque response.
- Packaging Machinery: Synchronized multi-axis motion for form-fill-seal, cartoning, and palletizing lines.
- Printing & Converting: Tension and register control in web-fed offset and flexographic presses.
- Semiconductor & Electronics Manufacturing: Precision positioning in pick-and-place, wafer handling, and SMT equipment.
- Plastics & Injection Molding: Servo-hydraulic and all-electric injection axis control.
- Robotics & Handling: Compact drive integration in articulated arm and SCARA robot joint controllers.
Engineering Advantages
- Compact Form Factor: Reduced panel footprint versus HCS03/HCS04 units — ideal for space-constrained control cabinets.
- IndraDrive Ecosystem Compatibility: Full firmware and parameter compatibility with Rexroth IndraWorks engineering software and IndraDrive Cs/Cc/Mi series.
- Integrated Functional Safety: Supports Safe Torque Off (STO) and Safe Stop 1 (SS1) per IEC 62061 / ISO 13849-1 (firmware/option dependent).
- Energy Efficiency: DC bus sharing capability reduces regenerative energy losses in multi-axis system configurations.
- Onboard Diagnostics: H1/H2 diagnostic display and SERCOS status LEDs for rapid fault identification without external tools.
- Global Voltage Range: Accepts 200–480 V AC input — suitable for worldwide deployment without hardware modification.
System Architecture & Signal Flow
The HCS02.1E-W0028-A-03-NNNN operates as a self-contained single-axis drive within the IndraDrive HCS topology. AC mains power is rectified to a 750 V DC bus, which feeds the IGBT inverter stage to generate variable-frequency, variable-voltage output to the connected servo motor (MSK/MSM series). The IndraDrive firmware processes position/velocity/torque commands received via the fieldbus interface (SERCOS III or PROFIBUS DP). Encoder feedback from the motor is evaluated by the integrated encoder circuit, closing position and current control loops at up to 4 kHz. The 24 V DC control supply maintains logic and communication functions independently of the main power stage, enabling safe power sequencing and STO functionality.
Sourcing & Quality Verification
- All units sourced through verified industrial supply channels with full traceability documentation.
- Pre-shipment inspection: visual examination, label verification, and functional power-on test where applicable.
- Original Bosch Rexroth packaging and documentation supplied where available.
- Counterfeit prevention: serial number cross-referenced against Rexroth production records on request.
- Warranty: 12-month limited warranty against manufacturing defects from date of shipment.
Procurement Process
- Inquiry: Submit your BOM or part number to [email protected] or via the product page.
- Stock Confirmation: Our team confirms availability and lead time within 1 business day.
- Quotation: Formal quotation issued with unit price, shipping terms (EXW/DDP), and payment options.
- Order Placement: Purchase order accepted via email; payment via T/T, PayPal, or credit card.
- Shipment: Dispatched via DHL / FedEx / UPS with full tracking. Export documentation (commercial invoice, packing list, COO) provided.
- After-Sales: Technical support available post-delivery for integration and commissioning queries.
Technical FAQ
Q: Is the HCS02.1E-W0028-A-03-NNNN compatible with IndraDrive Cs motors?
A: Yes. The HCS02 series is designed to operate with Rexroth MSK and MSM servo motors within the IndraDrive ecosystem. Verify that the motor power rating does not exceed the drive’s continuous output current.
Q: What firmware version is pre-loaded?
A: Firmware version varies by production batch. Rexroth IndraWorks can update firmware to the latest release. Contact us for specific firmware version confirmation prior to order.
Q: Can this drive be used with third-party servo motors?
A: The HCS02 supports third-party motors with compatible encoder interfaces (EnDat, Hiperface, resolver) via appropriate encoder adapter modules. Consult Rexroth application engineering for the full compatibility matrix.
Q: What does the suffix -A-03-NNNN indicate?
A: The suffix encodes hardware options: “A” = standard housing, “03” = firmware/communication option set, “NNNN” = no additional hardware options. Variants with different suffixes may include additional I/O, safety, or communication options.
Q: Do you provide export documentation for customs clearance?
A: Yes. Full export documentation including commercial invoice, packing list, and certificate of origin is provided with every international shipment.
