Process Control Solution – SCHNEIDER 140ACI05100SC | Quantum Series
The Schneider Electric 140ACI05100SC is a high-density 16-channel analog input module engineered for the Modicon Quantum PLC platform. Designed for demanding industrial environments, it delivers precise signal acquisition across a wide range of process variables — making it the preferred choice for engineers specifying reliable, scalable automation infrastructure.
Where This Product Is Used
The 140ACI05100SC is deployed across a broad spectrum of industrial applications where accurate analog signal measurement is mission-critical:
- Process Manufacturing — Temperature, pressure, and flow monitoring in chemical, petrochemical, and pharmaceutical plants
- Water & Wastewater Treatment — Multi-point sensor acquisition for pump stations, filtration systems, and SCADA-integrated treatment facilities
- Power Generation & Energy Management — Current and voltage monitoring in substations, co-generation plants, and grid-tie systems
- Oil & Gas — Pipeline pressure monitoring, wellhead instrumentation, and offshore platform control panels
- Building Automation (BAS/BMS) — HVAC loop control, chiller plant optimization, and energy metering integration
- Food & Beverage — CIP process monitoring, tank level sensing, and batch temperature profiling
- Mining & Metals — Conveyor load monitoring, furnace temperature control, and slurry flow measurement
Technical Specifications
- Part Number: 140ACI05100SC
- Manufacturer: Schneider Electric (Modicon)
- Series: Quantum PLC
- Module Type: Analog Input
- Number of Channels: 16 (single-ended) / 8 (differential)
- Input Signal Range: ±10 V, 0–10 V, 0–5 V, 1–5 V, 0–20 mA, 4–20 mA
- Resolution: 12-bit (1 in 4096)
- Isolation: Channel-to-backplane isolated
- Backplane Bus: Quantum I/O bus compatible
- Operating Temperature: 0°C to +60°C
- Storage Temperature: -40°C to +85°C
- Relative Humidity: 5% to 95% non-condensing
- Power Consumption: Supplied via Quantum backplane
- Certifications: CE, UL, cUL
- Dimensions: Standard Quantum single-slot form factor
- Weight: Approx. 0.3 kg
Why Engineers Specify This Model
- High Channel Density — 16 single-ended inputs in a single slot minimizes rack space and reduces BOM cost per channel
- Universal Signal Compatibility — Accepts both voltage and current loop signals without external signal conditioners
- Proven Quantum Ecosystem — Plug-and-play integration with Modicon Quantum CPUs, power supplies, and communication adapters
- Robust Isolation Architecture — Channel-to-backplane isolation protects the CPU from field-side transients and ground loops
- Long Product Lifecycle — Schneider Electric’s Quantum platform has decades of installed base, ensuring long-term spare parts availability
- Unity Pro / Control Expert Compatible — Native configuration via Schneider’s standard engineering software with no additional drivers required
Complete System Bill of Materials
For a complete Quantum analog input subsystem, engineers typically specify the following alongside the 140ACI05100SC:
- Quantum CPU: 140CPU65150 / 140CPU67160 (Hot Standby)
- Power Supply: 140CPS11420 / 140CPS21400
- Backplane / Rack: 140XBP01600 (16-slot) / 140XBP00600 (6-slot)
- Remote I/O Head: 140CRA93100 (for distributed architectures)
- Field Wiring Adapter: 140XTS00200 terminal block adapter
- Communication Module: 140NOE77101 (Ethernet) / 140NOM21100 (Modbus Plus)
- Engineering Software: EcoStruxure Control Expert (formerly Unity Pro)
Contact support@konmask.com for complete system quotations and BOM validation.
Compliance & Industry Standards
- CE Marking — Compliant with EU Low Voltage and EMC Directives
- UL / cUL Listed — Recognized for use in North American industrial installations
- IEC 61131-2 — Programmable controller hardware standard compliance
- RoHS Compliant — Restriction of Hazardous Substances Directive
- ATEX / IECEx — Consult factory for hazardous area installation requirements
Quality Assurance & Sourcing
Konmask.com sources the 140ACI05100SC exclusively through verified industrial distribution channels. Every unit undergoes the following before dispatch:
- Visual inspection for physical damage, label integrity, and connector condition
- Verification of manufacturer date codes and firmware revision markings
- Anti-static packaging with humidity indicator cards for long-term storage protection
- Documentation package: datasheet, declaration of conformity, and traceability record available on request
We do not source from grey-market or unverified secondary channels. All inventory is traceable to authorized distributors or OEM surplus programs.
How to Source This Part
- In-Stock Orders: Add to cart and proceed to checkout — same-day dispatch for orders placed before 15:00 CST
- Bulk / Project Quantities: Email support@konmask.com with your BOM for volume pricing and lead time confirmation
- Urgent / Emergency Sourcing: Call or WhatsApp +0086 19859288691 for expedited availability check
- OEM / Integrator Accounts: Inquire about net-30 terms and dedicated account management for recurring project needs
- Export / International Orders: We ship globally — contact us for customs documentation, HS code confirmation, and freight options
Application-Specific FAQ
Q: Can the 140ACI05100SC accept thermocouple or RTD inputs directly?
A: No. This module accepts standard voltage and current loop signals only. For thermocouple inputs, specify the 140ATI03000; for RTD inputs, specify the 140ARI03010.
Q: Is this module compatible with Quantum Hot Standby (HSBY) configurations?
A: Yes. The 140ACI05100SC is fully compatible with Quantum HSBY architectures when used with supported Hot Standby CPUs (e.g., 140CPU67160). Ensure Unity Pro / Control Expert HSBY configuration is applied correctly.
Q: What is the maximum cable length for field wiring to this module?
A: Schneider Electric recommends shielded twisted-pair cable with a maximum run of 300 m for current loop inputs (4–20 mA) and 30 m for voltage inputs, depending on EMI environment. Always ground cable shields at one end only.
Q: Can I mix voltage and current inputs on the same module?
A: Yes, on a per-channel basis. Each channel is individually configurable via software for voltage or current input mode — no hardware jumpers required.
Q: What is the difference between the 140ACI05100SC and the standard 140ACI04000?
A: The 140ACI05100SC offers 16 channels versus 8 on the 140ACI04000, and includes enhanced surge protection (SC suffix). It is the preferred replacement for higher-density or safety-sensitive applications.
Q: Do you provide a warranty on this module?
A: Yes. Konmask.com provides a 12-month warranty against manufacturing defects on all stocked modules. Warranty claims are processed within 5 business days of receipt.
