SCHNEIDER A.F.038.5/01 Electric Circuit Board | Replacement, Equivalent & Selection Guide
The Schneider Electric A.F.038.5/01 is an industrial-grade electric circuit board designed for use in automation and control system applications. This page provides full technical specifications, compatible replacement models, application guidance, and sourcing information to help engineers and procurement teams make confident selection decisions.
Technical Specifications
- Part Number: A.F.038.5/01
- Manufacturer: Schneider Electric
- Product Type: Electric Circuit Board / Control Card
- Application: Industrial automation, drive control, PLC/DCS auxiliary boards
- Form Factor: PCB module (plug-in / rack-mount, confirm with datasheet)
- Operating Temperature: 0°C to +55°C (typical for Schneider control boards)
- Storage Temperature: -25°C to +70°C
- Compliance: CE, RoHS (verify with current Schneider documentation)
- Condition Available: New, Refurbished, Tested Used
Note: Confirm exact electrical ratings (voltage, current, I/O count) against the original Schneider Electric datasheet before installation.
Compatible Replacement & Equivalent Models
The following models may serve as direct or functional replacements for the A.F.038.5/01. Always verify pinout, firmware version, and system compatibility before substitution:
- Schneider A.F.038.5/02 – Revised revision of the same board series; check revision compatibility with your drive/controller firmware
- Schneider A.F.038.4/01 – Previous generation; may be functionally equivalent in legacy systems
- Schneider VX5A1HC1 – Replacement control card for Altivar series (if A.F.038.5/01 is used in an Altivar drive context)
- Third-party OEM equivalents – Available from certified repair facilities; must match connector type, signal levels, and firmware interface
⚠ Important: Schneider Electric part numbers are revision-sensitive. Always cross-reference the full part number including suffix before ordering a replacement.
Why Choose the Original Model
- OEM Guaranteed Compatibility: Designed and tested specifically for Schneider Electric systems — zero integration risk
- Firmware Alignment: Original boards ship with factory-matched firmware; no re-flashing required
- Warranty & Support: Eligible for Schneider Electric technical support and warranty coverage
- Long-Term Reliability: Manufactured to IEC industrial standards with full traceability
- Reduced Downtime Risk: Drop-in replacement with no configuration changes in most applications
Typical Applications
- Schneider Altivar variable frequency drive (VFD) control boards
- Modicon PLC auxiliary interface cards
- Industrial motor control centers (MCC)
- Process automation panels in oil & gas, water treatment, and manufacturing
- Building automation and HVAC control systems
- Conveyor, crane, and hoist drive systems
System Compatibility
| System / Platform | Compatibility | Notes |
|---|---|---|
| Schneider Altivar 31 / 312 | ✅ Likely Compatible | Verify board slot and connector |
| Schneider Altivar 61 / 71 | ⚠ Check Revision | Confirm firmware version match |
| Modicon M340 / M580 | ⚠ Application-Specific | Used as auxiliary I/O board only |
| Third-party SCADA / DCS | ✅ Signal-Level Compatible | Requires signal mapping verification |
Selection Guide
Use the following checklist to confirm the A.F.038.5/01 is the correct part for your application:
- ☐ Match the full part number including suffix (e.g., /01 vs /02)
- ☐ Confirm host system model — drive, PLC, or controller model number
- ☐ Check firmware version of the host system against board compatibility matrix
- ☐ Verify connector type — edge connector, ribbon, or DIN rail interface
- ☐ Assess condition requirement — new OEM, certified refurbished, or tested used
- ☐ Confirm lead time tolerance — stock available vs. factory order
- ☐ Review export/import compliance if shipping internationally
Not sure which part you need? Contact our technical team at [email protected] with your system model and we will confirm compatibility.
Quality Assurance & Sourcing
- Source: Authorized distributors, certified surplus, and OEM-tested refurbished stock
- Inspection: All boards are visually inspected and function-tested prior to shipment
- Traceability: Date codes and batch records available on request
- Anti-Counterfeit: We do not source from unverified grey-market channels
- Packaging: ESD-safe anti-static packaging with moisture barrier for all circuit boards
- Documentation: Certificate of conformance (CoC) available upon request
How to Order
- Add to Cart directly on this page — select condition (New / Refurbished / Used-Tested)
- Request a Quote for bulk orders (>5 units) or urgent delivery — email [email protected]
- Provide System Details — share your drive/PLC model for compatibility confirmation before shipment
- Payment: T/T (Bank Transfer), PayPal, and major credit cards accepted
- Shipping: DHL / FedEx / UPS express worldwide; lead time 1–5 business days for in-stock items
📞 Phone / WhatsApp: +0086 19859288691
📧 Email: [email protected]
Replacement & Compatibility FAQ
Q: Can I use A.F.038.5/02 as a direct replacement for A.F.038.5/01?
A: In most cases yes, but the /02 revision may include hardware or firmware changes. Confirm with Schneider Electric’s compatibility matrix or contact us for guidance.
Q: Is a refurbished board as reliable as a new one?
A: Certified refurbished boards that have been fully tested and restored to factory spec are suitable for most applications. We provide test reports on request.
Q: Do you offer a warranty on this part?
A: Yes — new OEM parts carry the manufacturer warranty. Refurbished and tested-used parts carry a 90-day functional warranty from Konmask.com.
Q: Can you source this part if it’s not in stock?
A: Yes. We have access to global surplus and authorized distributor networks. Contact us with your timeline and we will provide availability and lead time.
Q: What information do I need to provide when ordering?
A: Full part number (A.F.038.5/01), host system model, required quantity, and preferred condition (new/refurbished/used).
