Servo Motion Control Solution — SCHNEIDER BCH2MM0813CA6C | Lexium BCH2 Series
Where This Product Is Used
The Schneider Electric BCH2MM0813CA6C is a high-performance AC servo motor from the Lexium BCH2 series, engineered for precision motion control across demanding industrial environments. Typical deployment scenarios include:
- CNC Machining Centers — Axis feed drives requiring tight positional accuracy and dynamic response
- Packaging Machinery — High-speed pick-and-place, form-fill-seal, and labeling lines
- Textile & Printing Equipment — Tension control and register synchronization applications
- Robotics & Handling Systems — Articulated arm joints and gantry positioning axes
- Semiconductor & Electronics Assembly — Sub-millimeter positioning on SMT and wafer-handling platforms
- Material Handling Conveyors — Variable-speed drives with precise start/stop profiling
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Schneider Electric |
| Part Number | BCH2MM0813CA6C |
| Series | Lexium BCH2 |
| Motor Type | AC Brushless Servo Motor |
| Compliance Standard | IEC 60034-1 |
| Frame Size | 80 mm (MM) |
| Rated Speed | 3,000 rpm |
| Encoder Type | Incremental / Absolute (per suffix) |
| Protection Rating | IP65 (shaft end IP54) |
| Insulation Class | Class F (155 °C) |
| Cooling Method | Self-cooled (IC 410) |
| Weight | ~1.2 kg |
| Mounting | Flange mount (B5 / IEC 60072) |
| Shaft | Cylindrical with keyway |
| Operating Temperature | 0 °C to +40 °C ambient |
| Storage Temperature | −20 °C to +70 °C |
Specifications are based on published Schneider Electric Lexium BCH2 datasheet values. Confirm exact ratings on the motor nameplate before commissioning.
Why Engineers Specify This Model
- IEC 60034-1 Certified — Meets international rotating electrical machine standards, simplifying CE and global compliance documentation
- Compact 80 mm Frame — High torque density in a space-efficient footprint, ideal for machine retrofits and tight cabinet layouts
- Native Lexium Drive Compatibility — Plug-and-play pairing with Schneider LXM32 and LXM28 servo drives; no third-party tuning required
- IP65 Ingress Protection — Suitable for wash-down-adjacent environments and dusty factory floors
- Class F Insulation — Extended thermal headroom for continuous-duty and high-cycle applications
- Broad Ecosystem — Integrates with SoMachine Motion, EcoStruxure Machine Expert, and CANopen / EtherCAT fieldbus topologies
Complete System Bill of Materials
For a fully operational servo axis using the BCH2MM0813CA6C, engineers typically specify:
- Servo Drive — Schneider LXM32MD18N4 or LXM28AU10F3X (matched to motor power rating)
- Servo Cable (Power) — VW3M5101Rxx motor power cable (shielded, drag-chain rated)
- Servo Cable (Encoder) — VW3M8102Rxx encoder feedback cable
- Braking Resistor — VW3A7601 (external, if regenerative braking is required)
- EMC Line Filter — VW3A4401 or equivalent, per CE installation guidelines
- Controller / PLC — Schneider M241, M262, or compatible Modicon PLC with motion library
- Safety Module — TM3SAF5R or equivalent STO (Safe Torque Off) module for SIL 2 / PLd compliance
Compliance & Industry Standards
- IEC 60034-1 — Rating and performance of rotating electrical machines
- IEC 60034-5 — Degrees of protection (IP65 enclosure)
- IEC 60034-8 — Terminal markings and direction of rotation
- EN 61800-5-1 — Safety requirements for adjustable-speed electrical power drive systems
- CE Marking — Machinery Directive 2006/42/EC and Low Voltage Directive 2014/35/EU
- RoHS Compliant — Directive 2011/65/EU (restriction of hazardous substances)
Quality Assurance & Sourcing
- All units sourced from authorized Schneider Electric distribution channels or verified surplus with full traceability documentation
- Pre-shipment inspection includes nameplate verification, insulation resistance check (≥ 100 MΩ at 500 VDC), and shaft/encoder continuity test
- Original manufacturer packaging preserved where available; repackaged units include inspection report
- Batch traceability records retained for 3 years post-shipment
- Counterfeit-prevention: serial numbers cross-referenced against Schneider Electric verification database prior to dispatch
How to Source This Part
Ready to order or need a formal quotation?
- Add to Cart — Immediate checkout for stocked units
- Request a Quote — Email [email protected] with your required quantity, delivery timeline, and destination port
- Bulk / Project Orders — Volume pricing available for OEM integrators and EPC contractors; contact us with your BOM
- Lead Time — In-stock units ship within 1–3 business days; ex-factory orders quoted on request
- Export Documentation — Commercial invoice, packing list, COO, and ECCN classification available upon request
Application-Specific FAQ
Q: Is the BCH2MM0813CA6C compatible with third-party servo drives?
A: The motor uses a standard resolver or incremental encoder interface. While native compatibility is with Schneider Lexium drives, integration with third-party drives (Siemens, Yaskawa, Mitsubishi) is possible with appropriate feedback adapter modules. Consult your drive manufacturer’s compatibility matrix.
Q: What is the difference between the CA6C and other BCH2MM0813 suffix variants?
A: The suffix encodes options such as encoder type (incremental vs. absolute), brake option, shaft configuration, and connector orientation. CA6C denotes a specific factory configuration — confirm your application requirements against the Schneider BCH2 selection guide before substituting variants.
Q: Can this motor be used in food & beverage or pharmaceutical environments?
A: The IP65 rating provides protection against dust and water jets, making it suitable for non-direct-contact food-adjacent zones. For wash-down or hygienic-design requirements, verify with Schneider Electric’s food-grade motor options or apply appropriate shaft sealing.
Q: What spare parts should be stocked alongside this motor?
A: Recommended spares include the matched encoder cable (VW3M8102R), shaft seal kit, and a spare drive module. For high-uptime lines, a cold-standby motor unit is advisable.
Q: Does Konmask provide installation or commissioning support?
A: We provide technical documentation, wiring diagrams, and parameter file templates. On-site commissioning support can be arranged through our partner network — contact us for details.
