Schneider Electric BMXAMO0410 Analog Output Module | Replacement, Equivalent & Selection Guide
The Schneider Electric BMXAMO0410 is a 4-channel analog output module designed for the Modicon M340 PLC platform. Delivering precise ±10 V / 0–20 mA / 4–20 mA output signals, it is the standard choice for process control, drive speed reference, and valve positioning in industrial automation systems. This page provides full technical specifications, verified replacement equivalents, and a practical selection guide to help engineers and procurement teams make confident sourcing decisions.
Technical Specifications
- Part Number: BMXAMO0410
- Brand: Schneider Electric
- Series: Modicon M340
- Module Type: Analog Output
- Number of Channels: 4
- Output Signal Types: ±10 V (voltage) | 0–20 mA / 4–20 mA (current)
- Resolution: 12-bit (voltage) / 12-bit (current)
- Accuracy: ±0.1% of full scale at 25 °C
- Update Time: ≤ 1 ms per channel
- Supply Voltage: 24 V DC (from backplane)
- Isolation: Channel-to-bus isolation
- Operating Temperature: 0 °C to +60 °C
- Mounting: Modicon M340 rack (BMX XBP ••••)
- Dimensions (W × H × D): 30 × 100 × 73 mm
- Weight: 180 g
- Certifications: CE, UL, cUL, RoHS
- Country of Origin: France
Compatible Replacement & Equivalent Models
When the BMXAMO0410 is unavailable or under evaluation, the following models are commonly considered as functional equivalents or drop-in replacements:
- BMXAMO0410H – Conformal-coated variant for harsh environments (same electrical specs, enhanced protection)
- BMXAMO0802 – 8-channel analog output alternative within M340 series (different channel count)
- TSXASO0820 – Legacy Premium platform equivalent (requires rack/bus adapter; not a direct swap)
- 140AO02000 – Quantum platform analog output (different platform; consult system integrator)
- Third-party equivalents: Wago 750-554, Phoenix Contact AXL F AO4 I (signal-compatible; verify rack compatibility before ordering)
⚠️ Always verify rack compatibility, firmware version, and Unity Pro/EcoStruxure configuration before substituting modules.
Why Choose the Original BMXAMO0410
- ✅ Native M340 Integration – Plug-and-play with BMX XBP racks; no adapter required
- ✅ Unity Pro / EcoStruxure Machine Expert Support – Full DDT and I/O mapping out of the box
- ✅ Proven Field Reliability – Widely deployed in oil & gas, water treatment, and manufacturing
- ✅ Schneider Electric Warranty – Backed by global service network and spare parts availability
- ✅ Regulatory Compliance – CE, UL, RoHS certified for global project requirements
Typical Applications
- Variable frequency drive (VFD) speed reference signals
- Control valve and actuator positioning (4–20 mA loops)
- Process temperature and pressure setpoint transmission
- Conveyor and pump flow rate control
- Building automation: HVAC damper and chiller control
- Water & wastewater treatment dosing systems
- Batch process control in food & beverage and pharmaceutical plants
System Compatibility
- Compatible Racks: BMX XBP 0400 / 0800 / 1200 / 0800H / 1200H
- Compatible CPUs: BMX P34 1000 / 2000 / 2010 / 2020 / 20302 / 20302H
- Programming Software: Unity Pro (v2.0+), EcoStruxure Machine Expert
- Bus: Modicon M340 X-Bus backplane
- Not compatible with: Modicon M580, Premium TSX, Quantum 140 racks (different bus architecture)
Selection Guide
| Requirement | Recommended Model | Notes |
|---|---|---|
| 4-ch AO, standard environment | BMXAMO0410 | This product — best fit |
| 4-ch AO, harsh/humid environment | BMXAMO0410H | Conformal coating |
| 8-ch AO needed | BMXAMO0802 | Same M340 platform |
| Mixed AI + AO in one slot | Not available in M340 | Use separate AI + AO modules |
| Migrating from Premium TSX | BMXAMO0410 + rewiring | Consult migration guide |
Quality Assurance & Sourcing
At Konmask.com, every BMXAMO0410 unit goes through a documented 4-step verification process before shipment:
- Source Verification – Traced to authorized distributors or OEM-certified supply chains
- Visual & Label Inspection – Part number, date code, and hologram authentication
- Functional Bench Test – Output signal accuracy verified across all 4 channels
- Packaging & Documentation Check – ESD-safe packaging, test report, and certificate of conformity included
We maintain traceability records for every unit. Counterfeit-free guarantee backed by our sourcing policy.
How to Order
- Confirm your M340 rack model and available slot count
- Verify Unity Pro / EcoStruxure software version compatibility
- Add BMXAMO0410 to cart or contact us for bulk/project pricing
- Request a certificate of conformity or test report if required for your project
- Choose your shipping method — DHL / FedEx / UPS express available worldwide
