Industrial Automation Power Solution – Schneider Electric BMXCPS4002 | Modicon M340
Where This Product Is Used
The Schneider Electric BMXCPS4002 is a rack-mount AC power supply module designed exclusively for the Modicon M340 PLC platform. It is widely deployed across demanding industrial environments where stable, regulated DC bus power is critical to system uptime. Typical application scenarios include:
- Automotive Assembly Lines – Powers M340 CPUs and I/O racks controlling robotic welding cells, conveyor sequencing, and quality inspection stations.
- Water & Wastewater Treatment Plants – Supplies continuous power to M340 controllers managing pump stations, dosing systems, and SCADA-connected RTUs.
- Oil & Gas Upstream/Midstream – Used in wellhead control panels and pipeline SCADA cabinets where wide-range AC input (100–240 VAC) accommodates unstable field power.
- Food & Beverage Processing – Integrated into hygienic-area control panels running CIP sequences, filling lines, and packaging machinery.
- Building Management Systems (BMS) – Provides reliable bus power for M340 controllers managing HVAC, lighting, and energy metering in commercial facilities.
- Pharmaceutical Manufacturing – Supports validated M340 systems in GMP-compliant environments requiring documented, traceable hardware.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | BMXCPS4002 |
| Brand | Schneider Electric |
| Series | Modicon M340 |
| Module Type | AC Power Supply Module |
| Input Voltage | 100 – 240 VAC (wide range) |
| Input Frequency | 47 – 63 Hz |
| Output Voltage | 3.3 VDC / 5 VDC / 24 VDC (internal bus) |
| Output Power | 40 W (backplane bus) |
| Sensor Power Supply | 24 VDC / 0.5 A (protected) |
| Rack Compatibility | BMX XBP ••00 series racks (4, 6, 8, 12 slots) |
| Slot Position | Slot 00 (leftmost position) |
| Protection Class | IP20 |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -25 °C to +70 °C |
| Relative Humidity | 10 – 95% (non-condensing) |
| Dimensions (H × W × D) | 100 × 30 × 115 mm (1 slot wide) |
| Weight | ~500 g |
| Certifications | CE, UL, cUL, CSA |
Why Engineers Specify This Model
- Wide-Range AC Input: Accepts 100–240 VAC without manual switching, making it suitable for global deployments and sites with unstable utility power.
- Integrated 24 VDC Sensor Supply: Eliminates the need for a separate sensor power supply in small-to-medium I/O configurations, reducing panel footprint and BOM cost.
- Hot-Swap Ready Architecture: Designed for the M340 backplane, enabling planned maintenance without full system shutdown when used with redundant configurations.
- Compact 1-Slot Form Factor: Maximizes available I/O slots in space-constrained enclosures.
- Proven Field Reliability: Part of the Modicon M340 ecosystem with millions of installed units across global industrial sites.
Complete System Bill of Materials
A typical Modicon M340 control system using the BMXCPS4002 includes the following components:
- BMXCPS4002 – AC Power Supply Module (this item)
- BMXP342020 / BMXP342030 – Modicon M340 CPU Module
- BMX XBP 0800 / 1200 – M340 Rack (8-slot or 12-slot)
- BMXDDI1602 / BMXDDO1602 – Digital Input / Output Modules
- BMXAMI0410 / BMXAMO0210 – Analog Input / Output Modules
- BMXNOE0100 / BMXNOE0110 – Ethernet Communication Module
- BMXXEM010 – Rack Extension Module (for multi-rack systems)
Contact [email protected] for complete system quotations.
Compliance & Industry Standards
- CE Marking – Compliant with EU Low Voltage Directive and EMC Directive
- UL 508 – Listed for industrial control equipment (USA)
- cUL / CSA – Certified for Canadian market
- IEC 61131-2 – Programmable controller hardware standard
- RoHS Compliant – Restriction of Hazardous Substances
- REACH Compliant – EU chemical regulation compliance
Quality Assurance & Sourcing
Every BMXCPS4002 unit offered by Konmask.com undergoes a structured quality process:
- ✔ Visual Inspection – Enclosure integrity, label authenticity, and connector condition verified
- ✔ Functional Power-On Test – Output voltage rails confirmed within specification
- ✔ Traceability Documentation – Batch records and sourcing chain documented on request
- ✔ Anti-Counterfeit Screening – Cross-referenced against Schneider Electric genuine part identifiers
- ✔ ESD-Safe Packaging – Shipped in anti-static bags with foam protection
We source from authorized distributors, OEM surplus channels, and verified industrial resellers. New, refurbished, and tested-used conditions are clearly labeled at time of purchase.
How to Source This Part
- Add to Cart – Click the purchase button above to place an order directly.
- Request a Quote – For bulk orders (5+ units), email [email protected] for volume pricing.
- Urgent Requirement – Call or WhatsApp +0086 19859288691 for same-day stock confirmation and expedited shipping options.
- System Integration Support – Our engineers can assist with rack configuration, CPU selection, and I/O module pairing for complete M340 system builds.
Application-Specific FAQ
Q: Can the BMXCPS4002 power a full 12-slot M340 rack with all slots occupied?
A: The BMXCPS4002 provides 40 W to the backplane. For fully loaded 12-slot racks with high-power modules, verify total module power consumption against this budget. For higher-demand configurations, consider the BMXCPS4022 (redundant) or BMXCPS3500 (higher wattage variants).
Q: Is this module compatible with the Modicon M580 platform?
A: No. The BMXCPS4002 is designed exclusively for the Modicon M340 (BMX) rack family. Modicon M580 uses the BMENOC and BMECPS series power supplies.
Q: Does the 24 VDC sensor output support field device power in a panel?
A: Yes, the integrated 24 VDC / 0.5 A output can power proximity sensors, limit switches, and other low-current field devices directly, reducing the need for a separate 24 VDC PSU in small systems.
Q: What happens during an AC input power failure?
A: The BMXCPS4002 provides a brief hold-up time allowing the CPU to execute a controlled shutdown. For extended ride-through, pair with an external UPS system on the AC input.
Q: Can I use this module in a hazardous area (Zone 1 / Class I Div 1)?
A: The BMXCPS4002 is rated IP20 and is not ATEX/IECEx certified for use in hazardous areas. It must be installed in a purged or pressurized enclosure (Ex p) or located in a safe area with appropriate barriers.
