Motor Protection Solution – Schneider Electric GVAD1001 | TeSys GV2 Series
The Schneider Electric GVAD1001 is a compact motor circuit breaker from the renowned TeSys GV2 series, engineered to deliver reliable short-circuit and overload protection for three-phase motors in demanding industrial environments. Combining manual motor control with integrated protection in a single device, the GVAD1001 eliminates the need for separate fuses and simplifies panel wiring — a preferred choice among control engineers worldwide.
Where This Product Is Used
The GVAD1001 is deployed across a wide range of industrial motor-driven applications:
- Pump Stations & Water Treatment Plants – Protects centrifugal and submersible pump motors from overload and phase loss.
- Conveyor & Material Handling Systems – Provides reliable branch circuit protection for belt and roller conveyor drives.
- HVAC & Compressor Units – Safeguards compressor motors in air handling and refrigeration systems.
- Machine Tool & CNC Panels – Used as a motor branch circuit protector in spindle and servo drive circuits.
- Packaging & Food Processing Lines – Ensures continuous uptime by isolating faulted motor circuits without tripping the main breaker.
- Oil & Gas Auxiliary Systems – Installed in MCC (Motor Control Center) panels for auxiliary pump and fan motor protection.
Technical Specifications
| Part Number | GVAD1001 |
| Brand | Schneider Electric |
| Series | TeSys GV2 |
| Type | Motor Circuit Breaker (Manual Motor Starter) |
| Rated Current | 0.1 – 0.16 A (adjustable) |
| Rated Voltage | 690 V AC (IEC) / 600 V AC (UL) |
| Short-Circuit Breaking Capacity | 100 kA at 415 V AC (with GV2AF auxiliary) |
| Poles | 3-pole |
| Mounting | DIN Rail (35 mm) / Panel Mount |
| Protection Class | IP20 (terminal), IP40 (front face) |
| Operating Temperature | -25°C to +60°C |
| Weight | 450 g |
| Certifications | IEC 60947-2, IEC 60947-4-1, UL 508, CSA C22.2 |
Why Engineers Specify This Model
- Integrated Protection: Combines thermal-magnetic overload and short-circuit protection in one compact unit — no separate fuse required.
- Precise Current Setting: Rotary dial allows fine-tuned current adjustment from 0.1 to 0.16 A, ideal for very small motor loads.
- High Breaking Capacity: Rated up to 100 kA Icu, meeting the most stringent industrial panel requirements.
- Modular Accessories: Compatible with GV2 series auxiliary contacts, alarm contacts, and communication modules for remote monitoring.
- Space-Saving Design: 45 mm wide footprint minimizes panel real estate in compact MCC and control cabinets.
- Global Certifications: IEC, UL, and CSA listed — suitable for projects in Asia, Europe, and North America.
Complete System Bill of Materials
For a complete motor protection and control circuit using the GVAD1001, engineers typically specify:
- GVAD1001 – Motor circuit breaker (this unit)
- GV2AF – Auxiliary contact block (1NO+1NC)
- GV2G – Enclosure / IP55 housing for standalone installation
- LC1D09 – TeSys D contactor (for remote start/stop control)
- LRD10 – Overload relay (if separate overload protection is required)
- NSYTRV24 – Terminal block for panel wiring
Compliance & Industry Standards
- IEC 60947-2: Low-voltage switchgear – Circuit breakers
- IEC 60947-4-1: Low-voltage switchgear – Electromechanical contactors and motor starters
- UL 508: Industrial Control Equipment (USA)
- CSA C22.2 No. 14: Industrial Control Equipment (Canada)
- CE Marked – Compliant with EU Low Voltage Directive 2014/35/EU
- RoHS Compliant – Restriction of Hazardous Substances
Quality Assurance & Sourcing
All Schneider Electric products supplied by Konmask.com are sourced through verified industrial distribution channels. Each unit undergoes the following quality checks before dispatch:
- Visual inspection for physical damage and label integrity
- Verification of original Schneider Electric holographic security label
- Functional continuity check on all poles
- Packaging inspection — original factory carton with batch traceability
We provide full traceability documentation upon request, including country of manufacture and production batch records.
How to Source This Part
The Schneider Electric GVAD1001 is available for immediate inquiry through Konmask.com. We serve OEM manufacturers, system integrators, MRO procurement teams, and engineering contractors globally.
- MOQ: 1 piece (sample orders accepted)
- Lead Time: In-stock items ship within 1–3 business days; ex-factory orders 2–4 weeks
- Payment: T/T, PayPal, Trade Assurance, and major credit cards accepted
- Shipping: DHL, FedEx, UPS express; sea freight for bulk orders
- Documentation: Commercial invoice, packing list, COO, and test report available
📧 Contact us: support@konmask.com | 📞 +0086 19859288691
Application-Specific FAQ
- Q: Can the GVAD1001 be used as a standalone motor starter without a contactor?
- A: Yes. The GVAD1001 includes a manual ON/OFF rotary handle and can function as a direct-on-line (DOL) manual motor starter for non-reversing, infrequently switched loads. For remote or automatic control, pair it with a TeSys D contactor.
- Q: What is the difference between GVAD1001 and GV2ME01?
- A: Both are TeSys GV2 series motor circuit breakers. The GVAD1001 uses a rotary handle operator, while the GV2ME01 uses a toggle handle. Current range and protection characteristics are equivalent for the 0.1–0.16 A range.
- Q: Is the GVAD1001 suitable for single-phase motor protection?
- A: The GVAD1001 is a 3-pole device designed for three-phase motors. For single-phase applications, only two poles are used; however, Schneider Electric recommends using a dedicated single-phase motor protector for optimal protection.
- Q: Can I add a remote trip or alarm signal to this breaker?
- A: Yes. The GV2 series supports snap-on auxiliary contact blocks (e.g., GV2AF) that provide auxiliary and alarm contacts for PLC feedback or remote indication panels.
- Q: What panel bus bar system is compatible with the GVAD1001?
- A: The GVAD1001 is compatible with Schneider Electric’s GV2 series comb bus bars and the Linergy distribution system for multi-motor panel assemblies.
