Schneider Electric iC65N 1P C1A Miniature Circuit Breaker – iC65N Series
When a miniature circuit breaker fails in an industrial control panel, the consequences cascade instantly: production lines halt, PLCs lose power, and unprotected wiring becomes a fire hazard. In precision-sensitive environments — from pharmaceutical clean rooms to automotive assembly lines — even a momentary overcurrent event without proper protection can destroy expensive equipment and trigger costly downtime. The Schneider Electric iC65N 1P C1A is engineered to prevent exactly this scenario, delivering fast, reliable overcurrent and short-circuit protection for the most demanding industrial and commercial applications.
Within the acclaimed Schneider Electric iC65N Series, the 1P C1A variant occupies a specialized niche: it is purpose-built for circuits requiring ultra-low rated current (1A) with a standard C-curve tripping characteristic, making it ideal for protecting sensitive instrumentation, control circuits, and low-power automation loads. The iC65N series is one of the most widely deployed MCB families globally, recognized for its compliance with IEC 60898-1 and IEC 60947-2 standards and trusted by panel builders and OEMs across Europe, Asia, and the Americas.
Technical Specifications
- Model / SKU: iC65N 1P C1A
- Brand: Schneider Electric
- Series: iC65N
- Poles: 1P (Single Pole)
- Rated Current (In): 1A
- Tripping Curve: C-Curve (trips at 5–10× In)
- Breaking Capacity (Icn): 6kA @ 230/400V AC
- Rated Voltage: 230/400V AC
- Frequency: 50/60 Hz
- Standards: IEC 60898-1, IEC 60947-2
- Mounting: DIN Rail (35mm)
- Terminal Type: Tunnel-type screw terminals
- Degree of Protection: IP20 (terminals IP40 with cover)
- Operating Temperature: -25°C to +70°C
- Weight: Approx. 95g
Key Features & Benefits
- Dual Protection: Provides both thermal-magnetic overload and instantaneous short-circuit protection in a single compact device.
- C-Curve Precision: The C-curve characteristic (5–10× In) is optimized for general industrial loads and resistive/slightly inductive circuits, minimizing nuisance tripping.
- High Breaking Capacity: 6kA Icn ensures reliable interruption of fault currents in most industrial distribution networks.
- DIN Rail Mounting: Snap-on 35mm DIN rail installation enables fast panel assembly and replacement.
- Compact 1P Design: Single-pole format saves panel space while delivering full protection for single-phase circuits.
- IEC Certified: Full compliance with IEC 60898-1 and IEC 60947-2 ensures global acceptance and regulatory compliance.
- Accessory Compatible: Supports a full range of Schneider iC65 accessories including auxiliary contacts, alarm contacts, and shunt trips.
- Long Service Life: Rated for 20,000 mechanical operations and 10,000 electrical operations at rated current.
Industry & Equipment Applications
- Industrial Automation: Protection of PLC power supply circuits, I/O modules, and 24VDC control circuits in manufacturing plants.
- Building Automation (BAS/BMS): Circuit protection for HVAC controllers, lighting control panels, and access control systems.
- Machine Tool Industry: Safeguarding CNC machine control circuits, servo drive auxiliary supplies, and operator panel feeds.
- Process Industry: Protection of instrumentation loops, transmitter power supplies, and field device circuits in oil & gas, chemical, and water treatment plants.
- Renewable Energy: Auxiliary circuit protection in solar inverter panels and wind turbine control cabinets.
- Commercial Buildings: Final circuit protection in distribution boards for lighting and small power circuits.
System Integration & Compatible Parts
The Schneider iC65N 1P C1A integrates seamlessly within the broader Acti9 / iC65 ecosystem. Compatible accessories and related components include:
- Auxiliary Contact: OF / SD / SDV auxiliary contact blocks for remote status monitoring
- Shunt Trip: MX voltage release for remote tripping
- Undervoltage Release: MN release for automatic tripping on voltage loss
- Residual Current Device: Vigi iC65 RCD add-on blocks for earth fault protection
- Busbar Systems: Acti9 comb busbars for multi-pole distribution
- Enclosures: Schneider Pragma and Kaedra distribution board ranges
Our Quality Assurance Process
At Konmask.com, every Schneider Electric product we supply undergoes a rigorous multi-stage verification process:
- Source Verification: Products are sourced exclusively from authorized distributors and verified supply chains to eliminate counterfeit risk.
- Visual Inspection: Each unit is inspected for correct labeling, catalog number, date codes, and packaging integrity.
- Documentation: Full traceability documentation including certificates of conformity and test reports available upon request.
- Secure Packaging: Anti-static and shock-resistant packaging ensures products arrive in perfect condition.
How to Order
- Submit your inquiry via the Contact Us form or email [email protected].
- Provide your required quantity, delivery destination, and any special requirements (e.g., certificates, urgent delivery).
- Receive a formal quotation within 24 business hours.
- Confirm order and arrange payment via T/T, L/C, or other agreed terms.
- Shipment arranged via DHL, FedEx, UPS, or sea freight — with full tracking provided.
Why Choose Konmask.com?
- ✅ Specialized in Industrial Automation Components — PLC modules, MCBs, drives, sensors, and more from leading global brands.
- ✅ Anti-Counterfeit Guarantee — Verified supply chain with full traceability documentation.
- ✅ Fast Global Shipping — Express and sea freight options to 50+ countries.
- ✅ B2B Inquiry-Friendly — Flexible MOQ, volume pricing, and OEM support available.
- ✅ Technical Support — Our engineering team can assist with product selection, compatibility checks, and application advice.
- ✅ Responsive Service — Dedicated account managers for repeat buyers and project procurement teams.
Frequently Asked Questions
Q: What is the difference between iC65N and iC65H?
A: The iC65N has a standard breaking capacity of 6kA (Icn), while the iC65H offers a higher breaking capacity of 10kA. Choose iC65H for installations with higher prospective short-circuit currents.
Q: Is the iC65N 1P C1A suitable for DC circuits?
A: The standard iC65N is rated for AC circuits. For DC applications, Schneider offers specific DC-rated variants. Please contact us to confirm suitability for your application.
Q: Can I add an RCD module to this MCB?
A: Yes. The Vigi iC65 RCD add-on block is compatible with the iC65N range, enabling earth fault protection without replacing the MCB.
Q: What does the C-curve mean for my application?
A: C-curve MCBs trip instantaneously at 5–10 times the rated current. This is suitable for general loads including resistive heaters, lighting, and slightly inductive loads. For motors with high inrush currents, a D-curve MCB may be more appropriate.
Q: Do you provide a certificate of conformity?
A: Yes. Certificates of conformity and test reports are available upon request for all Schneider Electric products supplied by Konmask.com.
Q: What is the minimum order quantity (MOQ)?
A: We support single-unit inquiries as well as bulk orders. Contact us for volume pricing on larger quantities.
