SCHNEIDER VX4A1104 Control Line Terminal Board | Replacement, Equivalent & Selection Guide
The Schneider Electric VX4A1104 is a dedicated Control Line Terminal Board designed for use with Schneider Altivar ATV71 and ATV61 series variable frequency drives. It provides a structured wiring interface for control signal connections, enabling clean, reliable integration in industrial automation panels. This page covers full technical specifications, compatible replacement models, application scenarios, and a structured selection guide to help engineers and procurement teams make confident sourcing decisions.
Technical Specifications
- Part Number: VX4A1104
- Manufacturer: Schneider Electric
- Product Type: Control Line Terminal Board / Wiring Accessory
- Compatible Drive Series: Altivar ATV71 / ATV61
- Function: Provides organized terminal connections for control wiring on VFD panels
- Weight: Approx. 360 g
- Mounting: Panel / DIN rail compatible (drive-specific mounting)
- Operating Environment: Industrial; suitable for standard drive enclosure conditions
- Compliance: CE marked; meets Schneider Electric quality standards
Compatible Replacement & Equivalent Models
When the VX4A1104 is unavailable or discontinued, the following models may serve as functional equivalents or replacements depending on your drive configuration. Always verify compatibility with your specific drive firmware and panel layout before substitution.
- VX4A1104 – Original Schneider Electric part (this listing)
- VW3A3101 – Schneider Altivar control card terminal block (verify pinout compatibility)
- VX4A1204 – Higher-capacity terminal board for larger ATV71 frames
- Generic DIN Terminal Boards – Third-party equivalents (Phoenix Contact, Weidmüller) may be adapted with custom wiring harnesses; engineering review required
- OEM Replacement Boards – Contact Konmask for sourced OEM-equivalent options with verified compatibility
Note: Konmask.com stocks both original Schneider parts and verified-compatible alternatives. Contact us for cross-reference confirmation.
Why Choose the Original Model
- Guaranteed Fit: Designed specifically for ATV71/ATV61 drive housings — no adaptation required
- Signal Integrity: Factory-matched terminal layout ensures correct control signal routing without re-engineering
- Warranty Compliance: Using OEM parts preserves Schneider Electric drive warranty coverage
- Reduced Commissioning Risk: Eliminates wiring errors common with generic substitutes
- Long-Term Support: Schneider Electric provides documentation, firmware compatibility, and spare parts support for original accessories
Typical Applications
- Variable frequency drive (VFD) panel wiring and commissioning
- Motor control center (MCC) builds using Altivar ATV71/ATV61 drives
- Industrial conveyor, pump, fan, and compressor control systems
- HVAC automation panels requiring structured control wiring
- OEM machine builders integrating Schneider Altivar drives into custom equipment
- Retrofit and upgrade projects replacing older drive accessories
System Compatibility
| Drive Series | Compatible | Notes |
|---|---|---|
| Altivar ATV71 | ✅ Yes | Primary compatible platform |
| Altivar ATV61 | ✅ Yes | Verify frame size before ordering |
| Altivar ATV312 | ⚠️ Check | Different terminal layout; consult datasheet |
| Altivar ATV320 / ATV340 | ❌ No | Newer platform; different accessory ecosystem |
| Lexium / Modicon | ❌ No | Not applicable |
Selection Guide
Use the following criteria to confirm the VX4A1104 is the correct part for your application:
- Step 1 – Confirm Drive Model: Verify your drive is an ATV71 or ATV61 series. Check the nameplate on the drive enclosure.
- Step 2 – Check Frame Size: VX4A1104 is rated for specific frame sizes. Cross-reference with Schneider’s accessory catalog (document reference: ATV71 Installation Manual).
- Step 3 – Assess Wiring Requirements: Count the number of control signal terminals needed. If your application requires expanded I/O, consider the VX4A1204 or an I/O expansion card.
- Step 4 – Evaluate Replacement vs. Original: For warranty-sensitive or safety-critical installations, always use the original VX4A1104. For cost-sensitive retrofits, contact Konmask for verified alternatives.
- Step 5 – Confirm Stock & Lead Time: Contact support@konmask.com with your quantity and delivery requirements for availability confirmation.
Quality Assurance & Sourcing
- All parts sourced through authorized distribution channels or verified OEM supply chains
- Each unit inspected for physical integrity and label authenticity prior to dispatch
- Traceability documentation available upon request (batch records, COO certificates)
- Anti-counterfeit verification available for critical procurement
- Konmask.com specializes in industrial automation components for B2B buyers — we understand spec accuracy matters
How to Order
- Online: Add to cart directly from this page
- Email: support@konmask.com — include part number, quantity, and delivery location
- Phone / WhatsApp: +0086 19859288691
- Bulk / Project Orders: Request a formal quotation with lead time and packaging details
- Payment: T/T, PayPal, and other B2B payment methods accepted
Replacement & Compatibility FAQ
Q: Can I use a generic terminal board instead of the VX4A1104?
A: Technically possible with custom wiring, but not recommended for warranty-covered or safety-rated installations. Contact us for verified alternatives.
Q: Is the VX4A1104 still in production?
A: Schneider Electric periodically updates accessory availability. Contact Konmask for current stock status and any superseding part numbers.
Q: What is the difference between VX4A1104 and VX4A1204?
A: The VX4A1204 is designed for larger ATV71 frame sizes and offers additional terminal capacity. Confirm your drive frame size before selecting.
Q: Do you provide installation documentation?
A: Yes. Schneider Electric installation manuals and wiring diagrams are available upon request. Contact support@konmask.com.
Q: Can Konmask source discontinued Schneider parts?
A: Yes. We maintain access to legacy inventory and can source discontinued parts through our supplier network. Inquire with your part number and quantity.
