Semikron SKKT106/16E Dual Thyristor Module | Replacement, Equivalent & Selection Guide
The Semikron SKKT106/16E is a high-performance dual thyristor (SCR) module designed for industrial AC/DC power conversion, motor drives, and rectifier applications. This page provides complete technical specifications, compatible replacement models, equivalent alternatives, and a structured selection guide to help engineers and procurement teams make confident sourcing decisions.
Technical Specifications
- Part Number: SKKT106/16E
- Manufacturer: Semikron (Germany)
- Module Type: Dual Thyristor (SCR) Module
- Configuration: Common Cathode (2× SCR)
- Repetitive Peak Off-State Voltage (VDRM/VRRM): 1600 V
- Average On-State Current (IT(AV)): 106 A
- Peak One-Cycle Surge Current (ITSM): 2200 A
- Gate Trigger Current (IGT): ≤ 150 mA
- On-State Voltage (VT): ≤ 1.75 V @ IT = 150 A
- Operating Temperature (Tj): −40°C to +125°C
- Mounting: Base plate, screw terminals
- Package: SEMIPACK® 1 (compatible footprint)
- Country of Origin: Germany
Compatible Replacement & Equivalent Models
The following models are electrically equivalent or functionally interchangeable with the SKKT106/16E. Always verify pinout, package dimensions, and voltage class before substitution.
- Semikron SKKT106/14E — Same current rating, 1400 V class (lower voltage grade)
- Semikron SKKT106/18E — Same current rating, 1800 V class (higher voltage grade)
- Semikron SKKT132/16E — Higher current (132 A), same voltage, same package — uprated replacement
- Vishay VS-VSKT106-16PBF — Direct cross-reference, SEMIPACK® 1 footprint compatible
- Infineon TT106N16KOF — Equivalent dual SCR, 106 A / 1600 V, compatible mounting
- IXYS MCC132-16IO1 — Functional equivalent, verify gate drive requirements
- Powerex T6300016 — Cross-reference for 106 A / 1600 V dual thyristor modules
Note: Cross-reference data is provided for reference only. Konmask.com recommends engineering validation before field replacement.
Why Choose the Original Semikron SKKT106/16E
- ✅ Proven reliability — Semikron SEMIPACK® series is an industry standard for 30+ years
- ✅ Tight parameter tolerance — Consistent VT and IGT across production batches
- ✅ Optimized thermal interface — Base plate design for direct heatsink mounting
- ✅ Wide availability — Stocked globally; long product lifecycle support
- ✅ Full datasheet traceability — Semikron-certified documentation available
Typical Applications
- Three-phase AC/DC rectifier bridges
- DC motor speed control drives
- Soft starters and AC power controllers
- UPS and battery charging systems
- Welding power supplies
- Industrial heating and temperature control
- Crane and hoist drive systems
System Compatibility
The SKKT106/16E is compatible with the following drive and control platforms when used as a rectifier or phase-control element:
- Siemens SIMOREG DC-MASTER series
- ABB DCS800 / DCS550 DC drives
- Eurotherm 590+ / 690+ series
- Schneider Electric ATV61 / ATV71 (rectifier stage)
- Custom-built SCR firing board systems using standard gate pulse ≥ 150 mA / 1.5 V
Selection Guide
Use the table below to select the correct SKKT module for your application:
| Parameter | SKKT106/14E | SKKT106/16E ✓ | SKKT106/18E | SKKT132/16E |
|---|---|---|---|---|
| IT(AV) | 106 A | 106 A | 106 A | 132 A |
| VDRM/VRRM | 1400 V | 1600 V | 1800 V | 1600 V |
| Recommended Use | 380 V AC systems | 380–480 V AC ✓ | High-line 480 V+ | Uprated current |
| Package | SEMIPACK® 1 | SEMIPACK® 1 | SEMIPACK® 1 | SEMIPACK® 1 |
Rule of thumb: Select VDRM ≥ 2× peak line voltage. For 380 V AC (537 V peak), SKKT106/16E (1600 V) provides a safe 3× derating margin.
Quality Assurance & Sourcing
- 🔍 Authenticity verification — All units sourced from authorized distributors or OEM-certified channels
- 📦 Original packaging — Shipped in Semikron OEM packaging with date code and lot traceability
- 🧪 Pre-shipment testing — Electrical parameters verified before dispatch
- 📄 Documentation — Certificate of conformance and datasheet available on request
- 🌍 Global shipping — DHL / FedEx express available; EXW Xiamen, China
How to Order
- Confirm part number: SKKT106/16E (Semikron)
- Specify quantity required
- Add to cart or contact us for bulk pricing and lead time
- For urgent requirements, email support@konmask.com with your PO or RFQ
- Payment: T/T, PayPal, credit card via Shopify Payments
Replacement & Compatibility FAQ
Q: Can I replace SKKT106/16E with SKKT132/16E?
A: Yes — the SKKT132/16E is an uprated replacement with higher current capacity (132 A vs 106 A) in the same SEMIPACK® 1 package. It is a safe drop-in upgrade.
Q: Is the Vishay VS-VSKT106-16PBF a direct replacement?
A: Yes — it shares the same footprint, voltage class, and current rating. Verify gate trigger current compatibility with your firing board.
Q: What is the difference between SKKT106/16E and SKKT106/16?
A: The “E” suffix denotes an enhanced or export-grade variant with tighter parameter screening. Functionally interchangeable in most applications.
Q: Do you supply original Semikron or compatible alternatives?
A: Konmask.com primarily supplies original Semikron-branded modules. Compatible alternatives are available upon request — please specify in your inquiry.
Q: Can I get a datasheet for SKKT106/16E?
A: Yes — contact support@konmask.com and we will provide the official Semikron datasheet.
