Siemens 6ES7134-4FB00-0AB0 – 2-Channel Analog Input Module | ET 200S / SIMATIC S7 Platform
Engineering Background: The ET 200S distributed I/O system is Siemens’ flagship modular field-level solution, designed for high-density, cabinet-mounted installations in process and factory automation. The 6ES7134-4FB00-0AB0 is a 2-channel analog input module within this family, engineered to acquire voltage and current signals from field transmitters with 12-bit resolution and deliver them reliably to the SIMATIC S7-300/400 or S7-1500 controller via PROFIBUS DP or PROFINET.
Product Positioning: This module targets applications where precise analog measurement is critical — process control loops, drive feedback, sensor integration, and quality monitoring systems. Its compact DIN-rail footprint and hot-swap capability make it ideal for high-availability production environments where downtime is not an option.
Complete Technical Specifications
- Order Number (MLFB): 6ES7134-4FB00-0AB0
- Series / Platform: SIMATIC ET 200S
- Module Type: Analog Input (AI)
- Number of Channels: 2 (differential)
- Input Ranges (Voltage): ±10 V, ±5 V, ±2.5 V, 1–5 V, 0–10 V
- Input Ranges (Current): ±20 mA, 0–20 mA, 4–20 mA
- Resolution: 12 bits + sign
- Conversion Time per Channel: ≥ 2 ms (basic cycle)
- Supply Voltage: 24 V DC (via ET 200S power module)
- Current Consumption: Approx. 60 mA at 24 V DC
- Isolation: Galvanic isolation between channels and backplane bus
- Permissible Input Voltage (Overvoltage): ±35 V continuous
- Dimensions (W × H × D): 15 mm × 81 mm × 52 mm
- Weight: Approx. 50 g (module only)
- Operating Temperature: 0 °C to +60 °C
- Storage Temperature: −40 °C to +70 °C
- Degree of Protection: IP20
- Mounting: DIN rail via ET 200S terminal module (TM-E)
- Compatible Controllers: S7-300, S7-400, S7-1500 (via IM 151-x interface module)
- Communication Bus: PROFIBUS DP / PROFINET (via ET 200S head station)
- Certifications: CE, UL, cULus, ATEX (Zone 2 with appropriate housing)
Proven Application Environments
- Process Industry: Temperature, pressure, and flow measurement loops in chemical, pharmaceutical, and water treatment plants using 4–20 mA transmitters
- Automotive Manufacturing: Weld force feedback, torque monitoring, and press force acquisition in body-in-white and powertrain assembly lines
- Food & Beverage: Level sensing, pH monitoring, and conveyor tension control in hygienic production environments
- Energy & Power: Generator output monitoring, transformer load sensing, and UPS battery voltage acquisition
- Machine Tool & Robotics: Servo drive analog command signals, spindle load feedback, and axis position reference inputs
- Building Automation: HVAC damper position feedback, chiller performance monitoring, and BMS integration via PROFIBUS
Engineering Advantages
- Hot-Swap Replacement: Modules can be replaced under power without shutting down the ET 200S station — critical for 24/7 production lines
- Flexible Signal Parameterization: Input range, smoothing, and diagnostics configured via STEP 7 / TIA Portal without hardware jumpers
- Integrated Diagnostics: Wire-break detection, overflow/underflow alarms, and supply voltage monitoring reported to the CPU in real time
- Compact 15 mm Pitch: Maximizes channel density in control cabinets — up to 63 I/O modules per ET 200S station
- Galvanic Isolation: Protects the backplane bus from field-side transients and ground loops common in industrial environments
- TIA Portal Integration: Full GSD/GSDML support with drag-and-drop hardware configuration and automatic address assignment
System Architecture & Signal Flow
Field transmitters connect to the ET 200S terminal module (TM-E15S24-01 or equivalent) via 2-wire or 4-wire connections. The 6ES7134-4FB00-0AB0 plugs into the terminal module and acquires differential analog signals, converting them to 13-bit digital values. These values are transferred via the ET 200S internal bus to the IM 151-x interface module, which forwards process data to the S7 CPU over PROFIBUS DP or PROFINET. The CPU reads the analog values as 16-bit integers in the process image input (PII) area, accessible via standard STEP 7 or TIA Portal addressing (e.g., PIW 256).
Typical BOM for a 2-Channel AI Station:
- IM 151-1 Standard (6ES7151-1AA05-0AB0) — PROFIBUS DP interface module
- PM-E 24V DC (6ES7138-4CA01-0AA0) — Power module for electronics
- TM-E15S24-01 (6ES7193-4CA40-0AA0) — Terminal module for AI module
- 6ES7134-4FB00-0AB0 — This analog input module (×2 channels)
- End module (6ES7193-4GA00-0AA0) — Bus termination
Sourcing & Quality Verification
- Origin: Germany (Siemens Amberg / Nuremberg manufacturing)
- Authenticity: Every unit sourced through authorized Siemens distribution channels or verified surplus with full traceability documentation
- Inspection Protocol: Visual inspection, label verification (MLFB, date code, firmware version), functional power-on test, and packaging integrity check before shipment
- Warranty: 12-month replacement warranty against manufacturing defects
- Lead Time: In-stock units ship within 1–3 business days; ex-stock orders confirmed within 24 hours
Procurement Process
- Submit your RFQ with quantity and required delivery date via support@konmask.com
- Receive a formal quotation with unit price, lead time, and traceability documentation within 24 hours
- Confirm purchase order — payment via T/T, PayPal, or trade credit (approved accounts)
- Shipment via DHL Express, FedEx, or UPS with full tracking and commercial invoice
- Post-delivery technical support available for integration and commissioning questions
Technical FAQ
Q: Is the 6ES7134-4FB00-0AB0 compatible with TIA Portal V17/V18?
A: Yes. The module is fully supported in TIA Portal via the ET 200S GSD file. It also remains compatible with STEP 7 V5.x for legacy projects.
Q: Can I use this module with a PROFINET head station (IM 151-3)?
A: Yes. The 6ES7134-4FB00-0AB0 is compatible with all ET 200S interface modules including IM 151-3 PN (PROFINET) and IM 151-7 CPU variants.
Q: What terminal module is required?
A: The TM-E15S24-01 (6ES7193-4CA40-0AA0) is the standard terminal module for this AI module. Ensure the terminal module is ordered separately as it is not included.
Q: Does the module support HART protocol?
A: No. The 6ES7134-4FB00-0AB0 does not support HART. For HART-enabled analog input, refer to the 6ES7134-4MB02-0AB0 (2AI HART) variant.
Q: What is the difference between 0AB0 and 0AB2 firmware versions?
A: The 0AB0 suffix denotes the base hardware revision. Functional differences between sub-revisions are documented in the Siemens product changelog (A5E00085541). Contact us if a specific firmware revision is required for your project.
