Siemens 6ES7135-6FB00-0BA1 Analog Output Module | Replacement, Equivalent & Selection Guide
The Siemens 6ES7135-6FB00-0BA1 is a 2-channel analog output module designed for the SIMATIC ET 200SP distributed I/O system. It delivers high-resolution voltage and current output signals for precise process control in industrial automation environments. This page provides full technical specifications, compatible replacement models, and a structured selection guide to help engineers and procurement teams make informed decisions.
Technical Specifications
- Part Number: 6ES7135-6FB00-0BA1
- Series: SIMATIC ET 200SP
- Module Type: Analog Output Module
- Number of Channels: 2
- Output Signal: ±10 V / 0–20 mA / 4–20 mA
- Resolution: 16-bit
- Supply Voltage: 24 V DC
- Current Consumption: Approx. 50 mA (from backplane bus)
- Isolation: Electrically isolated between channels and backplane
- Dimensions (W×H×D): 15 × 73 × 58 mm
- Weight: Approx. 60 g
- Operating Temperature: 0 °C to +60 °C
- Protection Class: IP20
- Certifications: CE, UL, cULus, ATEX (Zone 2)
- Compatible Base Unit: BU-Type A0 (6ES7193-6BP00-0BA0)
- Firmware: Configurable via TIA Portal V13 SP1 and above
Compatible Replacement & Equivalent Models
The following modules are functionally compatible or serve as direct/near-direct replacements for the 6ES7135-6FB00-0BA1 in most ET 200SP applications:
- 6ES7135-6GB00-0BA1 — Upgraded successor with enhanced diagnostics; drop-in replacement in TIA Portal V14+
- 6ES7135-6HD00-0BA1 — 4-channel variant; suitable when channel expansion is needed
- 6ES7135-6FB00-0CA0 — Earlier firmware revision; functionally equivalent for most applications
- Beckhoff EL4002 — Third-party 2-channel ±10 V analog output; requires EtherCAT infrastructure
- Phoenix Contact AXL F AO2 1H — Compatible in Axioline F systems; similar signal range
- Wago 750-556 — 2-channel analog output for WAGO I/O system; signal-compatible but requires different bus coupler
Note: Always verify firmware version, base unit compatibility, and TIA Portal project settings before substituting modules in live systems.
Why Choose the Original Model
- Guaranteed Siemens compatibility: Seamless integration with SIMATIC S7-1500, S7-1200, and ET 200SP controllers via PROFINET
- High resolution output: 16-bit DAC ensures precise analog signal control for demanding process loops
- Compact form factor: 15 mm width minimizes cabinet space in high-density installations
- Certified for hazardous areas: ATEX Zone 2 approval supports use in Ex environments
- Long-term availability: Supported under Siemens standard product lifecycle with firmware updates via TIA Portal
- Diagnostics support: Integrated channel-level diagnostics reduce troubleshooting time
Typical Applications
- Valve positioner control (4–20 mA current loop)
- Variable frequency drive (VFD) speed reference signals
- Process temperature and pressure setpoint transmission
- Proportional hydraulic valve control (±10 V)
- Conveyor and packaging line speed regulation
- Water treatment and chemical dosing systems
- Building automation and HVAC control panels
System Compatibility
- Controllers: SIMATIC S7-1500, S7-1200 (with ET 200SP IM), S7-300/400 (via IM 154-4 PN)
- Communication: PROFINET IO
- Engineering Software: TIA Portal V13 SP1 / V14 / V15 / V16 / V17 / V18 / V19
- Base Unit Required: BU-Type A0 — 6ES7193-6BP00-0BA0
- Server Module: 6ES7193-6PA00-0AA0 (required at end of ET 200SP station)
- Power Module: PM-E DC24V — 6ES7138-6CB01-0BA0 (if powering load circuits)
Selection Guide
Use the criteria below to determine whether the 6ES7135-6FB00-0BA1 is the right module for your application, or to identify a suitable alternative:
- Number of output channels needed: 2 channels → 6ES7135-6FB00-0BA1 ✓ | 4 channels → consider 6ES7135-6HD00-0BA1
- Signal type: Voltage (±10 V) or current (0/4–20 mA) → 6ES7135-6FB00-0BA1 ✓
- Resolution requirement: 16-bit → 6ES7135-6FB00-0BA1 ✓ | 13-bit sufficient → consider lower-cost alternatives
- Hazardous area (ATEX Zone 2): Required → 6ES7135-6FB00-0BA1 ✓
- Bus system: PROFINET → ET 200SP series ✓ | EtherCAT → Beckhoff EL4002 | Modbus TCP → third-party options
- Budget constraint: If cost is critical and resolution ≥13-bit is acceptable, consider 6ES7135-6FB00-0CA0 (earlier revision, often available at lower cost)
Quality Assurance & Sourcing
At Konmask.com, all Siemens modules are sourced through verified supply channels. Each unit undergoes the following before shipment:
- Visual inspection for physical damage and label authenticity
- Firmware version verification against Siemens product documentation
- Functional power-on test where applicable
- Anti-static packaging with humidity indicator card
- Certificate of conformity available upon request
We stock both new original and refurbished/tested units. Please specify your requirement when ordering.
How to Order
- Part Number: 6ES7135-6FB00-0BA1
- Minimum Order Quantity: 1 unit
- Lead Time: In-stock items ship within 1–3 business days; sourced items 5–15 business days
- Payment: T/T, PayPal, credit card, and trade assurance accepted
- Shipping: DHL / FedEx / UPS express worldwide; sea freight available for bulk orders
- Custom Quantity / OEM Inquiry: Contact us for volume pricing and project-based procurement
📧 support@konmask.com | 📞 +0086 19859288691
Replacement & Compatibility FAQ
Q: Can I replace 6ES7135-6FB00-0BA1 with 6ES7135-6GB00-0BA1 directly?
A: Yes, in most cases. The 6GB00 is the successor model with enhanced diagnostics. You will need to update the hardware configuration in TIA Portal and re-download to the controller.
Q: Is the 6ES7135-6FB00-0BA1 compatible with S7-300?
A: Not directly. ET 200SP modules require an ET 200SP interface module (e.g., IM 155-6 PN) connected via PROFINET to the S7-300 CPU.
Q: What base unit does this module require?
A: BU-Type A0 (6ES7193-6BP00-0BA0). Ensure the correct base unit is ordered alongside the module.
Q: Can this module output both voltage and current simultaneously on both channels?
A: Each channel is individually configurable for either voltage or current output, but not simultaneously on the same channel.
Q: Do you supply modules with original Siemens firmware?
A: Yes. All new units are supplied with factory-original firmware. Refurbished units are tested and firmware-verified prior to shipment.
