EMC Shielding Solution – Siemens 6ES7592-1BM00-0XB0 | SIMATIC S7-1500 Series
Where This Product Is Used
The Siemens 6ES7592-1BM00-0XB0 shield connector is deployed wherever SIMATIC S7-1500 PLCs are installed in electrically noisy industrial environments. Typical application sites include:
- Automotive assembly lines – servo drive cabinets requiring strict EMC compliance per IEC 61000
- Chemical & process plants – control panels with long cable runs susceptible to induced interference
- Water treatment facilities – remote I/O stations on DIN rails where cable shielding continuity is mandatory
- Food & beverage packaging – high-speed motion control systems with variable frequency drives (VFDs) generating conducted emissions
- Power generation & utilities – switchgear panels integrating S7-1500 CPUs with analog signal modules
- Machine tool & CNC – precision machining centers where signal integrity on encoder and analog cables is critical
Wherever engineers specify SIMATIC S7-1500 hardware and need a code-compliant, tool-free method to terminate cable shields directly on the mounting rail, the 6ES7592-1BM00-0XB0 is the OEM-specified solution.
Technical Specifications
| Parameter | Value |
|---|---|
| Siemens Order Number | 6ES7592-1BM00-0XB0 |
| Product Family | SIMATIC S7-1500 |
| Component Type | Shield Connector / Mounting Rail Accessory |
| Compatible Mounting Rail | SIMATIC S7-1500 DIN mounting rail (35 mm) |
| Cable Shield Diameter Range | Refer to Siemens datasheet (varies by sub-variant) |
| Installation Method | Tool-free snap-on to S7-1500 mounting rail |
| EMC Standard Compliance | IEC 61000-4 series, EN 55011 |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | −40 °C to +70 °C |
| Degree of Protection | IP20 (panel-mounted) |
| Weight | Approx. 100 g |
| Country of Origin | Germany |
| Siemens MLFB | 6ES7592-1BM00-0XB0 |
Why Engineers Specify This Model
- OEM-matched design – engineered exclusively for the S7-1500 rail profile; no adapters or improvised grounding straps required
- Low-impedance shield termination – direct metal-to-rail contact minimizes ground loop impedance, critical for analog and high-speed digital signals
- Tool-free installation – snap-on mechanism reduces panel build time and eliminates torque errors on shield clamps
- Repeatable EMC performance – consistent clamping force ensures shield termination meets IEC 61000 limits across production batches
- Space-efficient – mounts within the S7-1500 rail footprint without consuming additional DIN rail space
- Lifecycle alignment – part of Siemens’ active SIMATIC S7-1500 portfolio with long-term availability commitment
Complete System Bill of Materials
For a fully functional SIMATIC S7-1500 control station, engineers typically combine the 6ES7592-1BM00-0XB0 with:
- CPU module – e.g., 6ES7511-1AK02-0AB0 (CPU 1511-1 PN) or higher-spec CPUs
- Power supply module – e.g., 6EP1333-4BA00 (SITOP PSU100S 24 V)
- Digital I/O modules – e.g., 6ES7521-1BL00-0AB0 (DI 32×24VDC HF)
- Analog I/O modules – e.g., 6ES7531-7KF00-0AB0 (AI 8×U/I/RTD/TC ST)
- S7-1500 mounting rail – 6ES7590-1AB60-0AA0 (482 mm) or project-specific length
- Front connectors – 6ES7592-1AM00-0XB0 (40-pin) for I/O module wiring
- PROFINET switch – e.g., 6GK5005-0BA00-1AB2 (SCALANCE XB005) for network segmentation
Contact Konmask for bundle pricing on complete S7-1500 station builds.
Compliance & Industry Standards
- CE Marking – EU Low Voltage Directive 2014/35/EU & EMC Directive 2014/30/EU
- IEC 61131-2 – Programmable controllers: equipment requirements and tests
- IEC 61000-4-2/4/5/6 – EMC immunity requirements
- EN 55011 – Industrial, scientific, and medical equipment emissions
- UL Listed components (Siemens S7-1500 platform)
- RoHS 2 Directive 2011/65/EU compliant
- REACH regulation compliant
Quality Assurance & Sourcing
Konmask sources the 6ES7592-1BM00-0XB0 exclusively through verified Siemens authorized distribution channels and established industrial surplus networks. Every unit undergoes:
- Visual inspection – housing integrity, label legibility, and connector condition check
- Authenticity verification – Siemens hologram, MLFB label, and date code cross-reference
- Functional continuity check – shield clamp mechanism operation verified prior to dispatch
- ESD-safe packaging – anti-static bag + foam insert + outer carton for international shipping
All products ship with a Konmask inspection certificate. Traceability documentation available on request.
How to Source This Part
- Add to cart on this page and proceed to checkout — we accept T/T bank transfer, PayPal, and major credit cards
- Request a quote for quantities ≥ 5 units: email [email protected] with your project BOM
- Urgent requirement? Call or WhatsApp +0086 19859288691 for same-day stock confirmation and expedited dispatch
- OEM/EPC procurement – framework agreements and NET30 terms available for qualified accounts
Typical lead time: 1–3 business days for in-stock units. International shipping via DHL Express, FedEx, or UPS with full tracking.
Application-Specific FAQ
Q: Is the 6ES7592-1BM00-0XB0 compatible with all S7-1500 mounting rails?
A: Yes — it is designed for the standard SIMATIC S7-1500 35 mm DIN rail profile used across the entire S7-1500 CPU and I/O module range.
Q: Can I use this shield connector with S7-300 or S7-400 rails?
A: No. The 6ES7592-1BM00-0XB0 is mechanically specific to the S7-1500 rail geometry. For S7-300 applications, refer to the 6ES7390 series accessories.
Q: How many shield connectors are needed per cabinet?
A: One connector per shielded cable entering the S7-1500 station is the standard practice. For dense I/O stations with 20+ analog channels, plan accordingly and contact us for volume pricing.
Q: Does this part require any tools for installation?
A: No. The snap-on design is fully tool-free. The shield clamp screw may require a standard flat-blade screwdriver to secure the cable braid.
Q: What is the minimum order quantity (MOQ)?
A: MOQ is 1 unit. Volume discounts apply at 5, 10, and 25+ units.
Q: Can Konmask provide a Siemens certificate of conformity?
A: We provide our own Konmask inspection certificate. Original Siemens CoC is available for units sourced directly from authorized Siemens distribution — please specify at time of order.
