SIEMENS 6SL3055-0AA00-5MA0 – SINAMICS Operator Panel Adapter | SINAMICS G/S Series Platform
Engineering Background: The SIEMENS 6SL3055-0AA00-5MA0 (internal part number A5E33412837) is a dedicated operator panel interface adapter designed for the SINAMICS drive platform. It enables seamless communication between SINAMICS G120, G120C, G120D, S120, and S150 series frequency inverters and external operator panels (BOP-2, IOP, IOP-2), supporting commissioning, parameter management, and real-time diagnostics without requiring a PC or engineering workstation.
Product Positioning: Targeted at OEM machine builders, system integrators, and MRO procurement engineers who require a reliable, OEM-sourced interface component for SINAMICS drive systems. This adapter is a critical spare and commissioning tool for production lines, HVAC systems, pump/fan applications, and conveyor automation.
Complete Technical Specifications
- Manufacturer: Siemens AG
- Order Number (MLFB): 6SL3055-0AA00-5MA0
- Internal Part No.: A5E33412837
- Product Family: SINAMICS Drive System Accessories
- Compatible Platforms: SINAMICS G120, G120C, G120D, G120P, S120, S150
- Compatible Operator Panels: BOP-2, IOP, IOP-2
- Interface Type: Operator Panel Adapter / HMI Interface Module
- Mounting: Direct plug-in to Control Unit (CU) slot
- Communication Protocol: USS / PROFIBUS-compatible panel interface
- Supply Voltage: Powered via Control Unit backplane (no external supply required)
- Operating Temperature: -10 °C to +60 °C
- Storage Temperature: -40 °C to +70 °C
- Protection Class: IP20 (when installed in drive enclosure)
- Weight: Approx. 5,500 g (packaged)
- Country of Origin: Germany / China (Siemens manufacturing)
- RoHS Compliance: Yes
- CE Marking: Yes
Proven Application Environments
- Variable speed pump and fan control systems (HVAC, water treatment)
- Conveyor and material handling automation lines
- Compressor and blower drive systems
- OEM machine tool and packaging equipment
- Process industry: chemical, pharmaceutical, food & beverage
- Building automation and energy management systems
- MRO replacement for existing SINAMICS G/S series installations
Engineering Advantages
- Plug-and-Play Integration: Direct CU slot mounting — no wiring or additional hardware required
- Parameter Cloning: Supports parameter upload/download between drive and operator panel for rapid commissioning and backup
- On-Site Diagnostics: Real-time fault code display and parameter adjustment without PC/software
- Multi-Drive Compatibility: Single adapter supports the full SINAMICS G/S product range, reducing spare parts inventory complexity
- OEM Quality: Manufactured to Siemens AG production standards with full traceability
System Architecture & Signal Flow
The 6SL3055-0AA00-5MA0 adapter interfaces directly with the SINAMICS Control Unit (CU230P-2, CU240B-2, CU240E-2, CU250S-2, etc.) via the dedicated HMI port. The operator panel connects to the adapter’s front-facing RJ45/panel connector, establishing a bidirectional serial communication link. Parameter data, fault logs, and drive status are transmitted in real time, enabling full drive management from the panel without PLC or SCADA involvement.
Signal path: Operator Panel → 6SL3055-0AA00-5MA0 Adapter → SINAMICS Control Unit → Power Module
Sourcing & Quality Verification
- All units sourced from authorized Siemens distribution channels or verified OEM surplus
- Each unit inspected for physical integrity, label authenticity, and connector condition prior to dispatch
- Batch traceability maintained — date codes and serial numbers recorded
- Anti-counterfeit verification available upon request (hologram, QR trace)
- 30-day return policy for DOA (Dead on Arrival) units with documented evidence
Procurement Process
- Confirm compatibility: verify your SINAMICS Control Unit model and operator panel type
- Submit RFQ or place order directly via Konmask.com product page
- Receive order confirmation and estimated lead time within 1 business day
- Shipment with tracking number provided; DHL / FedEx / SF Express available
- Technical support available pre- and post-delivery via email or WhatsApp
Technical FAQ
Q: Is 6SL3055-0AA00-5MA0 compatible with SINAMICS G120C?
A: Yes. The adapter is compatible with SINAMICS G120C Control Units. Verify the CU variant supports external panel connection (some compact variants have integrated panels).
Q: Can this adapter be used to clone parameters between two drives?
A: Yes. Using the BOP-2 or IOP panel connected via this adapter, parameters can be uploaded from one drive and downloaded to another of the same type.
Q: What is the difference between 6SL3055-0AA00-5MA0 and 6SL3055-0AA00-4BA0?
A: The 5MA0 variant is the operator panel adapter/interface module, while 4BA0 refers to a different accessory class. Always cross-reference the MLFB against your drive’s accessory compatibility list in the SINAMICS hardware installation manual.
Q: Do you provide a certificate of conformity?
A: Yes, upon request. Please contact [email protected] with your order number.
