SIEMENS 6SL3351-6GE32-1AA1 – Control Interface Board | SINAMICS S120 Platform
Engineering Background
The SIEMENS 6SL3351-6GE32-1AA1 is a factory-original Control Interface Board engineered for the SINAMICS S120 modular drive platform — Siemens’ flagship multi-axis servo and vector drive system deployed across precision manufacturing, robotics, CNC machining, and heavy process automation. This board serves as the critical communication and control bridge between the drive’s power electronics and the higher-level automation controller (PLC/CNC), enabling deterministic real-time signal exchange and closed-loop drive management.
Product Positioning
Designed for OEM machine builders, system integrators, and MRO procurement teams requiring a verified, drop-in replacement or new-build component. The 6SL3351-6GE32-1AA1 maintains full backward compatibility within the S120 chassis ecosystem and is sourced directly from authorized Siemens distribution channels, ensuring genuine firmware revision and quality traceability.
Complete Technical Specifications
- Part Number (MLFB): 6SL3351-6GE32-1AA1
- Product Family: SINAMICS S120
- Component Type: Control Interface Board (CIB)
- Manufacturer: Siemens AG, Germany
- Drive Platform Compatibility: SINAMICS S120 Booksize / Chassis format
- Communication Interface: DRIVE-CLiQ (Digital Drive Link with iQ)
- Control Voltage: 24 V DC (via DRIVE-CLiQ or external supply)
- Digital Inputs/Outputs: Per S120 CU320-2 / CU310-2 topology
- Encoder Interface: Supports HTL, TTL, SSI, EnDat 2.1/2.2, Resolver
- Fieldbus Support: PROFIBUS DP / PROFINET IO (topology-dependent)
- Ambient Operating Temperature: 0 °C to +55 °C
- Storage Temperature: -40 °C to +70 °C
- Protection Class: IP20
- Weight: approx. 300 g
- Compliance: CE, UL, cUL, RoHS
- HS Code: 8537.10
- Country of Origin: Germany
Proven Application Environments
- CNC machining centers and multi-axis servo systems (SINUMERIK integration)
- Automotive body-in-white welding and press lines
- Packaging and labeling machinery with high-speed positioning
- Textile, printing, and converting lines requiring synchronized multi-axis control
- Crane, hoist, and material handling systems
- Pump and compressor stations with variable-speed drive requirements
- MRO replacement in existing SINAMICS S120 installations
Engineering Advantages
- DRIVE-CLiQ Native: Plug-and-play topology recognition — no manual parameterization of encoder or motor data when used with DRIVE-CLiQ-enabled motors
- Isochronous Real-Time: Supports PROFINET IRT for cycle times down to 250 µs, critical for high-dynamic servo applications
- Integrated Safety: Compatible with SINAMICS Safety Integrated (SIL 2 / PLe) functions including STO, SS1, SLS, SDI
- Scalable Architecture: Single board supports multiple drive axes within the S120 chassis, reducing panel footprint
- Firmware Traceability: Each board ships with Siemens factory firmware; version upgradeable via STARTER / TIA Portal Startdrive
System Architecture & Signal Flow
Within the SINAMICS S120 architecture, the 6SL3351-6GE32-1AA1 Control Interface Board interfaces between the Control Unit (CU320-2 DP/PN) and the Motor Module (power stage) via the internal DRIVE-CLiQ ring. It handles:
- Encoder feedback acquisition and processing (position, speed, temperature)
- Current and voltage actual-value conditioning for the closed-loop current controller
- Safe Torque Off (STO) hardware signal routing
- Status and fault signal relay to the Control Unit
- Internal 24 V DC power distribution to interface electronics
Signal latency through the board is deterministic at the DRIVE-CLiQ cycle rate (typically 125 µs or 250 µs), ensuring no jitter-induced positioning errors in servo applications.
Sourcing & Quality Verification
- Origin: Authorized Siemens distribution channel — genuine OEM part
- Inspection: Each unit undergoes incoming inspection including visual, label authenticity, and functional continuity checks
- Packaging: Ships in original Siemens ESD-protective packaging with factory seal intact
- Documentation: Certificate of conformity and packing list provided on request
- Warranty: 12-month Konmask warranty against manufacturing defects; Siemens OEM warranty terms apply where applicable
- Counterfeit Risk: All units verified against Siemens MLFB database; serial number traceable to factory batch
Procurement Process
- Confirm compatibility: Verify your SINAMICS S120 chassis type and Control Unit variant (CU320-2 DP or PN) against the 6SL3351-6GE32-1AA1 compatibility matrix
- Request quote: Contact support@konmask.com for volume pricing, lead time, and export documentation
- Place order: Add to cart and complete checkout — or submit a purchase order via email for B2B net-terms arrangements
- Shipping: DHL Express / FedEx International Priority standard; sea freight available for bulk orders. Export documentation (commercial invoice, packing list, CO) included
- After-sales: Technical support available for installation commissioning queries
Technical FAQ
Q: Is the 6SL3351-6GE32-1AA1 compatible with SINAMICS S120 Chassis format drives?
A: Yes. This Control Interface Board is designed for the S120 platform. Confirm your specific Motor Module frame size and firmware version with our technical team before ordering if you have a non-standard configuration.
Q: Can this board be used as a direct replacement without re-parameterization?
A: In most cases, yes — provided the replacement board carries the same MLFB and firmware baseline. DRIVE-CLiQ auto-topology detection will recognize the board. A STARTER/Startdrive upload-download cycle is recommended after replacement to confirm parameter consistency.
Q: What is the lead time for this part?
A: In-stock units ship within 1–3 business days. For out-of-stock scenarios, typical lead time is 2–4 weeks from Siemens authorized stock. Contact us for real-time availability.
Q: Do you provide export documentation for customs clearance?
A: Yes. Commercial invoice, packing list, and certificate of origin are standard. HS Code 8537.10 applies. ECCN classification available on request for dual-use compliance.
Q: Is this part RoHS compliant?
A: Yes. The 6SL3351-6GE32-1AA1 is RoHS 2 (Directive 2011/65/EU) compliant as manufactured by Siemens AG.
