Siemens A5E42740240 – DC Link Power Supply Unit | SINAMICS Drive Platform
Engineering Background: The A5E42740240 is a Siemens OEM power unit designed for integration within the SINAMICS modular drive family. It serves as the DC bus power conditioning and supply backbone for multi-axis servo and vector drive systems deployed in precision manufacturing, process automation, and motion control environments.
Product Positioning: Engineered for procurement engineers and system integrators who require a verified, drop-in replacement or expansion module for existing SINAMICS infrastructure. This unit eliminates the need for third-party DC bus converters and ensures full compatibility with Siemens drive firmware and safety architecture.
Complete Technical Specifications
- Part Number: A5E42740240
- Manufacturer: Siemens AG
- Product Family: SINAMICS Power Unit
- Module Type: DC Link / Power Supply Unit
- Country of Origin: Germany
- Mounting: DIN Rail / Panel Mount (system-integrated)
- Cooling Method: Forced air / integrated thermal management
- Protection Class: IP20 (cabinet installation)
- Communication Interface: DRIVE-CLiQ (Siemens proprietary)
- Firmware Compatibility: SINAMICS S120 / G120 platform series
- Weight: Approx. 80 g (module only, excluding mounting hardware)
- Compliance: CE, UL, RoHS
Proven Application Environments
- Multi-axis CNC machining centers and turning/milling systems
- Servo press and stamping lines requiring synchronized DC bus sharing
- Packaging machinery with high-cycle servo indexing
- Textile and printing equipment with tension-controlled web drives
- Crane and hoist systems with regenerative braking energy recovery
- Semiconductor fab equipment requiring ultra-low ripple DC supply
- Automotive assembly line conveyors and robotic welding cells
Engineering Advantages
- OEM-Grade Reliability: Manufactured to Siemens factory specifications with full traceability — no grey-market risk.
- DC Bus Sharing: Enables energy regeneration between axes, reducing net power consumption by up to 30% in multi-axis configurations.
- DRIVE-CLiQ Integration: Plug-and-play commissioning via STARTER or TIA Portal — automatic parameter upload eliminates manual configuration errors.
- Thermal Resilience: Rated for continuous operation in ambient temperatures up to 55 °C with derating curve — suitable for non-air-conditioned industrial cabinets.
- Compact Footprint: Modular booksize form factor minimizes cabinet space while maintaining full rated output.
- Diagnostic Transparency: Integrated fault memory and LED status indicators accelerate MTTR during unplanned downtime events.
System Architecture & Signal Flow
The A5E42740240 operates as a centralized DC bus supplier within a SINAMICS booksize or chassis drive line-up. AC mains input is rectified and conditioned to a stable DC link voltage, which is then distributed to connected Motor Modules (inverters) via the shared DC bus bar. DRIVE-CLiQ communication links the Power Unit to the Control Unit (CU320-2 or equivalent), enabling real-time monitoring of DC link voltage, current draw, temperature, and fault states. The unit supports both infeed and regenerative feedback modes, making it suitable for four-quadrant drive topologies.
Sourcing & Quality Verification
- Source: Authorized distribution channels and verified OEM surplus — all units traceable to Siemens manufacturing batch records.
- Inspection: Each unit undergoes visual inspection, label verification (part number, date code, country of origin), and functional pre-shipment check.
- Packaging: Anti-static ESD bag + foam-lined carton with desiccant — compliant with IEC 61340-5-1 handling standards.
- Documentation: Certificate of conformity and test report available upon request for regulated industries.
- Warranty: 12-month replacement warranty against manufacturing defects.
Procurement Process
- Confirm Part Number: Cross-reference A5E42740240 against your BOM or existing drive cabinet label.
- Request Quote: Contact [email protected] for volume pricing, lead time, and export documentation (CO, packing list, commercial invoice).
- Place Order: Secure checkout via Konmask.com — T/T bank transfer, PayPal, and credit card accepted.
- Shipping: DHL Express / FedEx International Priority — typical transit 3–7 business days worldwide. Air freight and sea freight available for bulk orders.
- After-Sales: Technical support available via email or WhatsApp for installation and commissioning queries.
Technical FAQ
Q: Is A5E42740240 compatible with SINAMICS S120 CU320-2 DP?
A: Yes. This power unit is designed for integration within the SINAMICS S120 booksize platform and communicates natively via DRIVE-CLiQ with CU320-2 DP and CU320-2 PN control units.
Q: Can this unit replace an existing infeed module in a running system?
A: Yes, provided the DC bus voltage rating and current capacity match your existing configuration. We recommend downloading the drive project from the CU before replacement and re-uploading after commissioning the new unit.
Q: Do you provide export documentation for customs clearance?
A: Yes. We provide commercial invoice, packing list, certificate of origin, and HS code declaration (HS 8537.10) for all international shipments.
Q: What is the lead time for this part?
A: In-stock units ship within 1–2 business days. For out-of-stock items, typical lead time is 2–4 weeks. Contact us for real-time availability.
Q: Is a test report available?
A: Yes. Pre-shipment functional test reports are available upon request for quality-critical procurement.
