Genuine SIEMENS 6ES7223-1PH22-0XA8 Digital I/O Module | EM 223 S7-200 Series – Verified Source
Konmask.com is a dedicated industrial automation components supplier specializing in genuine SIEMENS PLC hardware. The 6ES7223-1PH22-0XA8 is a high-density digital combination I/O expansion module for the SIEMENS S7-200 Micro PLC family, designed for demanding discrete control applications where both input sensing and output switching are required in a compact form factor.
Technical Specifications
- Part Number: 6ES7223-1PH22-0XA8
- Module Type: Digital Combination I/O Expansion Module (EM 223)
- Compatible PLC Family: SIEMENS S7-200 (CPU 221, 222, 224, 224XP, 226)
- Digital Inputs: 16 × DC 24V sink/source inputs
- Digital Outputs: 16 × DC 24V / 0.75A transistor outputs (sourcing)
- Input Voltage Range: 20.4 – 28.8 V DC
- Output Voltage Range: 20.4 – 28.8 V DC
- Power Consumption: 5V DC bus: 160 mA; 24V DC: 80 mA (inputs)
- Isolation: Optically isolated inputs and outputs
- Dimensions (W × H × D): 71.2 × 80 × 62 mm
- Weight: Approx. 400 g
- Operating Temperature: 0 °C to +55 °C
- Storage Temperature: −40 °C to +70 °C
- Protection Rating: IP20
- Certifications: CE, UL, cUL, FM, ATEX (Zone 2)
- SIEMENS Order Number: 6ES7 223-1PH22-0XA8
Our 4-Step Quality Verification Process
Every unit shipped from Konmask.com passes through our rigorous 4-step verification protocol before dispatch:
- Step 1 – Source Authentication: All modules are procured exclusively from authorized SIEMENS distributors or verified OEM surplus channels. Supplier credentials and batch traceability documents are retained on file.
- Step 2 – Physical Inspection: Each unit undergoes visual inspection for label integrity, housing condition, connector pin alignment, and holographic seal verification against SIEMENS anti-counterfeit standards.
- Step 3 – Functional Bench Test: Modules are powered up and I/O point continuity is verified using calibrated test equipment. Firmware version and hardware revision are logged.
- Step 4 – Packaging & Documentation Check: Units are repackaged in ESD-safe materials with original or equivalent documentation. Batch number, test date, and inspector ID are recorded on the packing slip.
Key Features & Benefits
- ✅ High I/O Density: 16 DI + 16 DO in a single compact expansion slot — maximizes panel space efficiency
- ✅ Optical Isolation: Protects the CPU backplane from field-side voltage transients and noise
- ✅ Plug-and-Play Expansion: Direct bus connection to S7-200 CPU — no additional power supply required for logic
- ✅ Transistor Outputs: Fast switching, no mechanical wear — ideal for high-cycle applications
- ✅ Wide Operating Temperature: Suitable for industrial environments without additional cooling
- ✅ Genuine SIEMENS Hardware: Full manufacturer traceability, not grey-market or refurbished
Typical Applications
- Conveyor and material handling control systems
- Packaging machinery and bottling lines
- HVAC and building automation panels
- Water treatment and pump station control
- Machine tool and CNC auxiliary I/O expansion
- Food & beverage processing equipment
- OEM equipment upgrades and legacy S7-200 system expansions
Compatible System Components
- CPUs: 6ES7214-1BD23-0XB8 (CPU 224), 6ES7216-2BD23-0XB8 (CPU 226), 6ES7212-1BB23-0XB8 (CPU 222)
- Programming Cable: 6ES7901-3CB30-0XA0 (PC/PPI USB)
- Power Supply: 6EP1332-1SH43 (SITOP PSU100S 24V/5A)
- Software: STEP 7-Micro/WIN V4.0 SP9 or later
- Expansion Bus Connector: Integrated — direct side-mount to CPU or adjacent EM module
Global Sourcing & Shipping Capabilities
- Stock Location: Shenzhen, China — with partner warehouses in Hong Kong and EU
- Lead Time: In-stock orders typically ship within 1–3 business days
- Shipping Methods: DHL Express, FedEx International Priority, SF Express, EMS
- Export Documentation: Commercial invoice, packing list, certificate of origin available on request
- Customs & HS Code: HS 8537.10 — Boards, panels, consoles for electric control (≤1000V)
- Served Markets: Southeast Asia, Middle East, Europe, North America, Africa — worldwide shipping available
- Minimum Order: 1 unit; volume pricing available for orders of 5+ units
