SIEMENS 6ES7590-1AB60-0AA0 Mounting Rail | Replacement, Equivalent & Selection Guide
The SIEMENS 6ES7590-1AB60-0AA0 is a standard mounting rail designed for the SIMATIC S7-1500 PLC system. It provides the mechanical backbone for mounting CPU modules, I/O modules, and interface modules in industrial control cabinets. This page serves as a comprehensive selection, replacement, and compatibility reference for procurement engineers and system integrators.
Technical Specifications
- Part Number: 6ES7590-1AB60-0AA0
- Manufacturer: SIEMENS (SIMATIC S7-1500 Series)
- Description: Mounting Rail for S7-1500 / ET 200MP
- Rail Length: 160 mm (standard; other lengths available in the 6ES7590 series)
- Material: Aluminum alloy, silver anodized
- Mounting: Standard 35 mm DIN rail profile compatible; also supports direct panel mounting
- Compatible Systems: SIMATIC S7-1500, ET 200MP distributed I/O
- Weight: Approx. 300 g
- Protection Class: IP20 (when installed with modules)
- Operating Temperature: -40 °C to +70 °C (storage); 0 °C to +60 °C (operation)
- Standards: CE, UL, cULus
Compatible Replacement & Equivalent Models
The following models are functionally equivalent or compatible replacements for the 6ES7590-1AB60-0AA0. Always verify rail length and hole pattern before substitution.
| Part Number | Length | Notes |
|---|---|---|
| 6ES7590-1AB60-0AA0 | 160 mm | Original / This model |
| 6ES7590-1AC40-0AA0 | 245 mm | Extended rail, same series |
| 6ES7590-1AE80-0AA0 | 530 mm | Long rail for large configurations |
| 6ES7590-1AF85-0AA0 | 830 mm | Maximum standard length |
| 6ES7590-1BC00-0AA0 | 2000 mm | Cut-to-length rail |
Note: Third-party DIN rail adapters may be used for panel mounting but are not officially certified by SIEMENS for S7-1500 systems.
Why Choose the Original Model
- Guaranteed Fit: Precision-machined to SIEMENS S7-1500 module slot tolerances — no alignment issues.
- Certified Grounding: Integrated PE (protective earth) connection points meet IEC 60204-1 requirements.
- Vibration Resistance: Tested to IEC 60068-2-6 for industrial environments with mechanical shock and vibration.
- Warranty Compliance: Use of original rails preserves SIEMENS system warranty and TÜV certification.
- Long-Term Availability: Supported under SIEMENS SIMATIC lifecycle policy with guaranteed spare parts availability.
Typical Applications
- Machine tool control panels with compact S7-1500 CPU configurations
- Process automation cabinets in chemical, oil & gas, and water treatment plants
- Automotive assembly line PLC enclosures
- Building automation and HVAC control systems
- Retrofit and upgrade projects replacing S7-300/400 systems with S7-1500
- ET 200MP distributed I/O stations in field cabinets
System Compatibility
- Primary: SIMATIC S7-1500 (all CPU variants: standard, F, T, C, H)
- Primary: ET 200MP distributed I/O (IM 155-5 interface modules)
- Not Compatible: S7-300 (uses 6ES7390 series rails), S7-400 (uses 6ES7400 series racks)
- Accessory Compatibility: Works with all S7-1500 bus connectors, shielding brackets (6ES7590-1AA00-0AA0), and cable ducts
Selection Guide
Use the following criteria to select the correct mounting rail length for your S7-1500 configuration:
- Step 1 — Count modules: List all CPUs, power supplies, I/O modules, and communication modules.
- Step 2 — Calculate width: Each S7-1500 module is 25–70 mm wide. Sum total width + 20 mm clearance on each side.
- Step 3 — Select rail: Choose the next standard rail length above your calculated total (160 / 245 / 530 / 830 mm).
- Step 4 — Verify cabinet depth: Minimum cabinet depth of 210 mm required for S7-1500 with front connectors.
- Step 5 — Check grounding: Ensure PE conductor ≥ 10 mm² is connected to the rail’s grounding screw.
For configurations exceeding 830 mm, use the 2000 mm cut-to-length rail (6ES7590-1BC00-0AA0) or split into multiple rows.
Quality Assurance & Sourcing
- All units sourced from authorized SIEMENS distribution channels or verified surplus with full traceability.
- Each unit inspected for dimensional accuracy, surface finish, and grounding continuity before dispatch.
- Packaging includes original SIEMENS labeling, part number verification, and anti-static protection.
- Certificate of Conformity (CoC) available upon request for regulated industries.
- Konmask.com maintains a no-counterfeit policy — all products are verified against SIEMENS authentic part databases.
How to Order
- Online: Add to cart directly on this page. Stock availability shown in real time.
- Bulk / Project Orders: Contact support@konmask.com for volume pricing and lead time confirmation.
- Urgent Requirements: Call/WhatsApp +0086 19859288691 for same-day quotation on critical spares.
- Export Orders: We ship globally. DDP (Delivered Duty Paid) terms available for select regions.
- Payment: T/T, PayPal, credit card, and trade assurance accepted.
Replacement & Compatibility FAQ
Q: Can I use a standard 35 mm DIN rail instead of the SIEMENS 6ES7590-1AB60-0AA0?
A: Standard DIN rails lack the S7-1500 specific hole pattern and PE grounding points. Using non-SIEMENS rails may cause module misalignment and voids system warranty. The original rail is strongly recommended.
Q: Is the 6ES7590-1AB60-0AA0 compatible with S7-300 modules?
A: No. S7-300 uses a different rail series (6ES7390-1Axxxx). The S7-1500 rail is not mechanically compatible with S7-300 modules.
Q: What is the maximum number of modules I can mount on the 160 mm rail?
A: The 160 mm rail typically accommodates 1 CPU + 1 power supply, or up to 3–4 narrow I/O modules. For larger configurations, select a longer rail.
Q: Can I cut the 6ES7590-1AB60-0AA0 to a shorter length?
A: Cutting is not recommended as it may damage the anodized surface and compromise grounding integrity. Use the 2000 mm cut-to-length rail (6ES7590-1BC00-0AA0) if a custom length is required.
Q: Do you supply the mounting screws and grounding hardware?
A: Mounting hardware is typically included with the rail. Please confirm at time of order. Additional grounding kits are available separately.
