SST 5136-CN-PCI ControlNet PCI Interface Card | Replacement, Equivalent & Selection Guide
The SST 5136-CN-PCI is a ControlNet PCI bus interface card manufactured by SST (Woodhead / Molex). Designed for seamless integration into PC-based control systems, it enables reliable ControlNet communication for industrial automation environments. This page serves as a comprehensive selection and replacement guide for engineers and procurement teams evaluating the 5136-CN-PCI and its compatible alternatives.
Technical Specifications
- Part Number: 5136-CN-PCI
- Manufacturer: SST (Woodhead / Molex)
- Bus Type: PCI (32-bit, 33 MHz)
- Network Protocol: ControlNet (ANSI/ISA-S72.01)
- Node Capacity: Up to 99 nodes per network
- Data Rate: 5 Mbps
- Connector: BNC (coaxial) — dual-port redundant media support
- Operating System Support: Windows XP / 7 / 10; VxWorks; QNX
- Driver Support: RSLinx Classic, SST ControlNet API
- Operating Temperature: 0°C to 60°C
- Power Consumption: Approx. 5W (from PCI slot)
- Weight: Approx. 280 g
- Certifications: CE, UL
Compatible Replacement & Equivalent Models
When the SST 5136-CN-PCI is discontinued, unavailable, or cost-prohibitive, the following models are commonly evaluated as replacements or equivalents. Always verify firmware and driver compatibility before substitution.
| Model | Manufacturer | Bus Type | Protocol | Compatibility Notes |
|---|---|---|---|---|
| 5136-CN-PCI | SST / Molex | PCI | ControlNet | Original model — direct match |
| 1784-PCIC | Allen-Bradley / Rockwell | PCI | ControlNet | Rockwell native; RSLinx compatible; widely used alternative |
| 1784-PCICS | Allen-Bradley / Rockwell | PCI | ControlNet (Scheduled) | Scheduled messaging support; suitable for motion-critical apps |
| 5136-CN-PCIe | SST / Molex | PCIe | ControlNet | PCIe form factor upgrade; recommended for modern servers |
| CNET-PCI-1 | HMS / Anybus | PCI | ControlNet | Third-party alternative; verify driver stack compatibility |
Note: Konmask.com recommends consulting your system integrator before substituting interface cards in safety-critical or motion-control applications.
Why Choose the Original Model
- Proven Field Record: The 5136-CN-PCI has been deployed in thousands of industrial installations globally since its introduction.
- RSLinx & Studio 5000 Compatibility: Native driver support ensures plug-and-play integration with Rockwell Automation software ecosystems.
- Dual-Port Redundant Media: Built-in support for ControlNet redundant coax topology improves network resilience.
- Stable API: SST’s ControlNet API is well-documented and supported by a broad base of third-party HMI and SCADA vendors.
- Long Service Life: Industrial-grade components rated for continuous 24/7 operation in demanding environments.
Typical Applications
- PC-based ControlNet scanner / adapter nodes in Rockwell Automation architectures
- HMI and SCADA workstations requiring ControlNet connectivity
- Data acquisition systems on ControlNet networks
- Legacy system maintenance and spare-parts replacement
- Test benches and engineering development stations
- Automotive assembly lines, food & beverage processing, and utilities
System Compatibility
- PLCs: Allen-Bradley ControlLogix, CompactLogix, PLC-5 (via ControlNet bridge)
- Software: RSLinx Classic, RSNetWorx for ControlNet, Studio 5000 Logix Designer
- Operating Systems: Windows 7 / 10 (32/64-bit), VxWorks 5.x / 6.x, QNX 6.x
- Chassis: Standard PCI slot (3.3V / 5V universal keyed)
- Media: RG-6 coaxial cable with BNC connectors; ControlNet taps and repeaters
Selection Guide
Use the following criteria to determine whether the SST 5136-CN-PCI or an alternative best fits your application:
- Bus Slot Available: If your PC has only PCIe slots, consider the 5136-CN-PCIe instead.
- Software Ecosystem: For pure Rockwell environments, the 1784-PCIC may offer tighter integration. For multi-vendor or OEM applications, the SST API provides greater flexibility.
- Redundancy Requirement: Both the 5136-CN-PCI and 1784-PCIC support dual-port redundant media; confirm your topology before ordering.
- OS Requirement: For non-Windows RTOS environments (VxWorks, QNX), the SST 5136-CN-PCI with SST API is the preferred choice.
- Budget vs. Availability: New OEM stock commands a premium; Konmask.com offers verified surplus and refurbished units with full inspection reports.
Quality Assurance & Sourcing
- Verified Surplus Stock: All units sourced from traceable, documented supply chains — no grey-market or counterfeit risk.
- 4-Step Inspection: Visual inspection → functional power-on test → ControlNet communication verification → firmware version check.
- Condition Grading: New (sealed OEM), Refurbished (tested & cleaned), or Surplus (as-removed, tested) — clearly stated at time of quotation.
- Warranty: 90-day replacement warranty on all units shipped from Konmask.com.
- Documentation: Datasheet, test report, and certificate of conformance available upon request.
How to Order
-
Confirm Part Number: Verify
5136-CN-PCIagainst your existing hardware label or BOM. - Specify Quantity & Condition: Indicate required quantity and acceptable condition grade (New / Refurbished / Surplus).
- Request a Quote: Email support@konmask.com or call +0086 19859288691 with your PO details.
- Lead Time & Shipping: In-stock units ship within 1–3 business days; international DHL / FedEx / UPS available with full tracking.
- Payment: T/T (bank transfer), PayPal, and trade assurance options available for B2B orders.
Replacement & Compatibility FAQ
Q: Can the 1784-PCIC directly replace the SST 5136-CN-PCI without software changes?
A: In most RSLinx-based environments, yes — both appear as ControlNet scanner devices. However, applications using the SST ControlNet API directly will require driver migration. Consult your software vendor.
Q: Is the 5136-CN-PCI still in production?
A: SST / Molex has transitioned to PCIe-based products. The 5136-CN-PCI is available as new-old-stock (NOS) and refurbished surplus. Contact Konmask.com for current availability.
Q: Can I use this card in a PCIe slot with a PCI adapter?
A: PCI-to-PCIe passive adapters are generally not recommended for industrial interface cards due to potential IRQ and DMA conflicts. Use the 5136-CN-PCIe for PCIe platforms.
Q: What is the maximum cable length on a ControlNet segment?
A: Per ControlNet specification, coax segments support up to 1,000 m (with repeaters). The 5136-CN-PCI supports the full ControlNet physical layer specification.
Q: Do you provide a test report with each unit?
A: Yes. All units shipped from Konmask.com include a functional test report. Certificate of conformance available upon request for quality-audited orders.
