Semiconductor Fab Automation Solution – Tokyo Electron 80E Loader Station Interface | RPCON-56P Series
Where This Product Is Used
The Tokyo Electron (TEL) 80E Loader Station Interface (P/N 208-501035-6 / 281-501035-7) is a critical communication and control bridge deployed in semiconductor wafer fabrication environments. It is specifically engineered for integration within TEL’s 80E platform — a widely adopted cluster tool architecture used in front-end-of-line (FEOL) and back-end-of-line (BEOL) processes.
- 300mm Wafer Fab Lines – Interfaces the loader station with process modules in high-throughput CVD, PVD, and etch systems.
- EFEM / Atmospheric Transfer Modules – Coordinates FOUP loading, wafer mapping, and robot handoff sequences.
- GOT1000 HMI Systems – Communicates with Mitsubishi GOT1000 series HMI panels (GT1575-VTBA) via the GT15-75QBUSL bus link unit for operator interface and diagnostics.
- Cluster Tool Automation – Acts as the RPCON-56P remote I/O controller node within the RGW-DV gateway network, enabling distributed control across multi-chamber platforms.
- Fab Maintenance & Spare Parts Programs – Stocked as a critical spare in preventive maintenance kits for TEL Trias, Tactras, and Eteris tool families.
Technical Specifications
| Manufacturer | Tokyo Electron Limited (TEL) |
| Part Number (Primary) | 208-501035-6 |
| Part Number (Alt) | 281-501035-7 |
| Module Designation | RPCON-56P |
| Gateway Type | RGW-DV |
| Compatible Platform | TEL 80E Loader Station |
| HMI Compatibility | Mitsubishi GOT1000 (GT1575-VTBA) |
| Bus Link Unit | GT15-75QBUSL |
| Function | Loader Station Interface / Remote I/O Controller |
| Weight | 800 g (approx.) |
| Condition | Used / Refurbished / New Surplus (specify on inquiry) |
| Origin | Japan |
Why Engineers Specify This Model
- Platform-Specific Design – Engineered exclusively for the TEL 80E architecture; drop-in replacement with no firmware modification required.
- Dual P/N Cross-Reference – Covers both 208-501035-6 and 281-501035-7 revision variants, simplifying procurement across tool generations.
- GOT1000 Native Integration – Pre-validated communication protocol with Mitsubishi GT1575-VTBA HMI via GT15-75QBUSL, reducing commissioning time.
- RPCON-56P Remote I/O – High-density I/O concentration reduces wiring complexity in multi-module cluster configurations.
- Proven Field Reliability – Widely deployed in Tier-1 fabs across Asia, North America, and Europe with documented MTBF performance.
Complete System Bill of Materials
This interface module is typically deployed alongside the following components. Contact Konmask for bundle pricing:
- TEL 80E Loader Station Main Controller Board
- Mitsubishi GOT1000 GT1575-VTBA HMI Panel
- Mitsubishi GT15-75QBUSL Bus Link Unit
- RGW-DV Remote Gateway Unit
- RPCON-56P Remote I/O Controller (this unit)
- TEL 80E EFEM Robot Controller
- FOUP Opener / Load Port Assembly
- Wafer Mapping Sensor Module
Compliance & Industry Standards
- SEMI E84 – Enhanced Parallel I/O Interface for Load Port / EFEM communication
- SEMI E87 – Carrier Management System (CMS) protocol compliance
- SEMI E37 (HSMS) – High-Speed Message Services for host-equipment communication
- CE / RoHS – Applicable to refurbished units re-certified for export markets
- ISO 9001 – Sourced from ISO-certified supply chain partners
Quality Assurance & Sourcing
All Tokyo Electron modules listed on Konmask.com undergo a structured verification process before dispatch:
- Visual inspection for physical damage, corrosion, and connector integrity
- Part number and revision label verification against TEL documentation
- Functional power-on test where applicable
- Anti-static packaging with humidity indicator cards
- Traceable sourcing from decommissioned fab equipment or authorized surplus channels
Condition (New Surplus / Refurbished / Used-Tested) is disclosed on each order confirmation. Custom inspection reports available on request for volume orders.
How to Source This Part
- Submit an RFQ – Email [email protected] with your tool serial number and required delivery date.
- Confirm Compatibility – Our engineers will cross-reference your TEL 80E BOM and confirm the correct revision.
- Receive Quotation – Pricing provided within 24 hours for in-stock units; 3–7 days for sourced items.
- Place Order & Ship – DHL / FedEx express worldwide. Export documentation (CO, packing list, commercial invoice) included.
Application-Specific FAQ
Q: Is 208-501035-6 interchangeable with 281-501035-7?
A: Both part numbers refer to revision variants of the same RPCON-56P interface module for the TEL 80E loader station. In most tool configurations they are functionally interchangeable, but we recommend confirming with your tool’s BOM before installation.
Q: Does this module work with TEL Trias or Tactras platforms?
A: The 80E loader station interface is primarily validated for TEL 80E-based cluster tools. Compatibility with Trias/Tactras depends on the specific tool configuration — contact us for a compatibility check.
Q: Can you supply the matching GT1575-VTBA HMI panel?
A: Yes. Konmask stocks a range of Mitsubishi GOT1000 series HMI panels and GT15-75QBUSL bus link units. Request a bundle quote for the complete loader station HMI assembly.
Q: What is the lead time for this part?
A: In-stock units ship within 1–2 business days. For sourced or refurbished units, typical lead time is 7–14 business days. Expedited sourcing available for critical fab downtime situations.
Q: Do you provide a warranty?
A: Yes. All tested units carry a 90-day functional warranty. Extended warranty and on-site support packages available for volume customers.
