TOKYO ELECTRON BB81-000009-18 – PCB ASSY Transfer Distribution Board | TEL Semiconductor Platform
Engineering Background
TOKYO ELECTRON (TEL) is one of the world’s leading semiconductor equipment manufacturers, supplying etch, deposition, and thermal processing systems to major fabs globally. The BB81-000009-18 is a factory-original PCB assembly designed for TEL’s wafer transfer and signal distribution subsystems, ensuring precise inter-module communication and power routing within the equipment chassis.
Product Positioning
This Transfer Distribution Board (part numbers 0200-14704 / 0020-44976) serves as a critical signal and power distribution node within TEL process equipment. It is sourced directly from verified TEL supply channels and is suitable for OEM replacement, preventive maintenance, and fab spare-parts inventory programs. Konmask.com specializes in B2B procurement of hard-to-source semiconductor equipment components for engineering and maintenance teams worldwide.
Complete Technical Specifications
| Attribute | Detail |
|---|---|
| Manufacturer | TOKYO ELECTRON (TEL) |
| Primary Part Number | BB81-000009-18 |
| Cross-Reference P/N 1 | 0200-14704 |
| Cross-Reference P/N 2 | 0020-44976 |
| Assembly Type | PCB Assembly (ASSY) |
| Function | Transfer Distribution Board |
| Country of Origin | Japan |
| Unit Weight | Approx. 800 g |
| Condition | New / Refurbished (specify on inquiry) |
| Compliance | RoHS-compatible; OEM-grade |
Proven Application Environments
- TEL semiconductor etch and deposition systems requiring inter-board signal distribution
- Wafer transfer module control subsystems in 200mm / 300mm fab environments
- Preventive maintenance replacement programs at high-volume fabs
- Emergency breakdown recovery for TEL equipment downtime reduction
- Spare parts inventory programs for equipment lifecycle extension
Engineering Advantages
- OEM Traceability: Part numbers BB81-000009-18 / 0200-14704 / 0020-44976 are factory-assigned TEL identifiers, ensuring direct cross-reference with TEL BOM documentation.
- Drop-in Replacement: Designed to exact OEM mechanical and electrical specifications — no field modification required.
- Signal Integrity: Engineered for stable distribution of control signals in high-EMI semiconductor process environments.
- Reduced Downtime: Stocking this board as a critical spare reduces mean time to repair (MTTR) for TEL equipment outages.
- Verified Sourcing: Konmask.com applies multi-point inspection before shipment, including visual, functional, and part-number verification.
System Architecture & Signal Flow
The BB81-000009-18 Transfer Distribution Board functions as a centralized routing node within the TEL equipment backplane. It receives control signals from the main CPU/controller board and distributes them to downstream actuator, sensor, and I/O modules within the transfer chamber or process module. Power rails are conditioned and distributed to peripheral PCBs, maintaining stable voltage levels critical for wafer handling precision. The board interfaces via standard TEL connector pinouts, compatible with the equipment’s existing wiring harness.
Sourcing & Quality Verification
- Source Verification: All units are cross-checked against TEL part number databases (BB81-000009-18, 0200-14704, 0020-44976) prior to listing.
- Inspection Protocol: Visual inspection for PCB damage, component integrity, and connector condition. Functional testing available on request.
- Packaging: ESD-safe anti-static packaging with foam cushioning for international freight.
- Documentation: Certificate of conformance and packing list provided with each shipment.
- Warranty: 90-day warranty against manufacturing defects. Contact us for extended warranty options.
Procurement Process
- Inquiry: Submit your RFQ via email or the contact form with your required quantity and delivery timeline.
- Quotation: Receive a formal quotation within 1 business day including lead time, unit price, and shipping options.
- Order Confirmation: Confirm PO; payment via T/T, PayPal, or trade finance terms for qualified accounts.
- Inspection & Dispatch: Pre-shipment inspection completed; ESD-safe packaging applied; tracking number issued.
- Delivery: DHL / FedEx / UPS express or sea freight depending on order volume and destination.
- After-Sales: Technical support and warranty claims handled by Konmask engineering team.
Technical FAQ
Q: Is BB81-000009-18 compatible with all TEL equipment models?
A: This board is designed for specific TEL platforms. Please provide your equipment model number when inquiring to confirm compatibility.
Q: What is the difference between 0200-14704 and 0020-44976?
A: Both are TEL-assigned cross-reference part numbers for the same assembly (BB81-000009-18). They may correspond to different revision or procurement catalog entries. Contact us to confirm the exact revision required.
Q: Can you provide a functional test report?
A: Yes. Functional testing and test reports are available upon request for an additional fee. Please specify this requirement in your RFQ.
Q: What is the lead time for this part?
A: Standard lead time is 3–7 business days for in-stock units. For out-of-stock items, lead time is quoted individually based on sourcing availability.
Q: Do you accept returns?
A: Returns are accepted within 30 days for unused, unopened units in original packaging. Defective units under warranty are replaced or refunded.
