TOKYO ELECTRON TYB419-1/PC PCB Assembly 30V 20A – UP-3020 Power Control Board Series
When a critical PCB assembly fails inside a Tokyo Electron semiconductor processing system, the entire production line comes to a halt. Wafer throughput drops to zero, cleanroom downtime costs mount by the minute, and engineering teams scramble to source an exact OEM-spec replacement. The TOKYO ELECTRON TYB419-1/PC PCB Assembly (P/N: 1D81-000120 / 0040-75905) is the precision power control board that keeps your UP-3020 system running without compromise — and sourcing the wrong substitute is simply not an option.
The TYB419-1/PC is a factory-specification PCB assembly rated at 30V / 20A, designed exclusively for the TEL UP-3020 platform — a workhorse power regulation module widely deployed in Tokyo Electron’s CVD, etch, and diffusion equipment lines. As one of the world’s leading semiconductor equipment manufacturers, Tokyo Electron’s proprietary board assemblies are engineered to exacting tolerances, and the TYB419-1/PC occupies a critical node in the power distribution architecture of the UP-3020 subsystem. At Konmask.com, we specialize in sourcing and supplying genuine and OEM-equivalent industrial automation components for global buyers.
Technical Specifications
- Manufacturer: TOKYO ELECTRON (TEL)
- Part Number (Primary): TYB419-1/PC
- Cross Reference P/N: 1D81-000120 / 0040-75905
- Assembly Type: PCB Assembly (Printed Circuit Board Assembly)
- Rated Voltage: 30V DC
- Rated Current: 20A
- Series / Platform: UP-3020
- Weight: 360g (approx.)
- Condition: New / Refurbished / Used — specify on inquiry
Key Features & Benefits
- OEM-Specification Design: Engineered to Tokyo Electron’s original factory tolerances for drop-in replacement without system recalibration.
- Stable 30V/20A Power Regulation: Delivers consistent power output critical for process stability in semiconductor fabrication environments.
- Multi-P/N Cross-Reference: Identified under both 1D81-000120 and 0040-75905, ensuring compatibility verification across TEL documentation systems.
- Cleanroom-Compatible Construction: PCB materials and conformal coating meet the contamination control requirements of semiconductor fab environments.
- Rapid Sourcing via Konmask.com: Dedicated B2B procurement channel with global shipping and professional pre-shipment inspection.
Industry & Equipment Applications
- Semiconductor Manufacturing: CVD (Chemical Vapor Deposition), Dry Etch, Thermal Diffusion, and ALD equipment powered by TEL UP-3020 platforms.
- Flat Panel Display (FPD) Production: TEL systems deployed in TFT-LCD and OLED panel fabrication lines.
- Advanced Packaging: Wafer-level packaging and back-end semiconductor processes utilizing TEL power subsystems.
- Research & Development Labs: University and corporate R&D facilities operating TEL equipment requiring spare parts support.
- Equipment Refurbishment: Secondary market TEL system rebuilders and certified refurbishers requiring OEM-grade PCB assemblies.
System Integration & Compatible Parts
The TYB419-1/PC PCB Assembly is designed for integration within the Tokyo Electron UP-3020 power control subsystem. When sourcing this component, buyers should also verify compatibility with associated TEL power modules, backplane connectors, and control interface boards within the same equipment generation. Konmask.com can assist with cross-referencing related TEL spare parts to support complete system restoration. Please provide your equipment model and serial number when submitting an inquiry for fastest response.
Our Quality Assurance Process
- Visual Inspection: Every unit undergoes thorough visual examination for physical damage, corrosion, and component integrity before shipment.
- Documentation Verification: Part numbers, labels, and markings are cross-checked against TEL OEM documentation to confirm authenticity.
- Functional Testing (where applicable): Refurbished units are bench-tested to verify electrical performance within rated specifications.
- Secure Packaging: Anti-static ESD packaging with foam cushioning ensures safe international transit for sensitive PCB assemblies.
- Traceability: Full sourcing documentation available upon request for regulated procurement environments.
How to Order
Konmask.com operates as a B2B inquiry-based platform. To request a quote for the TOKYO ELECTRON TYB419-1/PC PCB Assembly:
- Click the “Request a Quote” or “Contact Us” button on this page.
- Provide your required quantity, preferred condition (new/refurbished/used), and destination country.
- Our sourcing team will respond within 1 business day with availability, lead time, and pricing.
- Upon agreement, we issue a formal proforma invoice and arrange secure payment and shipment.
For urgent requirements, contact us directly at support@konmask.com or +0086 19859288691.
Why Choose Konmask.com?
- Industrial Automation Specialists: Focused exclusively on PLC, DCS, semiconductor equipment, and industrial control components — not a generalist marketplace.
- Global Sourcing Network: Access to OEM, surplus, and refurbished inventory from verified suppliers across Asia, Europe, and North America.
- B2B-First Service: Dedicated account support, volume pricing, and flexible procurement terms for industrial buyers and MRO teams.
- Fast Response: Inquiry-to-quote turnaround within 24 hours for standard requests.
- Secure Transactions: Professional export documentation, ESD-safe packaging, and insured international shipping as standard.
Frequently Asked Questions
- Q: Is the TYB419-1/PC the same as P/N 1D81-000120 or 0040-75905?
- A: Yes. TYB419-1/PC is the primary Tokyo Electron part number, while 1D81-000120 and 0040-75905 are cross-reference numbers used in different TEL documentation systems. All three refer to the same PCB assembly unit.
- Q: What equipment does the UP-3020 platform support?
- A: The UP-3020 is a power control platform used across multiple Tokyo Electron semiconductor processing systems, including CVD, etch, and thermal processing equipment. Please confirm your specific equipment model when inquiring.
- Q: Do you supply new or refurbished units?
- A: Konmask.com can source new (OEM surplus), professionally refurbished, and tested-used units depending on availability and your budget requirements. Condition is clearly stated in all quotations.
- Q: What is the lead time for this part?
- A: Lead time varies by stock availability. In-stock units typically ship within 3–5 business days. Out-of-stock items are sourced on order, with lead times communicated at the quotation stage.
- Q: Can you provide export documentation for customs clearance?
- A: Yes. We provide commercial invoices, packing lists, and certificates of origin as standard. Additional documentation can be arranged upon request.
