WESTINGHOUSE 5X00226G03 – Ovation Module | Ovation DCS Platform
Engineering Background
The Westinghouse Ovation™ Distributed Control System (DCS) is a purpose-built platform for power generation, nuclear, and process industries. Developed by Emerson (formerly Westinghouse Process Control), the Ovation architecture delivers deterministic, high-availability control across complex plant environments. The 5X00226G03 is a functional module within this ecosystem, designed to integrate seamlessly into existing Ovation controller cabinets without requiring system-wide reconfiguration.
Product Positioning
Procurement engineers sourcing replacement or expansion modules for Ovation-based plants will find the 5X00226G03 a direct, specification-matched solution. Konmask.com maintains verified stock of this module to support planned maintenance windows, emergency replacements, and capacity expansions — with full traceability documentation available on request.
Complete Technical Specifications
| Manufacturer | Westinghouse Electric / Emerson Process Control |
| Part Number | 5X00226G03 |
| Series / Platform | Ovation DCS |
| Module Type | Ovation Control / I/O Module |
| Form Factor | Rack-mount, Ovation standard card cage compatible |
| Operating Temperature | 0°C to 60°C (standard industrial range) |
| Communication Protocol | Ovation proprietary network (ONet) |
| Power Supply | Supplied via Ovation backplane (24 VDC nominal) |
| Weight | 700 g (approx.) |
| Compliance | CE, UL listed (per Ovation platform certification) |
| Condition Available | New surplus / Refurbished (tested) |
Note: Full datasheet and revision history available upon request. Contact [email protected].
Proven Application Environments
- Power Generation: Coal, gas, and combined-cycle turbine control systems running Ovation DCS
- Nuclear Plants: Balance-of-plant (BOP) control loops in nuclear facilities using Ovation architecture
- Petrochemical & Refining: Process control cabinets requiring Ovation-compatible I/O expansion
- Water & Wastewater: Large-scale treatment plants with Ovation-based SCADA integration
- Pulp & Paper / Mining: Continuous process industries with existing Ovation controller infrastructure
Engineering Advantages
- Drop-in Compatibility: Direct replacement for existing 5X00226G03 slots — no firmware re-flashing or cabinet rewiring required in standard configurations
- High Availability Design: Supports Ovation’s redundant controller architecture, enabling hot-standby failover without process interruption
- Deterministic Scan Cycle: Maintains Ovation’s real-time control loop integrity for safety-critical applications
- Long Service Life: Designed for 10+ year operational cycles typical of power and process plant environments
- Reduced Commissioning Time: Pre-tested modules ship ready for rack insertion, minimizing planned outage windows
System Architecture & Signal Flow
The 5X00226G03 operates within the Ovation controller drop architecture. Each drop consists of a controller module, I/O modules (such as this unit), and a communication interface to the Ovation Network (ONet). The module interfaces with field devices via the Ovation marshalling cabinet, with signals routed through the backplane to the controller for processing. Configuration and diagnostics are managed via the Ovation Developer Studio (ODS) engineering workstation.
Typical Signal Path: Field Device → Marshalling Terminal → Ovation I/O Module (5X00226G03) → Backplane → Ovation Controller → ONet → Operator Workstation
Sourcing & Quality Verification
- All modules undergo incoming inspection including visual, functional power-on, and communication handshake tests
- Serialized traceability records maintained for each unit
- Original manufacturer packaging preserved where available; otherwise shipped in anti-static ESD-safe packaging
- Certificate of conformance (CoC) and test report available upon request for regulated industries
- Konmask.com sources exclusively from verified industrial surplus channels and authorized distributors
Procurement Process
- Confirm Part Number: Verify 5X00226G03 against your Ovation system BOM or cabinet label
- Request Quote: Contact [email protected] with quantity and required delivery date
- Documentation Package: Request CoC, test report, and photos prior to order confirmation if required
- Order & Ship: Orders processed within 1 business day; express freight available for emergency shutdowns
- Incoming Inspection: Konmask supports third-party inspection coordination upon request
Technical FAQ
Q: Is the 5X00226G03 compatible with all Ovation controller generations?
A: The module is designed for the Ovation platform. Compatibility with specific controller revisions should be confirmed against your system’s BOM. Contact us with your controller part number for cross-reference support.
Q: Can this module be used in a redundant configuration?
A: Yes. Ovation supports redundant I/O and controller configurations. The 5X00226G03 can be deployed in redundant pairs where the system architecture supports it.
Q: What warranty is provided?
A: Konmask provides a 90-day functional warranty on all tested/refurbished modules. New surplus units carry the original manufacturer warranty terms where applicable.
Q: Do you provide installation support?
A: We provide technical documentation and pre-sales engineering consultation. On-site installation support can be arranged through our partner network — contact us for details.
Q: What is the lead time for stock items?
A: In-stock units ship within 1–2 business days. Lead time for sourced units is typically 2–4 weeks depending on availability.
