YOKOGAWA AAI143-H00 S1 16-Point Analog Input Module – CENTUM VP / CS 3000 Series
In a modern process plant, the analog input module is the nervous system of the entire control loop. When a field transmitter sends a 4–20 mA signal representing temperature, pressure, or flow, it is the analog input module that converts that raw signal into a digital value the DCS controller can act upon. Without a reliable, high-channel-density module like the AAI143-H00 S1, operators lose visibility into critical process variables — leading to unplanned shutdowns, off-spec product, and costly emergency maintenance. In refining, chemical, and power generation environments, a single failed I/O card can cascade into a full unit trip.
The YOKOGAWA AAI143-H00 S1 is a 16-channel analog input module engineered for the CENTUM VP and CS 3000 Distributed Control Systems — two of the most widely deployed DCS platforms in global process industries. Within the CENTUM I/O subsystem, the AAI143 series occupies the high-density analog input tier, offering a balance of channel count, signal accuracy, and field-proven reliability that makes it a preferred choice for brownfield expansions and greenfield projects alike. YOKOGAWA’s CENTUM platform holds a leading position in the Asia-Pacific and Middle East process automation markets, and the AAI143-H00 S1 is one of its most specified I/O modules.
Technical Specifications
- Model: AAI143-H00 S1
- Manufacturer: YOKOGAWA Electric Corporation
- Compatible Systems: CENTUM VP, CENTUM CS 3000
- Number of Channels: 16 analog input channels
- Signal Type: 4–20 mA DC (current input)
- Module Type: Analog Input (AI)
- Suffix Code H00: Standard configuration, no HART communication
- Suffix Code S1: CE marking / safety compliance variant
- Weight: Approx. 250 g
- Mounting: Node Unit / Field Control Unit (FCU) I/O slot
Note: All specifications are based on YOKOGAWA published documentation. Konmask.com does not fabricate or alter manufacturer specifications.
Key Features & Benefits
- 16-Channel Density: Maximizes I/O slot utilization in the FCU, reducing hardware footprint and cabinet space requirements.
- High Signal Accuracy: Precision A/D conversion ensures faithful representation of field transmitter signals across the full 4–20 mA range.
- Hot-Swap Capable: Supports online replacement within the CENTUM VP architecture, minimizing process interruption during maintenance.
- CE-Marked (S1 Suffix): Compliant with European electromagnetic compatibility and safety directives, suitable for global project deployment.
- Proven Field Reliability: Designed to YOKOGAWA’s stringent quality standards for continuous operation in harsh industrial environments.
- Seamless DCS Integration: Plug-and-play compatibility with CENTUM VP and CS 3000 node units — no custom configuration required at the hardware level.
Industry & Equipment Applications
- Oil & Gas: Upstream wellhead monitoring, midstream pipeline pressure/flow measurement, downstream refinery process control.
- Petrochemical & Chemical: Reactor temperature profiling, distillation column level and pressure loops.
- Power Generation: Boiler drum level, turbine inlet temperature, feedwater flow monitoring.
- Pulp & Paper: Digester pressure and temperature control loops.
- Water & Wastewater: Flow and level measurement in treatment plant control systems.
- Pharmaceuticals: GMP-compliant process monitoring in batch manufacturing environments.
System Integration & Compatible Parts
The AAI143-H00 S1 is designed to operate within the YOKOGAWA CENTUM VP and CS 3000 I/O subsystem. Typical compatible components include:
- CENTUM VP Field Control Unit (FCU) — e.g., AFV10D, AFV30D series
- Node Units — ANB10D, ANR10D series
- I/O Terminal Boards — compatible AAT141 / AAT145 series terminal assemblies
- Other AAI-series analog input modules (AAI141, AAI835) for mixed-channel configurations
- YOKOGAWA EJA/EJX series field transmitters (4–20 mA output)
Contact Konmask.com for cross-reference assistance and bill-of-materials support for your CENTUM system expansion.
Our Quality Assurance Process
- Visual Inspection: Each module is inspected for physical damage, connector integrity, and label authenticity before listing.
- Traceability Check: Serial numbers and date codes are verified against known production batches where documentation is available.
- Functional Verification: Where test equipment is available, modules undergo basic power-on and communication checks.
- Secure Packaging: Anti-static packaging with moisture barrier and shock-absorbing foam for international shipment.
- Documentation: Original manufacturer documentation and test records provided upon request.
How to Order
- Submit an inquiry via the Contact / RFQ form on this page or email support@konmask.com.
- Provide your project details: quantity required, delivery timeline, and destination country.
- Our team will respond within 1 business day with availability confirmation and a formal quotation.
- Upon PO acceptance, we arrange quality inspection, packaging, and shipment with full tracking.
We support T/T bank transfer, L/C, and other standard B2B payment terms. Export documentation (commercial invoice, packing list, COO) is provided as standard.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on DCS, PLC, and process control components — not a generalist marketplace.
- Global Sourcing Network: Access to genuine YOKOGAWA parts through verified supply channels, including surplus and new-old-stock inventory.
- Fast Response: Dedicated B2B inquiry handling with technical staff who understand your system requirements.
- Export Experience: Experienced in shipping to Southeast Asia, the Middle East, Europe, and the Americas with full customs documentation.
- Long-Term Partnership: We support ongoing MRO procurement, emergency spares, and system upgrade projects.
Frequently Asked Questions
Q: Is the AAI143-H00 S1 compatible with CENTUM CS 3000 as well as CENTUM VP?
A: Yes. The AAI143 series is designed for use in both CENTUM CS 3000 and CENTUM VP systems. Always verify the specific FCU and node unit compatibility with your system revision before installation.
Q: What does the “H00” suffix mean?
A: The H00 suffix indicates the standard analog input configuration without HART communication capability. If you require HART pass-through for smart transmitter diagnostics, please inquire about the AAI143-H50 variant.
Q: What does the “S1” suffix indicate?
A: S1 denotes CE marking compliance, indicating the module meets European EMC and safety directives. This suffix is commonly specified for projects with European regulatory requirements.
Q: Do you supply new or refurbished modules?
A: We supply both new (factory-sealed) and quality-inspected surplus modules. The condition is clearly stated in the quotation. All surplus units pass our internal QA process before shipment.
Q: Can you provide a datasheet or technical manual?
A: Yes. Please contact us with your inquiry and we will provide the relevant YOKOGAWA technical documentation.
Q: What is the lead time?
A: Lead time depends on current stock levels. In-stock items typically ship within 3–5 business days after PO confirmation. Please submit an RFQ for the most accurate availability information.
