Process Control Solution – Yokogawa ADM11T-S2 | CENTUM VP Analog Input Module
Where This Product Is Used
The Yokogawa ADM11T-S2 is a 16-channel analog input module designed for the CENTUM VP and CS 3000 Distributed Control Systems (DCS). It is widely deployed in mission-critical process industries where precise field signal acquisition is essential:
- Oil & Gas: Upstream wellhead monitoring, midstream pipeline pressure/flow measurement, downstream refinery process loops
- Petrochemical & Chemical Plants: Reactor temperature profiling, distillation column level sensing, feed-forward control loops
- Power Generation: Boiler drum level, turbine inlet temperature, flue gas O₂ monitoring
- Pulp & Paper / Water Treatment: Multi-point pH, conductivity, and flow signal aggregation into CENTUM VP controllers
- Pharmaceutical Manufacturing: FDA-regulated batch process monitoring with high-resolution analog acquisition
Technical Specifications
| Part Number | ADM11T-S2 |
| Manufacturer | Yokogawa Electric Corporation |
| Series | CENTUM VP / CS 3000 |
| Module Type | Analog Input Module (AI) |
| Number of Channels | 16 Channels |
| Input Signal Range | 4–20 mA / 1–5 V DC |
| Resolution | 16-bit A/D conversion |
| Isolation | Channel-to-channel isolation |
| Communication Bus | CENTUM VP V-net / ER Bus |
| Power Supply | Supplied via backplane (24 V DC) |
| Operating Temperature | 0°C to 55°C |
| Weight | Approx. 1,250 g |
| Mounting | CENTUM VP I/O Unit rack |
| RoHS Compliance | Yes |
Why Engineers Specify This Model
- High-density I/O: 16 analog channels per slot minimizes rack space and wiring cost in large DCS cabinets
- 16-bit resolution: Delivers ±0.1% accuracy for tight process control loops requiring fine signal discrimination
- Native CENTUM VP compatibility: Plug-and-play integration with Yokogawa Field Control Stations (FCS) — no gateway or signal converter required
- Channel isolation: Prevents ground loops and cross-channel interference in multi-transmitter field wiring scenarios
- Proven field reliability: Designed for 24/7 continuous operation in Class I hazardous-area adjacent installations
- Hot-swap capable: Supports online replacement in redundant FCS configurations, minimizing planned downtime
Complete System Bill of Materials
The ADM11T-S2 is typically specified alongside the following Yokogawa CENTUM VP components:
- AFV10D / AFV30D – Field Control Station (FCS) processor unit
- ANB10D – Node unit for I/O expansion
- ADM12T – Analog Output Module (paired for closed-loop control)
- ADV151 / ADV161 – Digital Input/Output Modules
- AIP588 – Intrinsically safe barrier terminal assembly
- CENTUM VP R6 Engineering Workstation (EWS) software license
Contact support@konmask.com for complete BOM quotations and system integration support.
Compliance & Industry Standards
- IEC 61511 – Functional Safety for Process Industry Sectors
- IEC 61508 – Functional Safety of E/E/PE Safety-related Systems
- CE Marking – EU Machinery and EMC Directives
- RoHS Directive 2011/65/EU – Restriction of Hazardous Substances
- ATEX / IECEx – Compatible with zone-rated field instruments via certified barriers
- ISA-5.1 – Instrumentation Symbols and Identification (loop documentation)
Quality Assurance & Sourcing
All Yokogawa modules supplied by Konmask.com undergo a structured quality verification process:
- Visual inspection: label integrity, connector condition, no physical damage
- Firmware version verification against Yokogawa compatibility matrix
- Functional power-on test where applicable
- Anti-static packaging with humidity indicator card
- Full traceability documentation provided on request
We source from authorized distributors, decommissioned plant inventories, and certified secondary-market channels. Counterfeit-free guarantee backed by our sourcing policy.
How to Source This Part
- Add to Cart – Proceed directly if quantity and lead time meet your requirement
- Request a Quote – Email support@konmask.com with your PO number, required quantity, and delivery deadline
- Urgent Requirement – Call/WhatsApp +0086 19859288691 for same-day stock confirmation
- System Integration Support – Our engineers can assist with CENTUM VP configuration, I/O mapping, and commissioning documentation
Application-Specific FAQ
Q: Is the ADM11T-S2 compatible with CENTUM CS 3000 as well as CENTUM VP?
A: Yes. The ADM11T-S2 is backward-compatible with CS 3000 R3 and later, and fully supported under CENTUM VP R5/R6 environments.
Q: Can this module accept thermocouple or RTD inputs directly?
A: No. The ADM11T-S2 accepts 4–20 mA and 1–5 V DC signals. For thermocouple/RTD inputs, specify the Yokogawa ADM12T or AAI141 modules with appropriate transmitter heads.
Q: What is the typical lead time for ADM11T-S2?
A: In-stock units ship within 3–5 business days internationally. For large quantities (>5 units), contact us for availability confirmation.
Q: Do you provide a warranty on this module?
A: Yes. Konmask provides a 90-day functional warranty on all modules. Extended warranty options are available upon request.
Q: Can Konmask assist with CENTUM VP system expansion projects?
A: Yes. We supply complete I/O module sets, FCS units, and engineering support for CENTUM VP brownfield expansions and migrations.
