Industrial Digital Input Solution – Yokogawa ADV157-S00 | CENTUM VP Series
Where This Product Is Used
The Yokogawa ADV157-S00 Digital Input Module is deployed across the most demanding process-control environments worldwide. Typical application sites include:
- Oil & Gas Refineries – Monitoring valve open/close status, pump run/stop signals, and emergency shutdown (ESD) discrete inputs across CENTUM VP DCS cabinets.
- Chemical & Petrochemical Plants – Acquiring 24 VDC dry-contact signals from field instruments, limit switches, and interlock relays in hazardous-area marshalling panels.
- Power Generation (Thermal & Nuclear) – Capturing turbine trip signals, breaker status, and BOP (Balance of Plant) discrete feedback in safety-critical I/O subsystems.
- Pulp & Paper / Water Treatment – High-density DI scanning for motor control center (MCC) status and process interlock logic within CENTUM VP field control stations (FCS).
- Pharmaceutical & Food Processing – cGMP-compliant discrete input acquisition for batch-process sequencing and equipment-status monitoring.
Technical Specifications
| Part Number | ADV157-S00 |
| Manufacturer | Yokogawa Electric Corporation |
| Series | CENTUM VP / CS 3000 Compatible I/O |
| Module Type | Digital Input (DI) |
| Channel Count | 32 channels |
| Input Voltage | 24 VDC (dry contact / wet contact selectable) |
| Isolation | Channel-to-channel and channel-to-bus optical isolation |
| Scan Cycle | Synchronised with FCS control cycle (min. 100 ms) |
| Backplane Bus | CENTUM VP I/O bus (node-redundancy capable) |
| Power Consumption | ≤ 3.5 W (typical) |
| Operating Temperature | 0 °C to +60 °C |
| Humidity | 10 % to 90 % RH (non-condensing) |
| Weight | Approx. 300 g |
| Mounting | CENTUM VP I/O nest (plug-in card) |
| Certifications | CE, IEC 61511 SIL 2 capable |
Why Engineers Specify This Model
- High-density 32-ch DI in a single slot reduces cabinet footprint and wiring cost versus discrete relay modules.
- Full optical isolation eliminates ground-loop interference common in large industrial plants with long cable runs.
- Hot-swap capability (with redundant I/O nest) allows module replacement without process shutdown — critical for continuous operations.
- Native CENTUM VP integration — zero configuration overhead; the FCS auto-recognises the module on insertion.
- SIL 2 suitability supports use in safety-instrumented systems (SIS) when combined with appropriate SIL-rated field devices and logic solvers.
- Long product lifecycle — Yokogawa maintains backward compatibility across CENTUM VP generations, protecting capital investment.
Complete System Bill of Materials
For a fully operational CENTUM VP digital input node, engineers typically specify:
- ADV157-S00 – Digital Input Module (this item)
- ANB10D / ANB11D – I/O Nest (8-slot or 16-slot)
- AIP835-S00 – Node Interface Unit (NIU) for I/O bus connection
- AWF10D – Field Terminal Board (FTB) for 32-ch DI wiring
- KS1-1 / KS1-2 – Marshalling cabinet power supply unit
- CENTUM VP R6.xx FCS license (software)
Contact support@konmask.com for complete BOM quotations and system integration support.
Compliance & Industry Standards
- IEC 61511 – Functional Safety: Safety Instrumented Systems (SIL 2 capable)
- IEC 61010-1 – Safety requirements for electrical equipment for measurement and control
- CE Marking – EMC Directive 2014/30/EU; Low Voltage Directive 2014/35/EU
- RoHS Compliant – Directive 2011/65/EU
- ATEX / IECEx – Consult Yokogawa for zone-rated barrier/isolator pairing requirements
Quality Assurance & Sourcing
Konmask.com sources the ADV157-S00 exclusively through authorised distribution channels and verified surplus-market partners with full traceability documentation. Every unit undergoes:
- Visual inspection against Yokogawa OEM cosmetic standards
- Label and firmware-revision verification
- Functional power-on test prior to dispatch
- Anti-static packaging with humidity indicator card
Certificates of conformance and test reports are available on request.
How to Source This Part
- In-stock orders: Add to cart and check out — same-day dispatch for orders placed before 15:00 CST.
- Bulk / project orders: Email support@konmask.com with your project BOM for volume pricing and lead-time commitment.
- Urgent / AOG requirements: Call +0086 198 5928 8691 for priority handling.
- Export / cross-border: We ship globally with full commercial invoice, packing list, and HS-code documentation for customs clearance.
Application-Specific FAQ
Q: Is the ADV157-S00 compatible with CENTUM CS 3000?
A: Yes. The ADV157-S00 is backward-compatible with CS 3000 I/O nests and FCS hardware, subject to firmware revision alignment. Contact us for compatibility matrix details.
Q: Can this module be used in a redundant I/O configuration?
A: Yes, when paired with a dual-redundant I/O nest (ANB11D) and NIU pair, the ADV157-S00 supports 1:1 I/O redundancy with bumpless switchover.
Q: What is the maximum cable length for field wiring?
A: Yokogawa specifies up to 200 m for 24 VDC dry-contact inputs using 0.5 mm² twisted-pair cable. Longer runs require signal conditioners or isolators.
Q: Does Konmask provide installation and commissioning support?
A: We provide remote technical support and can connect you with certified Yokogawa system integrators in your region. Email support@konmask.com.
Q: What warranty is provided?
A: All modules carry a 12-month warranty against manufacturing defects from the date of dispatch. Warranty claims are processed within 5 business days.
