Process Control & Safety Instrumented System Solution — YOKOGAWA ATA4S-00 S2 | CENTUM VP Series
Where This Product Is Used
The YOKOGAWA ATA4S-00 S2 is a field-proven analog I/O module deployed in mission-critical process automation environments worldwide. Engineers specify this module in:
- Oil & Gas Upstream/Midstream: FPSO vessels, wellhead control panels, and pipeline SCADA systems where SIL-rated I/O is mandatory.
- Petrochemical & Refining: Distillation column control, reactor temperature loops, and compressor surge control within CENTUM VP DCS architectures.
- Power Generation: Boiler management systems (BMS), turbine control, and grid-tie protection schemes requiring deterministic analog signal handling.
- Pulp & Paper / Chemical Plants: Continuous process lines where 4–20 mA loop integrity and redundancy are non-negotiable.
- Water & Wastewater Treatment: SCADA-integrated dosing control and pump station automation with IEC 61511 compliance requirements.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | ATA4S-00 S2 |
| Manufacturer | YOKOGAWA Electric Corporation |
| Module Type | Analog I/O Module |
| Compatible Platform | CENTUM VP / CS 3000 DCS |
| Signal Type | 4–20 mA analog (current loop) |
| Channels | 4-channel (configurable input/output) |
| Safety Rating | SIL 2 capable (IEC 61508 / IEC 61511) |
| Communication | Vnet/IP fieldbus (YOKOGAWA proprietary) |
| Power Supply | 24 VDC (from FCS power bus) |
| Operating Temperature | 0°C to +60°C |
| Humidity | 5% to 95% RH (non-condensing) |
| Weight | 900 g (approx.) |
| Mounting | Node Unit / I/O nest (hot-swap capable) |
| Firmware Revision | S2 (second-generation safety-enhanced) |
Note: Specifications are based on YOKOGAWA published datasheets. Confirm with official documentation for your specific revision.
Why Engineers Specify This Model
- S2 Safety Revision: The “-S2” suffix denotes the second-generation safety-enhanced firmware, offering improved diagnostic coverage and reduced spurious trip rates versus the base ATA4S-00.
- Hot-Swap Capability: Modules can be replaced under power without shutting down the FCS node — critical for continuous process plants with zero-downtime requirements.
- Tight CENTUM VP Integration: Native Vnet/IP communication eliminates gateway latency; the module is recognized and configured directly within YOKOGAWA’s System View engineering tool.
- Proven SIL 2 Pedigree: Certified for use in Safety Instrumented Functions (SIFs) when deployed per YOKOGAWA’s SIL implementation guidelines, reducing third-party SIL assessment costs.
- Long Product Lifecycle: YOKOGAWA’s CENTUM VP platform carries a 10+ year support commitment, protecting capital investment in brownfield and greenfield projects alike.
Complete System Bill of Materials
The ATA4S-00 S2 is typically deployed as part of a CENTUM VP Field Control Station (FCS). A representative BOM for a single FCS node includes:
- YOKOGAWA ATA4S-00 S2 — Analog I/O Module (this item)
- YOKOGAWA AFV10D / AFV30D — Field Control Unit (FCU) processor
- YOKOGAWA ANB10D — Node Unit (I/O nest / backplane)
- YOKOGAWA APS50D — Power Supply Module (redundant pair recommended)
- YOKOGAWA ACN11D — Vnet/IP Communication Module
- YOKOGAWA AER111D — Ethernet Interface Card (for HIS connectivity)
- Field terminal assemblies (FTA) — model per signal type and hazardous area classification
- Shielded twisted-pair cable (per ISA-5.1 wiring standards)
Contact Konmask for complete FCS node quotations and cross-reference assistance.
Compliance & Industry Standards
- IEC 61508: Functional Safety of E/E/PE Safety-related Systems (SIL 2 capable)
- IEC 61511: Functional Safety — Safety Instrumented Systems for the Process Industry
- ISA-5.1: Instrumentation Symbols and Identification
- CE Marking: EMC Directive 2014/30/EU compliant
- RoHS: Restriction of Hazardous Substances compliant
- ATEX / IECEx: Suitable for use with certified barriers in Zone 1/2 hazardous areas (verify FTA selection)
Quality Assurance & Sourcing
Konmask sources YOKOGAWA modules through established industrial distribution channels with full traceability. Every unit offered on Konmask.com undergoes the following before dispatch:
- Visual & Physical Inspection: Connector integrity, label authenticity, and housing condition verified against YOKOGAWA OEM standards.
- Firmware Revision Verification: S2 revision confirmed via module label and, where applicable, bench power-on self-test (POST) readout.
- Anti-Counterfeit Checks: PCB markings, holographic labels, and serial number format validated against known-genuine references.
- Packaging: ESD-safe anti-static bags, foam-lined cartons, and climate-controlled storage prior to shipment.
- Documentation: Certificate of conformance (CoC) available upon request; original YOKOGAWA datasheet included.
How to Source This Part
- Add to Cart — Click “Buy Now” or “Add to Cart” above. Stock is limited; reserve your unit today.
- Request a Quote — For quantities ≥ 2 units or project BOM requirements, email support@konmask.com with your project details for volume pricing.
- Lead Time — In-stock units ship within 1–3 business days (HK warehouse). Ex-stock orders confirmed same day.
- Export & Customs — Konmask handles HS code classification (HS 8537.10), commercial invoicing, and export documentation for international shipments.
- Technical Pre-Sales Support — Our engineers can verify compatibility with your existing CENTUM VP revision before you order. Call +0086 19859288691 or use the chat widget.
Application-Specific FAQ
Q: Is the ATA4S-00 S2 backward-compatible with CENTUM CS 3000?
A: Compatibility depends on the CS 3000 revision and FCS hardware generation. The S2 module is primarily validated for CENTUM VP R5.x and later. Contact us with your FCS model number for a definitive compatibility check.
Q: Can this module be used in a Safety Instrumented System (SIS) without a separate safety PLC?
A: Yes — when deployed within a YOKOGAWA ProSafe-RS or CENTUM VP Integrated SIS architecture and configured per YOKOGAWA’s SIL implementation manual, the ATA4S-00 S2 can form part of a certified SIF loop up to SIL 2.
Q: What is the difference between ATA4S-00 and ATA4S-00 S2?
A: The S2 revision incorporates enhanced diagnostic firmware, improved HART pass-through support, and updated safety certification documentation. For new installations, S2 is the recommended revision.
Q: Do you offer repair or refurbishment services for this module?
A: Konmask offers exchange programs for select YOKOGAWA modules. Contact support@konmask.com with your defective unit’s serial number for an exchange quote.
Q: What warranty applies to this module?
A: Konmask provides a 90-day functional warranty on all modules sold. Extended warranty and on-site commissioning support are available — inquire at time of order.
