YOKOGAWA NFTR8S-10 – 8-Channel Terminal Block Module | CENTUM VP / CS 3000 DCS Platform
Engineering Background
The NFTR8S-10 is a field-wiring terminal block module engineered by YOKOGAWA for use within its CENTUM VP and CS 3000 Distributed Control System (DCS) architectures. Designed to serve as the physical interface between field instrumentation and I/O cards, this module provides a structured, reliable, and maintenance-friendly termination point for process signals in demanding industrial environments.
Product Positioning
Targeted at process automation engineers and instrumentation specialists, the NFTR8S-10 eliminates improvised field wiring by providing a standardized, DIN-rail-mountable terminal block assembly. It is the preferred choice for greenfield DCS installations, brownfield upgrades, and spare-parts replenishment programs in refining, petrochemical, power generation, and pharmaceutical facilities.
Complete Technical Specifications
- Part Number: NFTR8S-10
- Manufacturer: YOKOGAWA Electric Corporation
- Module Type: Terminal Block Module (Field Wiring Interface)
- Compatible Platform: CENTUM VP, CENTUM CS 3000
- Channel Count: 8 channels
- Terminal Type: Screw-type, cage-clamp compatible
- Mounting: DIN rail / panel mount
- Signal Type: Analog / Digital I/O field wiring
- Weight: 190 g
- Condition: New / Refurbished (tested)
- Country of Origin: Japan
- Compliance: CE, RoHS compatible
Proven Application Environments
- Oil & Gas upstream / downstream process control
- Petrochemical and chemical plant DCS wiring panels
- Power generation (thermal, nuclear, hydro) control rooms
- Pharmaceutical batch process automation
- Pulp & paper and water treatment facilities
- Any CENTUM VP or CS 3000 I/O marshalling cabinet
Engineering Advantages
- OEM-grade compatibility: Designed and manufactured by YOKOGAWA to exact DCS I/O card specifications — no adaptation required.
- Reduced wiring errors: Numbered, color-coded terminal positions minimize mis-wiring during commissioning.
- Hot-swap friendly: Supports field replacement without full panel shutdown in supported configurations.
- Compact footprint: Optimized for high-density marshalling cabinets with minimal horizontal pitch.
- Long service life: Rated for continuous industrial duty with vibration and EMI resistance.
System Architecture & Signal Flow
In a CENTUM VP or CS 3000 system, field instruments (transmitters, actuators, switches) connect via shielded cables to the NFTR8S-10 terminal block. The module interfaces directly with the corresponding YOKOGAWA I/O card (e.g., AAI141, ADV151 series) via a dedicated ribbon or connector cable. Signals are then processed by the Field Control Station (FCS) and communicated over the Vnet/IP or ESB bus to the Human Interface Station (HIS). This architecture ensures signal integrity from field to operator display.
Sourcing & Quality Verification
- All units sourced from authorized YOKOGAWA distributors or verified OEM surplus channels.
- Each module undergoes visual inspection and functional continuity testing prior to shipment.
- Original YOKOGAWA part labels and serial numbers preserved and verified.
- Packaging: anti-static bag + foam-lined carton for international freight.
- Certificate of conformance (CoC) available upon request.
Procurement Process
- Step 1: Confirm part number NFTR8S-10 against your YOKOGAWA BOM or I/O list.
- Step 2: Contact Konmask for real-time stock confirmation and lead time.
- Step 3: Submit PO with delivery address and required quantity.
- Step 4: Receive shipment with packing list, CoC, and tracking number.
- Step 5: Inspect on arrival — 30-day return window for DOA units.
Technical FAQ
Q: Is the NFTR8S-10 compatible with CENTUM VP R6.x?
A: Yes. The NFTR8S-10 is backward and forward compatible across CENTUM VP revisions and CS 3000 systems sharing the same I/O card form factor.
Q: Can this module be used with third-party I/O cards?
A: The NFTR8S-10 is designed for YOKOGAWA I/O cards. Use with third-party cards requires custom cable adaptation and is not recommended without engineering validation.
Q: What is the lead time for bulk orders?
A: Standard stock orders ship within 3–5 business days. For bulk quantities (>10 units), contact us for a dedicated lead time quote.
Q: Do you provide installation documentation?
A: Yes. YOKOGAWA installation manuals and wiring diagrams are available upon request for registered buyers.
Q: Is a warranty provided?
A: All units carry a 90-day functional warranty. Extended warranty options available for project-based procurement.
