Predictive Maintenance Solution – Allen-Bradley 1440-TPS02-01RB | Dynamix Series
Where This Product Is Used
The Allen-Bradley 1440-TPS02-01RB Process Measurement Module is purpose-built for continuous condition monitoring in demanding industrial environments. Engineers deploy this module across a wide range of critical asset protection applications:
- Rotating Machinery Monitoring – Pumps, compressors, fans, and turbines in oil & gas, petrochemical, and power generation plants where unplanned downtime is unacceptable.
- Predictive Maintenance Programs – Integrated into plant-wide PdM strategies to detect early-stage bearing wear, imbalance, and misalignment before catastrophic failure.
- Process Variable Acquisition – Captures analog process signals (4–20 mA / voltage) alongside vibration data for unified asset health dashboards in FactoryTalk and SCADA systems.
- Conveyor & Drive Train Systems – Mining and bulk material handling operations requiring real-time speed and process measurement feedback.
- Water & Wastewater Treatment – Monitoring of high-duty-cycle pumps and blowers where maintenance access is limited and reliability is critical.
- Pharmaceutical & Food Manufacturing – Clean-room compatible monitoring of mixers, centrifuges, and filling lines under strict regulatory compliance requirements.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number (SKU) | 1440-TPS02-01RB |
| Brand | Allen-Bradley (Rockwell Automation) |
| Series | Dynamix 1440 |
| Module Type | Process Measurement Module |
| Input Channels | 2 Process Inputs |
| Input Signal Types | 4–20 mA, 0–10 VDC, ±10 VDC |
| Backplane Communication | ControlLogix / CompactLogix compatible |
| Operating Temperature | 0 °C to +60 °C (32 °F to 140 °F) |
| Storage Temperature | -40 °C to +85 °C |
| Relative Humidity | 5–95% non-condensing |
| Power Consumption | Supplied via Dynamix backplane |
| Approvals | CE, UL, cUL |
| Product Weight | Approx. 1.4 kg |
| Country of Origin | United States |
Why Engineers Specify This Model
- Seamless Dynamix 1440 Ecosystem Integration – Slots directly into the Dynamix 1440 chassis alongside vibration, speed, and relay modules, enabling a unified condition monitoring architecture without additional signal converters.
- Dual-Channel Process Acquisition – Two independent process inputs allow simultaneous monitoring of temperature, pressure, flow, or other 4–20 mA transmitter outputs correlated with vibration data.
- FactoryTalk AssetCentre Ready – Native integration with Rockwell’s FactoryTalk platform enables automated alarm management, trend logging, and predictive analytics without custom middleware.
- Deterministic Data Timestamping – Synchronized sampling ensures process and vibration data are time-aligned for accurate root-cause analysis.
- Reduced Panel Footprint – Modular backplane design eliminates standalone transmitter cards, reducing cabinet space and wiring complexity.
- Long-Term Availability – Part of Rockwell’s sustained product lifecycle program, ensuring spare parts availability for 10+ year plant asset lifecycles.
Complete System Bill of Materials
For a complete Dynamix 1440 condition monitoring node, the following components are typically specified alongside the 1440-TPS02-01RB:
- 1440-VST02-01RB – Dynamix 1440 Vibration Module (2-channel, standard)
- 1440-SPD02-01RB – Dynamix 1440 Speed Measurement Module
- 1440-RLY02-01RB – Dynamix 1440 Relay Output Module
- 1440-ACNR04-04RB – Dynamix 1440 4-Slot Chassis
- 1440-PS01-01R – Dynamix 1440 Power Supply
- 1440-TB-A – Terminal Block Assembly
Contact Konmask.com for complete system quotations and BOM verification.
Compliance & Industry Standards
- CE Marking – Compliant with EU Machinery Directive and EMC Directive for European installations.
- UL / cUL Listed – Recognized for use in North American industrial control panels per UL 508A.
- ISO 10816 / ISO 13373 – Supports measurement methodologies aligned with international vibration severity and condition monitoring standards.
- IEC 61511 – Compatible with safety instrumented system architectures when integrated with appropriate SIL-rated logic solvers.
- RoHS Compliant – Manufactured in accordance with EU Directive 2011/65/EU on restriction of hazardous substances.
Quality Assurance & Sourcing
Konmask.com sources the Allen-Bradley 1440-TPS02-01RB exclusively through verified supply channels. Every unit offered is subject to the following quality controls:
- Visual and dimensional inspection against OEM datasheets upon receipt.
- Firmware version verification and label authenticity check.
- Anti-static packaging and climate-controlled storage to preserve module integrity.
- Full traceability documentation available upon request for regulated industries.
- Warranty: 12-month replacement warranty against manufacturing defects.
How to Source This Part
- Add to Cart – Click the purchase button above to place an order directly online.
- Request a Quote – For volume orders (>5 units) or project-based procurement, email support@konmask.com for a formal quotation within 24 hours.
- Verify Compatibility – Share your existing Dynamix chassis catalog number and we will confirm module compatibility before shipment.
- Expedited Shipping – DHL Express, FedEx International Priority, and sea freight options available. Lead time: 3–7 business days for in-stock units.
- Export Documentation – Commercial invoice, packing list, and certificate of origin provided for all international shipments.
Application-Specific FAQ
Q: Can the 1440-TPS02-01RB accept thermocouple or RTD inputs directly?
A: No. This module accepts standard process signals (4–20 mA / voltage). For temperature inputs, use a dedicated transmitter to convert thermocouple/RTD signals to 4–20 mA before connecting to this module.
Q: Is this module compatible with CompactLogix as well as ControlLogix?
A: The 1440-TPS02-01RB communicates via the Dynamix 1440 backplane, which connects to ControlLogix or CompactLogix via EtherNet/IP. It is not a native ControlLogix I/O module.
Q: What software is required to configure and monitor this module?
A: Configuration is performed via Rockwell’s FactoryTalk AssetCentre or Studio 5000 Logix Designer with the appropriate Dynamix Add-On Profile (AOP) installed.
Q: Can I use this module as a standalone unit without a full Dynamix chassis?
A: No. The 1440-TPS02-01RB requires a Dynamix 1440 chassis (e.g., 1440-ACNR04-04RB) and power supply for operation.
Q: Do you offer repair or exchange services for this module?
A: Yes. Konmask.com offers exchange and repair evaluation services. Contact support@konmask.com with your module serial number for assessment.
