Rotating Machinery Vibration Monitoring Solution – Bently Nevada 24701-28-05-20-024-03-02 | 3300 XL Series
The Bently Nevada 24701-28-05-20-024-03-02 is a precision-engineered Proximity Probe Housing Assembly designed for continuous, real-time vibration and position monitoring of rotating machinery. As a core component of the industry-leading 3300 XL Series, this assembly enables engineers to detect shaft displacement, radial vibration, and axial position with exceptional accuracy — protecting critical assets from catastrophic failure.
Where This Product Is Used
This proximity probe housing assembly is specified across a wide range of heavy-industry and process-critical environments:
- Steam & Gas Turbines — Continuous shaft radial vibration monitoring per API 670 requirements; early detection of rotor imbalance, misalignment, and bearing wear.
- Centrifugal & Axial Compressors — Monitoring shaft position and vibration in high-speed compressor trains in LNG, petrochemical, and refinery applications.
- Pumps & Blowers — Installed on large process pumps and induced-draft fans where bearing health is critical to plant uptime.
- Gearboxes & Expanders — Radial shaft monitoring in power recovery expanders and high-ratio gearboxes.
- Hydro & Wind Turbines — Shaft displacement measurement in renewable energy generation equipment.
- Marine Propulsion Systems — Monitoring propeller shaft vibration and alignment in vessel drive trains.
Wherever rotating shafts demand protection, the 24701-28-05-20-024-03-02 housing assembly provides the mechanical interface that keeps the eddy-current probe precisely positioned and mechanically secured.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 24701-28-05-20-024-03-02 |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Series | 3300 XL Proximity Transducer System |
| Product Type | Proximity Probe Housing Assembly |
| Probe Tip Diameter | 8 mm (compatible with 3300 XL 8 mm probes) |
| Cable Length | 5.0 m (extension cable included per configuration) |
| Thread Size | M10 × 1.0 (standard mounting thread) |
| Housing Material | 316 Stainless Steel |
| Temperature Range | -35°C to +177°C (operating) |
| Ingress Protection | IP67 |
| Connector Type | Integral armored cable with BNC/TNC termination |
| Weight | 1,380 g (assembly) |
| Approvals | CE, ATEX, IECEx (consult datasheet for zone ratings) |
Why Engineers Specify This Model
- API 670 Compliant — Meets the Machinery Protection Systems standard mandated for turbomachinery in oil & gas and petrochemical plants.
- Eddy-Current Precision — Non-contact measurement eliminates mechanical wear; linear output over the full measurement range.
- 316 SS Construction — Corrosion-resistant housing withstands aggressive process environments including H₂S, steam, and hydrocarbon atmospheres.
- IP67 Sealed — Fully protected against dust ingress and temporary immersion; suitable for wash-down and outdoor installations.
- Drop-in Replacement — Identical form, fit, and function to OEM specification; no recalibration of the monitoring system required.
- Long Service Life — Solid-state eddy-current technology with no moving parts; MTBF exceeds 100,000 hours in typical installations.
Complete System Bill of Materials
The 24701-28-05-20-024-03-02 is typically deployed as part of a complete 3300 XL transducer system. A standard BOM includes:
- Proximity Probe — 3300 XL 8 mm probe (e.g., 330103-00-06-10-02-00)
- Extension Cable — 3300 XL extension cable, matched length (e.g., 330130-080-00-00)
- Proximitor® Sensor / Driver — 3300 XL proximitor (e.g., 330180-X1-05)
- Housing Assembly — 24701-28-05-20-024-03-02 (this item)
- Monitor Module — 3500/40M or 3500/42M Proximitor/Seismic Monitor
- Rack & Power Supply — 3500 Monitoring System rack with 3500/15 power supply
Contact support@konmask.com for complete system sourcing and BOM verification.
Compliance & Industry Standards
- API 670 — Machinery Protection Systems (5th Edition)
- IEC 61511 — Functional Safety for Process Industry Sectors
- ATEX Directive 2014/34/EU — Equipment for explosive atmospheres
- IECEx Scheme — International certification for Ex equipment
- ISO 10816 / ISO 20816 — Mechanical vibration evaluation standards
- CE Marking — European conformity
Quality Assurance & Sourcing
At Konmask.com, every Bently Nevada component is sourced through verified industrial supply channels. Our quality process includes:
- Visual and dimensional inspection against OEM drawings
- Functional verification of probe-to-housing fit and cable continuity
- Traceability documentation available on request (lot number, date code)
- Secure anti-static packaging for transit protection
- 30-day return policy for unused, unopened items
We do not sell counterfeit or refurbished parts without explicit disclosure. All items are represented accurately as new, surplus-new, or reconditioned where applicable.
How to Source This Part
- Add to Cart — Click the purchase button above to proceed directly.
- Request a Quote — Email support@konmask.com with your PO number, required quantity, and delivery timeline.
- Urgent Orders — Call or WhatsApp +0086 19859288691 for same-day response on critical plant shutdowns.
- Bulk / OEM Orders — Volume pricing available for MRO storerooms and EPC contractors. Request a formal quotation.
Typical lead time: 3–7 business days for in-stock items. Express air freight available for shutdown-critical orders.
Application-Specific FAQ
Q: Is the 24701-28-05-20-024-03-02 compatible with the Bently Nevada 3500 monitoring system?
A: Yes. This housing assembly is designed for use with the 3300 XL transducer system, which interfaces directly with the 3500 series monitors via standard Proximitor® drivers.
Q: Can this probe housing be used in ATEX Zone 1 hazardous areas?
A: The 3300 XL series carries ATEX and IECEx certifications. Verify the specific zone rating on the product datasheet or contact us to confirm suitability for your installation.
Q: What is the measurement range of the 3300 XL 8 mm probe used with this housing?
A: The standard linear range is 0.25 mm to 2.25 mm (gap), with a scale factor of approximately 7.87 V/mm. Confirm with the matched Proximitor® driver datasheet.
Q: Do I need to recalibrate my monitoring system after replacing the housing assembly?
A: The housing assembly itself does not affect calibration. However, if the probe or extension cable is also replaced, a full system calibration per Bently Nevada procedures is recommended.
Q: Is this a new or refurbished part?
A: Please confirm with our team at the time of order. We clearly disclose condition (new, surplus-new, or reconditioned) for every unit shipped.
Q: Can Konmask supply the complete 3300 XL transducer system?
A: Yes. We can source the full BOM including probe, extension cable, Proximitor® sensor, and monitor modules. Contact us with your system requirements.
