Bently Nevada 3500/61 163179-02 – Temperature Monitor | 3500 Series Machinery Protection Platform
Engineering Background
The Bently Nevada 3500 Series is the industry-standard modular machinery protection system deployed across power generation, oil & gas, petrochemical, and rotating equipment facilities worldwide. Developed and manufactured by Bently Nevada (a Baker Hughes company), the platform is engineered to API 670 standards and is trusted by OEMs and end-users for continuous, real-time machinery health monitoring.
Product Positioning
The 3500/61 (P/N 163179-02) is a dedicated Temperature Monitor module within the 3500 rack system. It acquires thermocouple or RTD signals from critical machine components—bearings, casings, stator windings—and provides configurable alarm and danger setpoints to protect rotating assets from thermal excursions. This module integrates seamlessly into existing 3500 racks without system downtime when hot-swap procedures are followed.
Complete Technical Specifications
| Part Number | 163179-02 |
| Model | 3500/61 |
| Series / Platform | Bently Nevada 3500 Machinery Protection System |
| Module Type | Temperature Monitor |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Country of Origin | United States |
| Input Types Supported | Thermocouple (TC) / RTD (Resistance Temperature Detector) |
| Channels | Multi-channel per module (rack-dependent configuration) |
| Alarm Outputs | Configurable Alert / Danger relay outputs |
| Communication | 3500 rack backplane; Modbus / System 1 compatible |
| Power Supply | Supplied via 3500 rack power module |
| Compliance | API 670, CE, SIL-capable configurations |
| Form Factor | Single-slot 3500 rack module |
| Weight | 780 g (approx.) |
| Operating Temperature | 0 °C to +65 °C |
| Storage Temperature | -40 °C to +85 °C |
Proven Application Environments
- Power Generation: Gas turbines, steam turbines, generators — bearing and winding temperature surveillance
- Oil & Gas: Compressor trains, pumps, expanders — API 670-compliant thermal protection
- Petrochemical & Refining: Critical rotating equipment with continuous process uptime requirements
- Marine & Offshore: Propulsion systems and auxiliary machinery requiring vibration-immune temperature sensing
- Industrial Manufacturing: High-speed spindles, blowers, and fans requiring thermal alarm integration
Engineering Advantages
- API 670 Compliance: Meets the international standard for machinery protection instrumentation, ensuring regulatory and insurance acceptance
- Hot-Swap Capable: Module replacement without full rack shutdown minimizes process interruption
- Configurable Setpoints: Alert and Danger thresholds independently programmable per channel via Rack Configuration Software (RCS)
- High Noise Immunity: Differential input design rejects common-mode electrical interference in industrial environments
- System 1 Integration: Native compatibility with Bently Nevada System 1 condition monitoring software for trend analysis and predictive maintenance
- Proven Field Reliability: Deployed in thousands of installations globally with documented MTBF exceeding 100,000 hours
System Architecture & Signal Flow
The 3500/61 module occupies a single slot in the 3500 rack chassis. Temperature sensors (TC or RTD) connect to the I/O module terminal block. Conditioned signals pass through the backplane to the 3500/61 monitor, which applies engineering-unit conversion, compares values against programmed setpoints, and drives relay outputs and system communication simultaneously. The rack’s Communication Gateway module (e.g., 3500/92) forwards data to DCS/SCADA via Modbus TCP or OPC.
Sourcing & Quality Verification
- All units sourced from verified industrial surplus, OEM overstock, or authorized distribution channels
- Each module undergoes visual inspection, label verification (P/N, revision, date code), and functional pre-shipment check
- Original firmware and hardware revision preserved — no unauthorized modifications
- Packaging: anti-static ESD bag + foam-lined carton; humidity indicator included for international shipments
- Certificate of conformance available upon request
Procurement Process
- Confirm compatibility: Verify your 3500 rack revision and I/O module pairing before ordering
- Request quote: Contact support@konmask.com for volume pricing, lead time, and availability confirmation
- Place order: Purchase via this listing or submit a PO — net payment terms available for qualified accounts
- Shipping: DHL / FedEx international express; export documentation (commercial invoice, packing list, COO) included
- After-sales: 90-day warranty on verified units; RMA process available
Technical FAQ
Q: Is the 163179-02 revision compatible with all 3500 rack generations?
A: The 3500/61 is compatible with standard 3500 rack chassis. Confirm your rack’s backplane revision with Bently Nevada documentation or contact us for cross-reference support.
Q: Can this module accept both TC and RTD inputs simultaneously?
A: Input type is configured per channel via RCS software. Consult the 3500/61 datasheet (GEK-91485) for channel configuration rules.
Q: What is the lead time for this part?
A: In-stock units typically ship within 1–3 business days. Contact us to confirm current inventory status.
Q: Do you provide a test report or functional verification certificate?
A: Yes. A pre-shipment inspection report is available upon request at no additional charge.
Q: Is this a new or refurbished unit?
A: Units are clearly described as new surplus or tested-good refurbished. Condition is confirmed in your order confirmation.
