Bently Nevada 3500/64M 176449-05 Dynamic Pressure Monitor | Replacement, Equivalent & Selection Guide
The Bently Nevada 3500/64M (P/N 176449-05) is a dedicated dynamic pressure monitoring module within the industry-standard 3500 Series Machinery Protection System. Designed for continuous, real-time measurement of dynamic pressure fluctuations in rotating and reciprocating machinery, this module is widely deployed in turbines, compressors, pumps, and process-critical equipment across oil & gas, power generation, and petrochemical industries.
Technical Specifications
- Manufacturer: Bently Nevada (Baker Hughes)
- Model / Part Number: 3500/64M | 176449-05
- Module Type: Dynamic Pressure Monitor
- Platform: Bently Nevada 3500 Series Machinery Protection System
- Channels: 2-channel dynamic pressure input
- Input Signal: Compatible with dynamic pressure transducers (charge-mode / IEPE)
- Frequency Range: Configurable per application requirements
- Communication: Rack-based backplane communication; supports System 1 software integration
- Power Supply: Supplied via 3500 rack backplane (typically 24 VDC)
- Approvals: SIL 2 capable; CE marked; suitable for hazardous area installations (with appropriate barriers)
- Weight: Approx. 800 g
- Operating Temperature: 0 °C to +65 °C
- SKU: 3500/64M 176449-05
Compatible Replacement & Equivalent Models
When the original 3500/64M 176449-05 is unavailable or requires a cost-effective alternative, the following models are commonly evaluated:
- Bently Nevada 3500/64 (176449-01 / -02 / -03) – Earlier revisions of the same module family; verify firmware and rack compatibility before substitution.
- Bently Nevada 3500/65 Pressure Monitor – Static pressure variant; not a direct dynamic replacement but used in hybrid monitoring architectures.
- Emerson CSI 6500 ATG – Emerson’s next-generation platform; requires full rack migration and software reconfiguration.
- Metrix MX2033 – Third-party dynamic pressure monitor; compatible with standard charge-mode transducers; requires relay output mapping.
- Rockwell ICS Triplex T8431 – SIL-rated pressure monitor for TMR architectures; suitable for safety-critical upgrades.
⚠ Note: All replacements must be validated against your specific rack configuration, transducer type, and system software version. Contact Konmask for pre-sales compatibility review.
Why Choose the Original Model
- Proven field reliability – Deployed in thousands of machinery protection systems globally across critical infrastructure.
- Seamless 3500 rack integration – Plug-and-play within existing 3500 Series racks; no hardware modification required.
- System 1 software compatibility – Full integration with Bently Nevada System 1 condition monitoring and diagnostics platform.
- SIL 2 functional safety – Meets IEC 61511 requirements for safety instrumented systems.
- Regulatory acceptance – Widely accepted by API 670 compliance audits in rotating machinery protection.
- Minimized re-engineering cost – Using the original P/N avoids costly reconfiguration, re-validation, and downtime.
Typical Applications
- Gas turbine combustion dynamics monitoring
- Reciprocating compressor cylinder pressure analysis
- Centrifugal pump cavitation detection
- Steam turbine blade passing frequency measurement
- Flare header and process line pressure pulsation monitoring
- Offshore platform and FPSO machinery protection systems
System Compatibility
- Rack: Bently Nevada 3500 Series (3500/20 Power Supply required)
- Communication Gateway: 3500/92 or 3500/93 Communication Gateway Module
- Software: System 1 v6.x / v7.x; Bently Nevada Rack Configuration Software (RCS)
- Transducers: Compatible with Bently Nevada 330900 series dynamic pressure transducers and equivalent IEPE/charge-mode sensors
- I/O Module: Requires dedicated I/O module (sold separately); verify P/N against rack slot assignment
Selection Guide
Use the following criteria to confirm the 3500/64M 176449-05 is the correct module for your application:
- ✅ Existing 3500 rack infrastructure – If your plant already runs a 3500 Series rack, this module is the lowest-risk, lowest-cost upgrade path.
- ✅ Dynamic (AC) pressure measurement required – For static pressure, consider the 3500/65 instead.
- ✅ Charge-mode or IEPE transducer – Confirm transducer output type matches module input specification.
- ✅ API 670 compliance required – This module supports API 670 4th/5th edition machinery protection requirements.
- ✅ SIL 2 safety loop – Suitable for use in SIL 2 safety instrumented functions with appropriate proof-test intervals.
- ⚠ New greenfield installation – For new projects, evaluate whether the Emerson CSI 6500 or System 1 Evolution platform better fits long-term roadmap.
Quality Assurance & Sourcing
- Source: Konmask.com sources from authorized distributors, OEM-certified channels, and verified surplus inventories.
- Inspection: All units undergo visual inspection, label verification, and functional pre-shipment checks.
- Warranty: 12-month warranty against manufacturing defects on all stocked units.
- Traceability: Full documentation including original packaging, datasheet, and certificate of conformance available on request.
- Lead Time: In-stock units ship within 1–3 business days; ex-stock international delivery 5–10 business days.
How to Order
- Confirm your rack slot availability and existing module P/N from your 3500 rack configuration printout.
- Verify transducer type (charge-mode vs. IEPE) and cable termination requirements.
- Add 3500/64M 176449-05 to cart, or contact us for volume pricing and lead time confirmation.
- Provide your shipping address and preferred freight method at checkout.
- For urgent requirements, email support@konmask.com with subject line: URGENT – 3500/64M 176449-05.
Replacement & Compatibility FAQ
Q: Can I use a 176449-01 or 176449-03 in place of the 176449-05?
A: Earlier revisions (-01, -02, -03) are functionally similar but may differ in firmware version and minor hardware revisions. Always verify compatibility with your rack firmware and System 1 software version before substitution. Konmask can assist with revision mapping.
Q: Is the 3500/64M compatible with third-party transducers?
A: Yes, provided the transducer output matches the module’s input specification (charge-mode or IEPE). Sensitivity and frequency range must be configured in RCS to match the transducer datasheet.
Q: What is the difference between the 3500/64 and 3500/64M?
A: The “M” suffix typically denotes a modified or enhanced hardware revision with improved EMC performance and updated firmware support. Confirm with your Bently Nevada documentation or contact Konmask for clarification.
Q: Can this module be used in a SIL 2 safety loop?
A: Yes. The 3500/64M is SIL 2 capable when installed and maintained per the Bently Nevada functional safety manual. A proof-test procedure must be implemented per IEC 61511.
Q: Do you offer exchange / repair services?
A: Yes. Konmask offers board-level repair and exchange programs for 3500 Series modules. Contact us for a repair quotation.
