The Bently Nevada 3500/61E (Part No. 285694-02) is a dedicated Dynamic Pressure Monitor module within the industry-standard 3500 Series Machinery Protection System. Designed for continuous, real-time monitoring of dynamic pressure fluctuations in rotating and reciprocating machinery, this module delivers high-accuracy measurements critical to plant safety and predictive maintenance programs.
Technical Specifications
- Manufacturer: Bently Nevada (Baker Hughes)
- Model / Part Number: 3500/61E — 285694-02
- Module Type: Dynamic Pressure Monitor
- Rack Compatibility: Bently Nevada 3500 Series Rack
- Channels: 2-channel dynamic pressure input
- Input Signal: Compatible with dynamic pressure transducers (ICP / charge-mode)
- Alert / Danger Setpoints: Configurable via System 1 / Rack Configuration Software
- Communication: Rack backplane communication; supports Modbus, Ethernet (rack-level)
- Power Supply: Supplied via 3500 rack backplane
- Operating Temperature: 0 °C to +65 °C
- Approvals: CE, SIL-capable (refer to datasheet for SIL rating)
- Weight: Approx. 800 g
- Form Factor: Single-slot 3500 rack module
Compatible Replacement & Equivalent Models
When the 3500/61E 285694-02 is unavailable or end-of-life, the following models may serve as functional replacements or equivalents depending on your system configuration. Always verify firmware and rack compatibility before substitution.
- Bently Nevada 3500/61 (earlier revision) — predecessor module; verify I/O card and software compatibility
- Bently Nevada 3500/61E 285694-01 — alternate sub-revision; confirm feature parity with your application
- Bently Nevada 3500/62 — Phase Reference / Process Variable Monitor; applicable in mixed-channel configurations
- Emerson CSI 6500 ATG — next-generation platform for new installations requiring advanced analytics
- Third-party 3500-compatible modules — contact Konmask for vetted OEM-equivalent sourcing options
Note: Konmask.com supplies genuine Bently Nevada modules. Replacement recommendations are for reference only; consult your system integrator for validated substitutions.
Why Choose the Original Model
- Proven reliability — field-tested in thousands of turbomachinery and compressor installations worldwide
- Seamless rack integration — plug-and-play within existing 3500 Series racks; no re-wiring required
- Software continuity — fully supported by Bently Nevada System 1 and rack configuration tools
- Regulatory compliance — meets API 670 machinery protection standards
- Long service life — designed for continuous 24/7 operation in harsh industrial environments
- Traceability — genuine part with full OEM documentation and calibration records available
Typical Applications
- Gas turbine combustion dynamics monitoring
- Reciprocating compressor cylinder pressure analysis
- Steam turbine blade-pass pressure pulsation detection
- Centrifugal pump cavitation monitoring
- Flare and process gas pressure surge detection
- Offshore platform rotating equipment protection
- LNG plant compressor train monitoring
System Compatibility
- Rack: Bently Nevada 3500 Series (all standard rack sizes)
- Software: System 1 Evolution, Rack Configuration Software (RCS)
- I/O Modules: Compatible with standard 3500 Series I/O terminal blocks
- Communication Gateways: 3500/92 Ethernet, 3500/93 Modbus, 3500/94 Profibus
- Power Supply: 3500/15 or 3500/15E Power Supply Module
- Not compatible with: 3300 Series racks or 1900 Series standalone monitors
Selection Guide
Use the following criteria to confirm the 3500/61E 285694-02 is the correct module for your application:
- Measurement type: Do you need dynamic (AC) pressure measurement? → 3500/61E ✓
- Transducer type: ICP or charge-mode dynamic pressure sensor? → 3500/61E ✓
- Channel count: 1–2 channels required? → 3500/61E ✓ (for 4+ channels, consider dual-module configuration)
- Rack slot availability: Single slot available in 3500 rack? → 3500/61E ✓
- Static pressure only: If only static/process pressure is needed → consider 3500/60 Process Variable Monitor instead
- New installation: For greenfield projects, evaluate Emerson CSI 6500 for advanced IIoT capabilities
Quality Assurance & Sourcing
- Source: Genuine Bently Nevada / Baker Hughes OEM parts
- Inspection: Each unit undergoes functional verification prior to shipment
- Condition: New, refurbished, and tested-used options available — specify at order
- Documentation: Certificate of conformance, test reports, and original packaging available on request
- Warranty: 12-month warranty on all units supplied by Konmask.com
- Lead Time: In-stock units ship within 3–5 business days; contact us for urgent requirements
How to Order
- Confirm part number: 3500/61E — 285694-02
- Specify required condition: New / Refurbished / Tested-Used
- Provide quantity and delivery timeline
- Submit inquiry via support@konmask.com or call +0086 19859288691
- Receive quotation within 1 business day
- Confirm order and receive shipping tracking within 24 hours of payment
Replacement & Compatibility FAQ
Q: Can I use the 285694-01 sub-revision in place of the 285694-02?
A: In most cases yes, but verify with your System 1 software version and rack firmware. Contact Konmask for a compatibility check.
Q: Is the 3500/61E compatible with third-party dynamic pressure sensors?
A: The module is optimized for Bently Nevada-approved ICP transducers. Third-party sensors may work but require validation against the module’s input impedance and signal conditioning specs.
Q: What is the difference between the 3500/61 and 3500/61E?
A: The “E” revision introduced enhanced diagnostics, improved EMC performance, and expanded software configurability. The 3500/61E is the recommended current standard.
Q: Can Konmask supply a tested spare for emergency replacement?
A: Yes. We maintain stock of tested units for rapid dispatch. Contact us directly for emergency sourcing.
Q: Do you provide installation support?
A: We provide technical documentation and remote guidance. On-site commissioning support can be arranged through our partner network.
