DCS Field Wiring Solution – FOXBORO RH916DB | I/A Series Cable Assembly
Where This Product Is Used
The FOXBORO RH916DB Cable Assembly Termination is engineered for field-to-controller wiring in Foxboro I/A Series Distributed Control Systems (DCS). It is widely deployed in:
- Oil & Gas Processing Plants – connecting field transmitters and actuators to FBM (Field Bus Module) termination assemblies
- Chemical & Petrochemical Facilities – providing reliable signal routing in hazardous-area control loops
- Power Generation – integrating analog and discrete I/O signals from turbine and boiler instrumentation
- Pulp & Paper Mills – supporting continuous process control with structured cable management
- Water & Wastewater Treatment – enabling SCADA/DCS hybrid architectures with standardized termination
Technical Specifications
- Part Number: RH916DB
- Manufacturer: Foxboro (Schneider Electric)
- Series: I/A Series DCS
- Type: Cable Assembly Termination
- Weight: 280 g
- Connector Type: DB-style multi-pin termination
- Application: FBM field wiring interface / marshalling cabinet termination
- Compatibility: Foxboro I/A Series FBM modules and termination assemblies
- Condition: New / Refurbished (specify at inquiry)
Why Engineers Specify This Model
- Drop-in Compatibility: Designed specifically for Foxboro I/A Series architecture — no field modification required
- Reduced Wiring Errors: Pre-terminated cable assembly eliminates point-to-point field wiring mistakes
- Faster Commissioning: Plug-and-connect design cuts marshalling cabinet installation time significantly
- Signal Integrity: Shielded construction maintains signal quality in electrically noisy industrial environments
- Long Service Life: Industrial-grade materials rated for continuous duty in process control environments
Complete System Bill of Materials
The RH916DB is typically used alongside the following Foxboro I/A Series components:
- Foxboro FBM (Field Bus Module) – analog/discrete I/O modules
- Foxboro ZCP270 / CP60 – Control Processors
- Foxboro NFEP-0002 / NFEP-0004 – Ethernet Fieldbus Modules
- Foxboro Termination Assemblies (TA series) – DIN-rail mounted signal termination
- Foxboro P0916SA / P0916SB – related cable assemblies for FBM interconnect
- Marshalling cabinet DIN rails, terminal blocks, and cable management trays
Compliance & Industry Standards
- Designed and manufactured to Foxboro / Schneider Electric engineering standards
- Compatible with IEC 61511 (Functional Safety – Process Industry) system architectures
- Suitable for use in installations compliant with ISA-5.1 instrumentation wiring practices
- RoHS-compliant materials (verify with current datasheet for specific revision)
Quality Assurance & Sourcing
- Inspection: Every unit undergoes visual and continuity inspection prior to shipment
- Traceability: Batch and serial documentation available on request
- Sourcing: Procured from authorized distributors, OEM surplus, or certified refurbishers
- Warranty: 90-day replacement warranty against defects in materials and workmanship
- Packaging: Anti-static, moisture-barrier packaging for safe international transit
How to Source This Part
- Submit your RFQ via Konmask.com with quantity and required delivery date
- Receive a formal quotation within 1 business day
- Confirm order — we verify stock condition and issue a proforma invoice
- Payment processed securely; shipment dispatched within 3–5 business days
- Tracking number and shipping documents provided upon dispatch
📧 support@konmask.com | 📞 +0086 19859288691
Application-Specific FAQ
Q: Is the RH916DB compatible with all Foxboro I/A Series FBM modules?
A: The RH916DB is designed for specific FBM termination interfaces. Please confirm your FBM model number when submitting your RFQ so we can verify pin-for-pin compatibility.
Q: Can this cable assembly be used in a hazardous (Ex) area?
A: The cable assembly itself is not intrinsically safe rated. For hazardous-area installations, ensure the overall loop design uses appropriate IS barriers or Zener barriers per your site’s area classification.
Q: Do you supply refurbished units?
A: Yes. Refurbished units are available and are fully tested and documented. Please specify your preference (new or refurbished) in your inquiry.
Q: What is the lead time for bulk orders?
A: Standard stock orders ship within 3–5 business days. For bulk or project quantities, lead time is quoted individually based on availability.
Q: Can you provide a certificate of conformance?
A: Yes, a Certificate of Conformance (CoC) is available upon request for all orders.
