Process Control Solution – Honeywell 80364052-100 | TDC 3000 Analog Input Module
Where This Product Is Used
The Honeywell 80364052-100 Analog Input Module is deployed in continuous process industries where precise field signal acquisition is critical to safe and efficient plant operation. Typical installation environments include:
- Oil & Gas Refineries – Monitoring pressure transmitters, flow meters, and temperature sensors across distillation columns and reactor loops.
- Chemical & Petrochemical Plants – Acquiring 4–20 mA signals from field instruments in hazardous-area processes requiring high-integrity data acquisition.
- Power Generation Facilities – Integrating boiler drum level, turbine exhaust temperature, and feedwater flow signals into the TDC 3000 supervisory layer.
- Pulp & Paper Mills – Continuous monitoring of digester pressure and consistency transmitters within Honeywell TotalPlant DCS architectures.
- Pharmaceutical Manufacturing – GMP-compliant batch process monitoring where validated DCS platforms are mandated.
- Water & Wastewater Treatment – Integrating level, pH, and flow analog signals into centralized SCADA/DCS control systems.
Technical Specifications
- Part Number: 80364052-100
- Manufacturer: Honeywell Process Solutions
- Series: TDC 3000 / TotalPlant Solution (TPS)
- Module Type: Analog Input Module (AIM)
- Signal Type: 4–20 mA / 1–5 V DC analog field inputs
- Isolation: Channel-to-channel and channel-to-bus isolation
- Communication Bus: Local Control Network (LCN) / Universal Control Network (UCN)
- Form Factor: Card/module for TDC 3000 card file chassis
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Weight: Approx. 700 g
- Country of Origin: USA
Why Engineers Specify This Model
- Platform Continuity: Direct drop-in replacement for existing TDC 3000 / TPS card file slots — no firmware reconfiguration or bus adapter required.
- Signal Integrity: Hardware-level channel isolation prevents ground loops and cross-channel interference in multi-transmitter loops.
- Proven Reliability: Honeywell TDC 3000 modules are field-proven across decades of continuous operation in Tier-1 process facilities globally.
- Reduced Downtime: Hot-swap compatible within supported TDC 3000 card file configurations, minimizing process interruption during maintenance.
- Long-Term Support: Sourcing genuine Honeywell spare modules extends the operational life of legacy TDC 3000 systems without costly full-system migrations.
Complete System Bill of Materials
For a fully operational TDC 3000 analog input subsystem, engineers typically specify the following alongside the 80364052-100:
- Honeywell TDC 3000 Card File / Chassis (e.g., 51401288-100)
- Honeywell Power Supply Module (e.g., 51109684-100)
- Honeywell LCN/UCN Interface Card
- Honeywell Field Termination Assembly (FTA) for AIM
- Shielded twisted-pair field wiring (per ISA-5.1 standard)
- Honeywell TPS / Experion configuration software license
Contact support@konmask.com for bundle pricing on complete subsystem kits.
Compliance & Industry Standards
- Designed and tested to IEC 61511 functional safety guidelines for process industry SIS applications
- Compatible with ISA-5.1 instrumentation signal and loop diagram standards
- Suitable for installation in environments meeting IEC 60068 environmental testing requirements
- Honeywell factory quality management system certified to ISO 9001
Quality Assurance & Sourcing
Every Honeywell 80364052-100 unit shipped by Konmask.com undergoes the following verification process:
- ✔ Visual inspection for physical damage, corrosion, and component integrity
- ✔ Label and part number authentication against Honeywell OEM markings
- ✔ Functional power-on test where applicable
- ✔ Anti-static packaging with humidity indicator card
- ✔ Traceable documentation provided upon request
We source exclusively from authorized distributors, decommissioned plant inventories, and certified refurbishers. Counterfeit-free guarantee backed by our sourcing policy.
How to Source This Part
- Add to Cart – Click “Buy Now” or “Add to Cart” above.
- Request a Quote – For volume orders (>3 units) or urgent requirements, email support@konmask.com for priority pricing.
- Lead Time – In-stock units ship within 1–3 business days. Ex-stock lead time for sourced units: 5–10 business days.
- Export & Customs – We handle export documentation for international shipments including China customs declarations.
- Payment – T/T bank transfer, PayPal, and major credit cards accepted.
Application-Specific FAQ
Q: Is the 80364052-100 compatible with both TDC 3000 and TPS (TotalPlant Solution) architectures?
A: Yes. The module is designed for the TDC 3000 platform, which is the hardware foundation of the TotalPlant Solution (TPS). It is slot-compatible with standard TDC 3000 card file chassis used in both architectures.
Q: Can this module be used as a direct replacement without reconfiguring the DCS database?
A: In most cases, yes — provided the replacement module carries the same part number and revision. Always verify the module revision suffix against your system’s hardware compatibility matrix before installation.
Q: Do you provide a warranty on this module?
A: We offer a 90-day functional warranty on all tested units. Extended warranty options are available — contact us for details.
Q: Can you supply the matching Field Termination Assembly (FTA)?
A: Yes. Contact support@konmask.com with your full BOM and we will source the complete assembly.
Q: What is the lead time for bulk orders?
A: For orders of 5+ units, please allow 7–14 business days. We maintain relationships with multiple authorized Honeywell channel partners to fulfill large requirements.
