Honeywell FC-TDOL-0724 / FC-TDOL-0724P Analog Input Module | Replacement, Equivalent & Selection Guide
The Honeywell FC-TDOL-0724 (also known as FC-TDOL-0724P) is a high-precision Analog Input Module designed for use in Honeywell’s Experion PKS Distributed Control System (DCS). It provides reliable signal acquisition for process control applications in industries such as oil & gas, chemical, power generation, and manufacturing. This page serves as a comprehensive selection, replacement, and compatibility reference for engineers and procurement teams.
Technical Specifications
- Part Number: FC-TDOL-0724 / FC-TDOL-0724P
- Manufacturer: Honeywell Process Solutions
- Module Type: Analog Input (AI)
- Series: Experion PKS / TotalPlant Solution (TPS)
- Signal Type: 4–20 mA / 1–5 V (configurable)
- Channels: 8 channels (isolated)
- Resolution: 16-bit A/D conversion
- Communication: FTE (Fault Tolerant Ethernet) / CEE bus
- Power Supply: 24 VDC (supplied via backplane)
- Operating Temperature: 0°C to 60°C
- Dimensions: Standard Honeywell I/O module form factor
- Certifications: CE, UL, FM (Class I, Div 2)
- Weight: Approx. 200 g
Compatible Replacement & Equivalent Models
The following modules are commonly evaluated as replacements or functional equivalents for the FC-TDOL-0724. Always verify electrical and firmware compatibility before substitution:
- FC-TDOL-0724P — Factory-sealed/protected variant; direct functional equivalent
- Honeywell FC-SDAI-0824 — 8-ch AI module, same Experion PKS platform; verify channel count and signal range
- Honeywell 51304485-150 — Legacy TPS AI module; compatible with older C200/C300 controllers via adapter
- Honeywell 51309276-175 — High-density AI module; suitable for expansion applications
- ABB AI810 — Third-party alternative for 800xA DCS; requires engineering re-mapping
- Emerson KJ3221X1-BA1 — DeltaV AI module; cross-platform migration option with I/O marshalling changes
Note: Cross-brand replacements require system re-engineering. Konmask recommends using OEM-equivalent Honeywell modules for plug-and-play replacement.
Why Choose the Original FC-TDOL-0724
- Zero re-engineering: Drop-in replacement within existing Experion PKS architecture
- Firmware compatibility: Fully supported by Honeywell’s R400–R520 Experion releases
- Diagnostic support: Native FDT/DTM and Experion Station alarm integration
- Redundancy ready: Supports hot-standby I/O redundancy configurations
- Long lifecycle: Honeywell’s extended support program covers legacy DCS hardware
Typical Applications
- Oil & gas upstream/downstream process monitoring
- Chemical plant temperature, pressure, and flow signal acquisition
- Power plant boiler and turbine control loops
- Pharmaceutical batch process control
- Water treatment and utilities automation
System Compatibility
- DCS Platform: Honeywell Experion PKS (C200, C300, C300E controllers)
- Legacy Systems: TotalPlant Solution (TPS) with appropriate adapter
- Software: Experion R400, R410, R430, R500, R510, R520
- I/O Link: CEE (Control Execution Environment) bus
- Redundancy: Supported with IOLIM redundancy module
Selection Guide
Use the following criteria to confirm the FC-TDOL-0724 is the right module for your application:
- Step 1 — Verify controller type: Confirm your system uses a C200 or C300 Experion PKS controller
- Step 2 — Check signal type: Ensure field devices output 4–20 mA or 1–5 V analog signals
- Step 3 — Count channels: FC-TDOL-0724 provides 8 isolated AI channels per module
- Step 4 — Confirm firmware revision: Check Experion release compatibility (R400+)
- Step 5 — Assess redundancy needs: If redundant I/O is required, pair with IOLIM module
- Step 6 — Hazardous area rating: Verify FM Class I Div 2 rating meets your site classification
Not sure which module fits your system? Contact our engineers for a free selection consultation.
Quality Assurance & Sourcing
- All units sourced from authorized distributors or verified surplus channels
- Each module undergoes visual inspection and functional verification before shipment
- Original Honeywell packaging and documentation preserved where available
- Traceability records maintained for industrial compliance requirements
- Warranty: 12 months from date of shipment
How to Order
- Add the FC-TDOL-0724 to your cart and proceed to checkout
- For bulk orders (>5 units) or urgent requirements, email support@konmask.com
- Provide your Experion PKS revision and controller model for compatibility confirmation
- Lead time: In-stock units ship within 1–3 business days; sourced units 5–15 business days
- International shipping available — DDP/DAP Incoterms supported
Replacement & Compatibility FAQ
Q: Is FC-TDOL-0724P the same as FC-TDOL-0724?
A: Yes. The “P” suffix denotes a factory-protected/conformal-coated variant. Functionally identical; choose “P” for humid or corrosive environments.
Q: Can I use FC-TDOL-0724 with a C300E controller?
A: Yes, the C300E is backward compatible with standard Experion PKS I/O modules including the FC-TDOL-0724.
Q: What is the difference between FC-TDOL-0724 and FC-SDAI-0824?
A: Both are 8-channel AI modules on the Experion PKS platform. The FC-SDAI-0824 supports HART pass-through communication; the FC-TDOL-0724 does not. Choose FC-SDAI-0824 if HART device management is required.
Q: Can I replace FC-TDOL-0724 with a third-party module?
A: Third-party replacements require significant re-engineering of I/O mapping, controller configuration, and alarm logic. Konmask strongly recommends OEM-equivalent modules for safety-critical applications.
Q: Do you offer exchange/repair services?
A: Yes. Contact us at support@konmask.com for repair evaluation and exchange pricing.
