LAM X10-14210100 – 24VDC Industrial Power Supply Module | X10 Modular Automation Platform
Engineering Background
The LAM X10-14210100 is a dedicated DC power supply module engineered specifically for the LAM X10 modular automation platform. Delivering stable, regulated 24VDC bus power to downstream I/O, communication, and controller modules, it forms the electrical backbone of any X10-series control cabinet. Its compact DIN-rail form factor and robust multi-layer protection circuitry make it the preferred choice for system integrators and OEM machine builders operating in demanding industrial environments worldwide.
Product Positioning
Targeted at procurement engineers and automation specialists who require a drop-in, OEM-verified power supply for LAM X10 system expansions, retrofits, or spare-parts inventory. Konmask.com stocks this module with full traceability documentation, ensuring compliance with plant maintenance and quality audit requirements. Whether you are commissioning a new line or maintaining an existing installation, the X10-14210100 delivers the reliability your uptime demands.
Complete Technical Specifications
- Part Number / SKU: X10-14210100
- Manufacturer: LAM
- Series / Platform: X10 Modular Automation System
- Module Type: DC Power Supply Module (PSU)
- Output Voltage: 24 VDC (regulated)
- Mounting: DIN Rail (EN 60715 / TS 35)
- Protection: Short-circuit, overload, reverse-polarity protection
- Operating Temperature: 0 °C to +55 °C
- Storage Temperature: −25 °C to +70 °C
- Relative Humidity: 5 % – 95 % RH (non-condensing)
- Weight: 1,600 g (approx.)
- Compliance: CE, RoHS
- Condition: New / Refurbished OEM (specify at inquiry)
Proven Application Environments
- Discrete manufacturing lines with LAM X10 PLC racks
- Process automation panels requiring stable 24VDC bus power
- Machine tool control cabinets and CNC auxiliary power rails
- Water treatment and HVAC distributed control systems
- Automotive assembly and conveyor system control nodes
- Spare-parts inventory for existing LAM X10 installations
- Pharmaceutical and food-grade automation requiring CE/RoHS compliance
Engineering Advantages
- Native Platform Fit: Plug-in compatible with the LAM X10 backplane — no adapter, converter, or custom wiring required.
- Regulated 24VDC Output: Tight voltage regulation ensures downstream modules receive clean, stable power, reducing nuisance trips and sensor drift.
- Compact DIN-Rail Footprint: Minimises panel real estate while maintaining full-rated continuous output.
- Integrated Multi-Layer Protection: Built-in short-circuit, overload, and reverse-polarity protection reduces system downtime and safeguards connected I/O modules.
- Industrial-Grade Longevity: Components rated for continuous duty in high-ambient-temperature environments up to 55 °C.
- Status Monitoring: Onboard LED and fault relay output enable real-time health indication at the panel and remote SCADA level.
System Architecture & Signal Flow
The X10-14210100 accepts AC mains input (or DC bus, per system configuration) and converts it to a regulated 24VDC output distributed across the X10 backplane. Power is sequenced to the CPU, I/O, and communication modules via the internal bus connector. The module’s status LED provides real-time indication of output health, and its fault relay output can be wired to the plant SCADA or safety relay for remote monitoring.
[AC/DC Mains Input]
│
▼
[LAM X10-14210100 PSU Module]
│
▼
[24VDC Regulated Backplane Bus]
├── CPU / Controller Module
├── Digital Input / Output Modules
├── Analog Input / Output Modules
└── Communication & Network Modules
Sourcing & Quality Verification
- Origin: OEM-sourced from authorised LAM distribution channels.
- Traceability: Each unit ships with manufacturer serial number and, where available, original packaging and datasheet.
- Pre-Shipment Inspection: Functional test and visual inspection performed by Konmask technical staff before dispatch.
- Warranty: 90-day replacement warranty against manufacturing defects (see full policy at Konmask.com/policies).
- Counterfeit Prevention: All units verified against LAM OEM markings, label fonts, and PCB revision codes prior to listing.
- Certificate of Conformance: Available upon request — note in your purchase order or contact us before checkout.
Procurement Process
- Confirm part number X10-14210100 matches your BOM or existing system label.
- Select quantity and add to cart — bulk pricing available for orders of 5+ units (contact us).
- Choose shipping method: DHL Express, FedEx International Priority, or sea freight for large orders.
- Receive order confirmation with tracking number within 1 business day of payment clearance.
- Inspect unit upon receipt and retain original packaging for warranty claims.
Technical FAQ
Q: Is the X10-14210100 compatible with all LAM X10 backplane revisions?
A: Yes. The module is designed to the X10 platform standard and is backward-compatible with all known X10 backplane revisions. Confirm your backplane revision with LAM documentation if in doubt.
Q: Can this module be used as a standalone 24VDC power supply outside the X10 rack?
A: It is optimised for X10 backplane integration. Standalone use is technically possible but not recommended without consulting the LAM X10 system manual.
Q: What is the lead time for out-of-stock units?
A: Typical lead time for sourced units is 7–15 business days. Contact support@konmask.com for real-time availability.
Q: Do you provide a Certificate of Conformance (CoC)?
A: Yes, upon request at time of order. Please note this in your purchase order or contact us before checkout.
Q: What is the return policy?
A: Units may be returned within 30 days of receipt if unused and in original condition. See full policy at Konmask.com/policies/refund-policy.
Q: Is a datasheet or wiring diagram available?
A: Yes. Contact support@konmask.com with your part number and we will provide the relevant LAM X10 technical documentation.
